FOREDOM Work Bench System Mounting Instructions

Foredom Work Bench System
®
All components are available separately.
MALB-1
MAAH-B
MAAH-J
MAAH-HR
MAAH-P
MAAH-M
MAAH-H
MAAH-T
Components:
Part No. / Product Name / Description
MAMH-13 Dual Motor Hanger – Base mount with
supplied wood screws, 2 spring safety hooks, hex key
MALB-1 LED Light Bar – with Shade
31.5" (80cm) long. For 115 Volt or 230 Volt.
630 Lumens, 9 Watt, 24 Volt.
MAAH-B Bur Holder Arm – 2 tiers hold 95 burs:
Top tier holds 57 burs with 3/32" shanks Bottom tier
holds 38 burs with 1/8" shanks Arm: 12" long x 2" wide
x 1-1/4" high (30cm x 5cm x 3cm)
MAAH-J 6 Jar Arm – Holds 6 –1.35 oz. (40ml)
plastic jarswith screw-on tops. Jars are 1-1/2" (3.18cm)
in diameter Arm: 12" long x 2" wide x 2-1/2" high
(30cm x 5cm x 6cm)
MAAH-P Peg Arm – 5 angled, stainless pegs on
each side of arm which has non-scratch felt along
upper edge. Pegs are 1-1/2" long x 5/16" in diameter
(3.7cm x 0.8cm) Arm: 12" long x 4" wide x 1-1/2" high
(30cm x 10.2cm x 3.7cm)
MAAH-M Magnetic Arm – with non-scratch felt
surface Arm: 12" long x 1/2" wide x 1-1/2" high
(30cm x 1.2cm x 3.7cm)
MAAH-T Tray Arm – with movable partitions
Arm: 12" long x 2-1/4" wide x 1-1/4" high
(30cm x 5.8cm x 3cm)
MAAM-L Support Rod 25.75" long, .875" diameter with
MABC-3 mounting plate
MAAM-S Support Rod 17.75" long, .875" diameter with
MABC-3 mounting plate
MAAH-HR Dual Handpiece Rest – holds 2 flex shaft
" long x 3 " wide x 1 " high (13.3cm x
handpieces. 5 1 ⁄ 1 ⁄ 1 ⁄
4 4 2
8.3cm x 3.8cm)
MAAH-H Multi Handpiece Arm – holds 6 handpieces.
" wide x 1 " high
Arm: 12" long x 2 ⁄ ⁄
1 1
4 4
(30cm x 5.8cm x 3cm)
Contact your favorite Foredom dealer for Foredom Work Bench System components or replacement parts.
Components and replacement parts are also available on our website www.foredom.net
Flex shafts, tools and
rotary accessories
not included.
MAMH-13 MAAM-L MAAM-S
adjustable 25.75" 17.75"
height
Shelf Arms swing 180°
horizontally for easy access
to compact tools such as a
micromotor, filter hood,
wax carver, and more.
MAAH-S Shelf Arm
MAAH-S Medium Shelf –
" x 8 " (260mm x 220mm)
Arm: 10 ⁄ ⁄
1 3
4 4
" x 6"
MAAH-S2 Small Shelf – Arm: 4 ⁄
3
4
(120mm x 155mm)
" x 13 "
MAAH-S3 Large Shelf – Arm: 9 ⁄ ⁄
1 1
4 4
(235mm x 335mm)
Replacement Components:
Part No. / Description
UAL018 Adapter Plug for light
UAL016 Light Connector Cordset
UAL013 Light Shade
UAL012 Micro Switch for light
UAL007 LED Light Strip
UAL008 Light Shade
UAL015 Hanger Hook with spring
MAJAR 40ml Plastic Jar with Cap
MAJAR-6 40ml Plastic Jars with Cap, 6pk
UAL302 4mm Head Hex Screw to tighten arms
onto upright rod
MABC-3 Base Mounting Plate
FOREDOM
Work Bench System
Be sure to read
the set-up and
assembly instructions
before installing the
Work Bench System!
Flex shafts, tools
and rotary accessories
not included.
Safety Instructions
Before using your Foredom power tool,
please read safety instructions. They are for
your protection and should always be
followed to reduce the risk of personal
injury or damage to the tool.
Always wear proper eye and face protection.
•
Wear safety glasses or face shields whenever
you operate a Foredom or any power tool to
prevent serious eye or face injuries.
Secure the work piece or item that you are
•
working on in a vise or other work holding
device. Holding it with your hand can result in
serious hand injury.
Always use a proper dust collection system or
•
wear a respirator to prevent the inhalation of
dust particles, polishing compounds, or other
debris into the lungs.
Foredom Electric Company
16 Stony Hill Road, Bethel, CT 06801 USA
Tel: 203-792-8622 Fax: 203-796-7861
•
Email: customerservice@blackstoneind.com
www.foredom.net
®
Do not wear loose fitting clothing or jewelry.
•
Loose clothing or jewelry can become entangled
in the rotating accessory. Do not wear items
such as neckties, necklaces, or bracelets when
operating power tools. Be sure to tie back or
secure long hair.
Secure flex shaft power tool to motor
•
hanger or work surface. Flexible shaft
power tools can "jump" at start up or
vibrate during operation. The tool should
be properly secured in order to prevent it
from vibrating off of the motor hanger or
work bench.
Never operate any accessory at speeds above
•
its maximum rated speed. When properly used,
all of Foredom's accessories can be operated at
the speed ratings listed in the Foredom Acces-
sory Catalog or specified on kits and packages.
Always find out the manufacturer's speed rating
before using accessories other than those
from Foredom.
F-1362 2/17 n
