Utility Relay AC-PRO Retrofit Kit Instructions Manual page 6

ILLUSTRATIONS
Figure
1 Front View, Breaker with Amptector ....................17
2 Front View, Breaker with Digitrip .....................18
3 Side View, Trip Unit Installation, Amptector...........19
4 Side View, Trip Unit Installation, Digitip ............20
5 Top View, BR-020-1 Bracket Installation................21
6 CT Installation, With Terminals........................22
7 New Actuator Installation..............................23
8 New Actuator Assembly..................................24
9 Side View, Neutral CT Installation, Amptector..........25
10 Side View, Neutral CT Installation, Digitrip ..........26
11 Neutral Interposing CT Terminal Block Installation.....27
12 Standard Wiring Diagram................................28
13 Wiring Diagram (5:1 Interposing Neutral CT)............29
14 Side View, PT Module Installation, Amptector...........30
15 Side View, PT Module Installation, Digitrip ...........31
16 Side View, Fuse Block Installation, Amptector..........32
17 Side View, Fuse Block Installation, Digitrip...........33
18 Communications Wiring Diagram..........................34
19 TEMPLATE: QT-SWITCH-ENCLOSURE Drilling Plan............35
20 QT-SWITCH-ENCLOSURE Installation.......................36
