THE FIRST SYSTEM
FOR THE AUTOMATED
AND UNATTENDED
SANITIZATION
BLOCKCHAIN
CERTIFIED
SAFETY WARNINGS
IMPORTANT PRECAUTIONS FOR USE
WARNING! BEFORE USING THE APPLIANCE,
CAREFULLY READ ALL THE INSTRUCTIONS AND
WARNINGS IN THIS MANUAL.
Simple Group AG declines all liability for any accident deriving from any improper use of this appliance.
Correct use of the product is only as detailed in this instruction manual.
Any use which does not comply with these instructions will invalidate the warranty.
SHOULD THE PACKAGING SHOW SIGNS OF DAMAGE PLEASE CONTACT THE MANUFACTURER OR THE AFTER SALES LOCAL
SERVICE IN ORDER TO LET THEM CHECK IF THE PRODUCT HAS BEEN DAMAGED BEFORE USING THE PRODUCT.
ATTENTION: MAKE SURE THAT NO OBSTACLES OR WALLS WILL BE IN FRONT OF H-FOG AT A DISTANCE IF LESS THAN 4 ME-
TERS AND THAT HUMIDITY LEVEL WILL BE LOWER THAN 45%.
SAFETY SYMBOLS:
WARNING: High temperature. Risk of scalding!
If shown on the product, do not touch as parts may be very hot.
WARNING: Steam.
Risk of scalding!
This appliance reaches very high temperatures. Incorrect use of the device can cause scalding.
• Never disassemble or carry out maintenance on the appliance apart from that indicated in this manual. In the
event of a fault or malfunction, do not try and repair the appliance yourself. Incorrect use or a lack of respect for the
instructions herein may lead to serious accidents. Always contact Authorised Service Centres.
• This appliance must not be used if it has been dropped, if there are visible signs of damage or if it leaks.
• The plug must be removed from the socket before the appliance is for maintenance or reparations.
• This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and under-
stand the hazards involved. Children should be supervised to ensure that they do not play with the appliance.
QUICK INSTALLATION GUIDE
Rel. 01_05-2021
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-Fog and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Simple H-Fog

Summary of Contents for Simple H-Fog

  • Page 1 SERVICE IN ORDER TO LET THEM CHECK IF THE PRODUCT HAS BEEN DAMAGED BEFORE USING THE PRODUCT. ATTENTION: MAKE SURE THAT NO OBSTACLES OR WALLS WILL BE IN FRONT OF H-FOG AT A DISTANCE IF LESS THAN 4 ME- TERS AND THAT HUMIDITY LEVEL WILL BE LOWER THAN 45%.
  • Page 2 • Keep all the parts of the packaging out of the reach of children; they are not toys. Keep the plastic bag out of the reach of children: danger of suffocation. • This appliance is destined exclusively for indoor domestic use, with a maximum volume indicated in the H-FOG con- trolling APP.

  • Page 3: Installation

    INSTALLATION ATTENTION: Installation of the Device has to be performed by Authorized Installers. OPENING H-FOG To install H-Fog on the wall it is nec- essary to Open it and separate the BODY/FRONT PANEL from the BACK PANEL. Insert the metallic tool in the small flat SLOT, push on the left side and pull the Drawer out.

  • Page 4: Mounting The Bracket

    110 centimeters there will be a power socket available to plug in the H-Fog device. The bracket has to be fixed with 6 Screws / and correspond- ing wall fixing expanders units supplied by drilling the holes on the wall with a Drill BIT with 6mm diameter.
  • Page 5 Step 3: Mount the BODY with the Glass Front Panel on the H-Fog Back Panel guides on the top side of the product and then LOCK it with the two Plastic guides. Let the Power Cord come out from the hole on the right bottom side of the BODY.
  • Page 6 CONFIGURATION H-Fog must to be configured in order to inject the quantity of disinfecting liquid into the air. From the H-Fog APP the volume of the room when H-Fog is installed was to be defined by filling the following info:...
  • Page 7 (60 minutes after the start of the treatment). Follow the step by step instructions on the H-Fog APP or on the H-Fog Portal to properly run a Sanitization Treat- ment. ATTENTION: until the status “NO EN- TRY”...

  • Page 8: Information For Users

    With reference to the H-Fog Smart Bags containing Disinfecting Liquid, such products have to be sent to authroized disposal plants or incineration under controlled conditions. In so doing, comply with the local and national regulations currently in force.
