SereneLife SLGT15 User

SereneLife SLGT15 User

15.6'' graphics tablet monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

SLGT15
15.6'' Graphics Tablet Monitor
Full-Laminated Technology Drawing Monitor with Buttons,
Wireless Passive Pen and Pen Holder

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SLGT15 and is the answer not in the manual?

Questions and answers

silver
April 18, 2025

where is the software download

1

Summary of Contents for SereneLife SLGT15

  • Page 1 SLGT15 15.6'' Graphics Tablet Monitor Full-Laminated Technology Drawing Monitor with Buttons, Wireless Passive Pen and Pen Holder...

  • Page 2: Table Of Contents

    Apple and Mac OS are either registered trademarks or trademarks of Apple Corporation in United States and/or other countries. Any additional company and product name mentioned in this documentation may be registered trademarks or trademarks. CONTENTS I. General Information INSTALLATION ON WINDOWS INSTALLATION ON MAC II.

  • Page 3: General Information

    I. General Information OVERVIEW Discover how simple and innovative it is to control your computer using our Pen and LCD Pen Display in place of your mouse or track pad. The Monet Pen functions very similar to an art pen, being able to draw a line very thin or thick, light or dark.
  • Page 4 VERIFYING HARDWARE Your Drawing Tablet and its packaged contents are shown below. If anything is missing, contact your dealer immediately. *P08 Battery-free Pen *Pen Nib Remover *Pen Nibs (3 hard, 3 soft) LCD Display Power cable Power adapter USB cable HDMI cable SETUP 1.

  • Page 5: Installation On Windows

    2. Insert USB end of cable with safety lock into pen display. Insert USB end into computer. 3. Insert HDMI end of cable into pen display. Insert HDMI end into computer. 4. If pen display does not turn on right away, press the power button on the side of your pen display.
  • Page 6 3. When installing the driver, follow the installation instructions on your screen. Press Ok. 4. After the installation has completed, reboot your computer. 5. After you have nished the driver installation and restarted your computer. If the device has been successfully installed, you will see a small Tablet icon appear in the system tray, which is normally located at the lower right-hand corner of the screen.
  • Page 7 USAGE TIPS Double Tapping To double tap with the Monet Pen (equivalent to a double click with a mouse), quickly lift the pen tip up away from the pen display before returning for the second tap. Scrolling Function of Digital Pen To scroll on a page, press the rst button on the Monet Pen (same function as the mouse middle button) over the pen display.
  • Page 8 2. In Multiple Displays dropdown, change to (Extend these displays). 3. If your computer is equipped with more than one monitor, your Tablet pen display will map to the monitors based on how they are con gured in the DISPLAY PROPERTIES control panel. 4.
  • Page 9 Display Con guration (for Windows) You may con gure your Tablet Pen Display by modifying the functions of the pen tip and the two side buttons. • Tap on the Tablet icon in the system tray, usually located at lower right-hand corner of the screen.

  • Page 10: Installation On Mac

    INSTALLATION ON MAC 1. Download the driver from website 2. Go to Downloads at the top right-hand corner, or your Downloads folder in Finder. 3. Select the Tablet Driver package (decompress if needed) and follow the installation instructions shown on screen. 4.
  • Page 11 Scrolling Function of Digital Pen To scroll on a page, press the rst button on the Monet Pen (same function as the mouse middle button) over the Pen display. If you have customized your Monet Pen, you must reset the button to Middle Button in the Pen driver Pen settings in order to use this function.
  • Page 12 2. With the Pen LCD Display connected, in Displays go to Arrangement. Here you can rearrange how displays are mapped to each other. How to Change to Mirror Display 3. In Arrangement, at the bottom left-hand of the window, select Mirror Displays if you want your main computer monitor and your Pen LCD Display to show the same image.

  • Page 13: Hotkeys

    Devices The Devices tab shows the device currently in use and the driver version being run. Note: If nothing is shown in Device Information, make sure your Tablet pen display is properly connected to your computer. Unplug and re-plug if problem still persists. If the issue still persists, restart your computer.

  • Page 14: Scroll Dial

    Custom De ne: At the bottom of the dropdown menu, choose Custom. This will allow you to input a custom keyboard shortcut. Note: Software keystrokes are based on English input methods. If not already, set to English when using HotKeys on your Tablet pen display. Note: Most creative software will not accept keystroke inputs when you Monet Pen is still in use or when your Monet Pen is still within the detectable cursor range.

  • Page 15: Pen

    Pen Button Settings: Customize the functions of the two side buttons on the Monet Pen. Click the button name and choose a function from the dropdown menu. Double Click Speed: Move the slider toward “Slow” if you want more time in- between double tapping the pen tip.

  • Page 16: Calibration

    Pen Pressure: Using the Monet Pen, press down in the white rectangle. Use di erent levels of pressure to test if pen pressure sensitivity is working on your computer. Note: Please close the Tablet Control Panel when nished with the Pressure test. Monitor: If working in Extended Display, choose which monitor you want your Tablet pen display to track with.
  • Page 17 Open Monitor Tuner: Monitor Tuner can help you con gure the pen display’s Brightness, Contrast, and Color Temperatures. Press “Open Monitor Tuner” to open “Tablet Monitor Tuner” utility Calibrate Display Options: These options are there to assist you with preparing your designs for CMYK printing.

  • Page 18: Save & Backup

    Note: The “Calibrated Pen Displays” are only there to assist you, to prepare your work for best accuracy before CMYK printing. Refer to guidelines set by your printing services. Note: When opening pen Monitor Tuner, the system will need up to 30 seconds or more to access the necessary information for your monitor.

  • Page 19: Change The Pen Tip

    III. CHANGE THE PEN TIP 1. You will need the pen nib removal tool . 2. Use the pen nib removal tool to pull out the pen nib. 3. Push the new pen tip into tip into the Monet Pen. IV.

  • Page 20: Settings For Graphic Applications

    V. SETTINGS FOR GRAPHIC APPLICATIONS Some applications need their settings changed so the pen display can act just the way you like. A. SAI a. Find [misc.ini] in SAI folder. b. Right click on [misc.ini] and select “Edit. ” c. Find Tablet > Mouse > Simulation = 0, then modify 0 to 1 and save the le. d.
  • Page 21 D. Clip Studio Paint a. Run Clip Studio Paint and press Ctrl + K to open [Preferences]. b. Select “Tablet. ” c. In “Using tablet services” select Tablet PC. d. Press OK and restart Clip Studio www.SereneLifeHome.com...
  • Page 22 Questions? Issues? We are here to help! Phone: (1) 718-535-1800 Email: support@pyleusa.com...
