Phone +31 (0)36 53 94 570
SOUND PROJECTS
Karperweg 16
1317 SN Almere
The Netherlands
Fax +31 (0)36 53 00 578
Advertisement
Table of Contents
Summary of Contents for Sound Projects SPX Series
- Page 1 S O U N D P R O J E C T S ™ ™ SOUND PROJECTS Karperweg 16 1317 SN Almere The Netherlands Phone +31 (0)36 53 94 570 Fax +31 (0)36 53 00 578...
-
Page 2: Table Of Contents
GUIDELINE TO MAXIMUM AMOUNT OF CABINETS ..........15 DECLARATION OF CONFORMITY ................. 16 All the important notes regarding proper operation of the product and potential danger or damage to either the user or the equipment, are highlighted in light grey - 1 - Product info SPX Series... -
Page 3: Line-Array Basics
Line-array basics What is a line-array? A line-array is a sound system made up out of a group of identical, omni-directional radiating elements oriented in a tightly spaced, straight line. If this line is long enough compared to the wavelength the elements behave acoustically as if it were a single source. The basics of this principle are employed in today‘s vertical line-array systems. -
Page 4: Basic Set-Up Principles
In addition, the ear cannot resolve tightly spaced comb filtering notches at higher frequencies throughout the overlap region. - 2 - Product info SPX Series... -
Page 5: Quick Reference Set-Up Guide
SPX flying system components SPX Mounting Bracket for single cabinet use SPX Basic Flyingframe for use up to 6 cabinets SPX Flyingframe Extender For use up to 6 cabinets – configuration dependant - 3 - Product info SPX Series... - Page 6 15 when preparing the design of an SPX line-array using the SPX flying frame with the flying frame extender. SPX Connector (2 per cabinet) Cabinet interconnect Quick Release Pin (8 per cabinet) Connector fixes - 4 - Product info SPX Series...
-
Page 7: Using The Spx Mounting Bracket
10 or 15 degrees downwards. Step 3 ONLY applicable when using two or more fixing holes! Connect a second cabinet by means of two connector plates and 8 quick release pins. - 5 - Product info SPX Series... - Page 8 SPX-65 on a tripod using the SPX Mounting bracket Safety Note: For direct fixes to walls or ceilings ALWAYS use two or more fixtures suitable for the applicable underground! Consult local rigging legislation regarding overhead suspension. - 6 - Product info SPX Series...
-
Page 9: Simple Steps To Rig Your Spx Array
Lift the frame and cabinet to approximately head-high position to enable attachment of the next cabinet. Start with attaching the two connectors at the cabinet in the array using the Quick Release Pins. - 7 - Product info SPX Series... - Page 10 2 thru 4 for all cabinets in the array. Step 5 Connect audio and power cables and lift the SPX array to the desired height. Guide the cables and fix them to avoid extensive pulling forces at the connectors. - 8 - Product info SPX Series...
-
Page 11: Setup Examples
Setup examples Typical system setup consisting of 3 SPX-65s, 1 SPX-60 (downfill), 2 SP210s and 4 SP18s - 9 - Product info SPX Series... -
Page 12: Ground-Stacking An Spx Array
The latter is explained below. Step 1 Pre-assembly the array of cabinets on the floor with the angles between cabinets as needed. Step 2 Attach the flying frame including extender at the intended angel. - 10 - Product info SPX Series... - Page 13 Note: the maximum amount of cabinets is largely depending on local circumstances such as ground-stability, weather influences (e.g. wind) and array shape. Always check groundstack stability physically and if necessary grant stability using stabilizing lines. - 11 - Product info SPX Series...
-
Page 14: Groundstacking On Top Of Bassbins
When making a ground stack on top of a bassbin cluster it is highly recommended to use fixing connectors between the bassbin and the SPX flying frame. Typical groundstack setup consisting of 3 SPX-65s and 2 SP18s - 12 - Product info SPX Series... -
Page 15: Additional Safety Guidelines
Approval testing by Certified Body every two years. (Official agency) Like any high performance tool your Sound Projects system needs regular maintenance. Check all bolts and nuts of your audio systems at least once a year! Clean fan-grill, foam-grill and cabinet openings with vacuum cleaner and compressed air to remove excessive dust. -
Page 16: Spx Specsheet
IEC XLR-3 in/out Main connectors: powercon in, powercon out Max. operating temp.: -10 to 40 C ambient Weight: 32kg 32kg 32kg Additional information about SPX Series can be found on our website: www.soundprojects.com - 14 - Product info SPX Series... -
Page 17: Guideline To Maximum Amount Of Cabinets
Guideline to maximum amount of cabinets *Flying frame should be positioned horizontally ALWAYS consult Sound Projects’ proprietary acoustic prediction software SPArC™ (downloadable at www.soundprojects.com) to determine the maximum amount of cabinets at specific situations. The angle of the flying frame influences the forces on the flying hardware. -
Page 18: Declaration Of Conformity
Declaration of Conformity Almere, 1 October 2010 SOUND PROJECTS, hereafter referred to as the manufacturer, declares that the SPX rigging system and its rigging hardware as supplied by the manufacturer are produced and, when provided with certificate, tested conform CE norms as described in the Guidelines for Machinery appendix 2A.
