Summary of Contents for Spod SourceLT
- Page 1 GET TO KNOW...
- Page 2 COMPONENTS Positive battery cable connection Negative battery cable connection Accessories terminal block for switches 4-6 DIP switch for pairing Bluetooth (see page 3) Jumper for low voltage bypass (see page 2) Controller input 2AMP fuse for harness/circuit board protection Accessories terminal block for switches 1-3 Thumb screw for fastening lid Place holders for switch ID labels (legends)
- Page 3 INSTALLATION Find a dry, clean, easily accessible, at surface to mount the SourceLT that is within reach of the provided battery cables. Mount the SourceLT using the provided hardware. Run control cable through the rewall of the cab. Keep protective cap on during the process.
- Page 4 With the app closed and o , ip DIP switch ON then OFF in quick succession to put the SourceLT in PAIRING MODE for 60 seconds. Open the app and touch Setup. Touch the Scan button and wait 10 seconds.
- Page 5 5.38” W x 5.38” L x 1.34” D 6 circuits rated at 30 amps at 12.5 VDC per circuit 12-position terminal block (easily attach accessories) Controller cable (10 foot) for simple plug-n-play connectivity to the switch controller Integrated low voltage cuto (LVCO) battery protection w/ optional override Self-healing fault protection system (from 1.5 to 30amps) Current-sensing MOSFETs controlled by a microprocessor (no fuses &...
- Page 6 INSTRUCTIONAL VIDEOS ALSO AVAILABLE ON OUR WEBSITE...
