- Page 1 USER MANUAL HPC312 – HPC324 Please read this manually carefully before using the system and hold on to it for future reference. www.hpc-hydraulics.com...
- Page 3 HPC Hydraulics be liable for any direct or indirect damage resulting from the use or inability to use this documentation or this product. HPC Hydraulics reserves the right to, at any time without prior or direct notification to the customer, to change parts of the product.
-
Page 4: General Safety Measures
GENERAL SAFETY MEASURES • Do not work under the vehicle when it is standing on jacks. • Always ensure that the vehicle is blocked and unable to move before operating the hydraulic levelling system. • If present, shut off the air suspension system, but do ensure that air remains in the bellows to prevent damage. -
Page 5: Levelling Safety Measures
LEVELLING SAFETY MEASURES • Park the vehicle on a surface that is as flat as possible. • Check if the surface on which the jacks will rest is preferably flat, not slippery, and free of debris, rocks, etc. • When parking on a soft surface, plates or blocks must be used under the bases of the jacks, to prevent the supports sinking into the ground. -
Page 6: Table Of Contents
TABLE OF CONTENTS GENERAL SAFETY MEASURES ..................................... 4 LEVELLING SAFETY MEASURES ................................... 5 OPERATION ......................................7 GENERAL INFORMATION ................................7 START-UP ..................................... 8 LANGUAGE SETTINGS ................................... 9 LEVELING FUNCTIONS .................................. 9 MANUAL AND AUTOMATIC CONTROLS ............................. 10 CHANGING AUTOLEVEL 1 EN AUTOLEVEL 2 ..........................12 ADDITIONAL OPTIONS ................................... -
Page 7: Operation
OPERATION GENERAL INFORMATION... -
Page 8: Start-Up
START-UP When the system is started, the HPC logo will be displayed. The screen will go into standby mode if it is not used for about a minute. By touching the screen, it will turn on again. Tap the red lock until it turns green. The left screen will appear. -
Page 9: Language Settings
LANGUAGE SETTINGS Usually the right language is preprogrammed. If this is not the case or if it needs to be changed, this can be done via the main menu. Select the following symbol as shown in the left image. A screen with different flags will appear. The highlighted flag is the language that is currently set. Select the desired flag;... -
Page 10: Manual And Automatic Controls
MANUAL AND AUTOMATIC CONTROLS In the main screen, press [Leveling]. A new option will appear. Select [Manual] and the screen below will appear. The jacks are controlled in pairs, Left, Right, Front, and Back. Select the side to be controlled by pressing the letter. - Page 11 During automatic levelling, the function can always be interrupted by pressing the STOP button. When the jacks have not yet reached the ground, the levelling function can be resumed. If the jacks touch the ground, they will first have to be retracted before starting levelling again. Auto lvl 1 has a visual level when the function is engaged.
-
Page 12: Changing Autolevel 1 En Autolevel 2
CHANGING AUTOLEVEL 1 EN AUTOLEVEL 2 The programmed level value can be changed, if it does not meet the requirements. Please note, HPC- Hydraulics and the dealer are not responsible for injuries, damage, etc. caused by values changed by the user. Manually set the vehicle to the desired position. -
Page 13: Additional Options
ADDITIONAL OPTIONS OPERATING SLIDE-OUTS In order to operate the slide-outs, you must select [Extras] in the main screen. A screen will appear with one or more active slide-outs. In order to operate the slide-out, it must first be selected. Please note that when using an Air Seal, a red, orange, or green button will be displayed in the top right corner. -
Page 14: Hpc App Installation And Operation
HPC APP INSTALLATION AND OPERATION Wireless controls for the levelling system are possible via Bluetooth in combination with the HPC Hydraulics app. It is available for iOS and Android. iOS – installation Download the HPC app in the App Store. Click on the icon as shown to the right. - Page 15 The phone must now first be interfaced with the HPC control panel. Check if Bluetooth has been activated on the phone or tablet. Open the App. A warning will first appear. Accept this message. The app will automatically use the language the phone is set to. If this language is not available, the language is automatically set to English.
- Page 16 When the app has launched, the main screen will appear with two options: Leveling and Extras. Leveling shows all the options that are also available on the control panel. For slide-outs and to change settings, select Options. With the exception of manual operation, a screen will appear showing a cross. The system can be ...
-
Page 17: Maintenance
MAINTENANCE The oil level has to be checked regularly. The system is closed. Without leaks, the oil level will not change much. Ensure that the oil level is checked when the jacks are fully retracted. The maximum oil level is shown below. The system is filled with HPC-extreme ZH-M oil. -
Page 18: Jacks
JACKS Remove any sand, snow, ice, mud, and/or other contamination. This impedes the operation of the system. Protect the piston rods periodically with a silicone lubricant. If the supports have been extended for a longer period of time, it may be necessary to re-lubricate the piston rods when stored. Protect the jacks, jack holders, and hose connections with a wax coating. -
Page 19: Emergency Controls
EMERGENCY CONTROLS In the event of an electrical malfunction, the system can always be easily operated manually, without tools. Note that the correct procedures are followed for retracting or deploying the jacks. Retracting the jacks • Open the 4 valves by manually turning them anticlockwise. •... -
Page 20: Troubleshoot
TROUBLESHOOT Cause Solution Description The control panel will not turn on No power Turn on the vehicle's ignition Check the wiring Check the connectors The system stops while levelling. Too low power Start the vehicle Charge the battery Replace the battery The system is controlling the Hoses connected incorrectly Connect the right jacks... -
Page 21: Dealer Information
DEALER INFORMATION To facilitate maintenance and repair, it is easy for the company that will work with it to know where important components are located. For this we would like to ask the company that does the mounting to fill in the list below. Also fill in the information on the next page, so that the customer knows who to contact with questions or problems. -
Page 22: Service And Maintenance
SERVICE AND MAINTENANCE Company name: Phone number: Date Discription of the activities Signature... - Page 23 Edisonstraat 18-20 7575 AT Oldenzaal +31(0) 541-222 444...
