Summary of Contents for Ilsco ND-58
- Page 1 INSTRUCTION MANUAL ND-58 and ND-60 Mechanical Crimping Tools Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 999 4935.0 © 2003 Ilsco Corporation 7/03...
- Page 2 All specifications are nominal and may change as design improve- by this warranty. This warranty is null and void if instruc- ments occur. Ilsco shall not be liable for damages resulting from tions and operating procedures are not followed. Contact misapplication or misuse of its products.
- Page 3 • For the ND-60, the upper opening is a “BG” die. 3. Check that the index marks (red grooves) on the • For the ND-58, the upper opening is an “O” die. toggle link and frame line up. • For both the ND-58 and ND-60 tools, the lower opening is a “D...
- Page 4 500 2151.6 Kit, screw-set; includes one of items 16, 17 U.S. TECHNICAL SUPPORT 1-800-776-9775 Ilsco Corporation • 4730 Madison Road, Cincinnati, Ohio 45227-1426 Phone (800) 776-9775, (513) 533-6200 • Fax (513) 871-4084 E-mail: sales@ilsco.com • Web site: http://www.ilsco.com Printed in the USA Ilsco Corporation 4730 Madison Rd.
