GSL electronics UPS240-1210 Operating Instructions

Model:
UPS240-1210
Page 1 of 2
The unit is for bench mounted operation providing approx. 13.65VDC at 10Amps. An output mating connector kit is provided
with each unit. The unit has been designed specifically for telecommunications applications demanding high reliability under
heavy usage with low noise, fully automatic and unattended operation.

Applications:

Power Supply Mode: It may be used to power equipment that normally runs on a 12 Volt battery e.g. mobile
communication equipment. The unit will run loads requiring up to 10 Amp output. It is fully protected against overload and
short circuit and also incorporates overvoltage shut down facility.
Battery Charger Mode: As a lead acid battery charger it will provide a safe method of restoring discharged batteries. When
batteries are heavily discharged the unit can provide 10 Amps continuous charging current. Fully charged batteries can be
left connected to the unit indefinitely with no adverse effect on the lifetime of the batteries. An internal self resettable fuse is
incorporated in the battery output. Faulty and heavily discharged batteries will not damage the power supply.
UPS Mode: The full features of the unit are utilised when both battery and load are connected so that it operates as a power
supply with power fail protection. Under normal conditions an internal switch connects the battery in parallel with the load.
The average load must be less than 10 Amps to ensure there is a remainder (current) available to float charge the battery.
When mains failure occurs the unit no longer provides power. The battery remains switched in parallel with the load and
supports it without interruption. Restoration of the mains restarts the unit which will resume supporting the load and charging
the battery again without interruption.
During extended mains failure the unit disconnects the battery before it becomes excessively discharged. The battery
is automatically reconnected when mains power is restored enabling a quick charge to a workable voltage. This feature
contributes to long battery lifetime and allows unattended operation of a system with minimum service calls. The battery is
always being charged while mains are present. A heavily discharged battery will pull the unit into current limit and therefore
reduce the voltage supplied at load terminals. For batteries in good condition that have been protected from deep discharge
voltage should never be less than 10 Volts.
Installation & Safety Precautions:
1. This appliance is not meant for use by young children or infirm persons without supervision.
2. Young children should be supervised to ensure that they do not play with the appliance.
3. During charging process, do not use a naked flame near a battery, due to gases emitted from the battery, which may
ignite and explode.
4. Never smoke or light cigarettes near a battery.
5. Do not place tools on top of battery or allow tools to fall on battery.
6. Always wear eye protection near a charging battery.
7. Ensure a "well" ventilated area is used when testing or re-charging batteries.
8. Ensure ventilation is adequate and venting holes are not obstructed. Inadequate ventilation may over-heat the unit and
cause inefficient operation.
9. The UPS is intended for indoor use only. Do not expose it to extreme weather conditions e.g. rain or dampness.
10. If skin or clothing comes into contact with acid, flush the area(s) with water immediately. Seek medical attention if
necessary.
11. Use only 12V lead acid batteries never attempt to use non rechargeable batteries.
12. The UPS contains hazardous voltages. There are no user serviceable components inside. If the AC supply cord is
damaged, in order to avoid a hazard it must be replaced by the manufacturer or its service agent or a similarly
qualified person.
12 Volt 10 Amp Switchmode
Uninterruptable Power Supply
Please read these instructions before use
Should product require service, return it to place of purchase.
Unit 2, 110 Station Road, Seven Hills ,NSW, 2147, Australia
More information https://www.caravansplus.com.au
Operating Instructions
RPS12-R1
