Grimm ENVIRON CHECK 180 Manual

Mobile dust monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Manual
Mobile Dust Monitor
ENVIRON CHECK 180
GRIMM Aerosol Technik
GmbH & Co. KG
Dorfstrasse 9, D-83404 Ainring, Germany
Tel: 0049-8654-578-0
Fax: 0049-86540-578-35
E-Mail: sales@grimm-aerosol.com
www.grimm-aerosol.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENVIRON CHECK 180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Grimm ENVIRON CHECK 180

  • Page 1 Manual Mobile Dust Monitor ENVIRON CHECK 180 GRIMM Aerosol Technik GmbH & Co. KG Dorfstrasse 9, D-83404 Ainring, Germany Tel: 0049-8654-578-0 Fax: 0049-86540-578-35 E-Mail: sales@grimm-aerosol.com www.grimm-aerosol.com...
  • Page 2 Manual EDM 180 Revision 1.0 29.03.2010 Page 2/61...
  • Page 3 Manual EDM 180 Index INDEX 1 GENERAL ..........................6 NNOTATION ....................7 EANING OF THE USED SYMBOLS 2 IMPORTANT HINTS FOR THE CUSTOMER ......................8 AFETY REGULATIONS ........................9 LECTRIC AFETY .......................... 9 ASER SAFETY ........................10 RANSPORTATION ....................11 XTREME AMBIENT CONDITIONS 186 ..........................
  • Page 4 LLUSTRATION OF THE MEASURED VALUES 6 HYPERTERMINAL VIA RS-232 INTERFACE ........................39 YPER ERMINAL ....................42 ORK WITH YPER ERMINAL 7 SWITCHING POSSIBILITIES OF THE GRIMM 190 ....................46 ITH A TERMINAL PROGRAM GRIMM 1177 3.30 ..............47 SOFTWARE VERSION 8 RS-232 INTERFACE RS-232 ........................
  • Page 5 Manual EDM 180 12.1 S 187 ....... 65 AMPLE AIR DUCT INSIDE THE OPTICAL CHAMBER OF THE SPECTROMETER 12.2 F 182 ................... 65 LY SCREEN ON THE SAMPLE PIPE 12.3 C ......................65 HANGE DUST FILTER 12.4 I ....................65 NTERNAL RINSING AIR FILTER 13 ACCESSORY 13.1 S...
  • Page 6 Grimm Aerosol Technik moreover is not responsible for damages, which result from patent infringement or abuse of a third's party rights.
  • Page 7 Manual EDM 180 We reserve the right to change or improve the instruments described in this manual without previous announcement, simply in accordance to the technical progress. Therefore insignificant deviations between the descriptions in this instruction and your measuring instrument are possible. 1.2 Meaning of the used symbols In this manual following symbols will be used in order to ease locating important hints, advices, and situations.

  • Page 8: Safety Regulations

    Manual EDM 180 Important hints for the customer 2.1 Safety regulations The manufacturer declines any direct or indirect liability if the operator opens the instrument or manipulates the instrument! This instrument is built and tested in accordance with EN-61010 (DIN VDE 0411 T1) to assure proper protection of the electronic material and measurement function of the instruments.

  • Page 9: Electric Safety

    Caution! Optical laser class 3 B inside! The instrument may only be opened by GRIMM trained service personnel. During the opening of the laser unit, especially the measuring chamber, a laser radiation of the class 3 B can be released. The direct look into the laser beam or a reflexion can lead to damage of the eyes even at a short exposure time.
  • Page 10 Manual EDM 180 All stickers shown are on the bottom of the instrument and warn the operator for laser light radiation in case the covers of the instrument have been dismounted! Laser class 1 in closed state of the measurement unit! Laser of class 1 are not dangerous and safe for eyes even in case of malfunction due to manipulation or usage of optical additives (e.g.
  • Page 11 Manual EDM 180 2.5 Extreme ambient conditions Altitude correction The pressure altitude formula describes the vertical distribution of the (gaseous) particles in the Earth´s atmosphere, means the change of the barometric pressure related to height. This is also called the vertical pressure gradient.
  • Page 12 The external probe head heating model 180-DF is an accessory for the Enviro product line of the company GRIMM (165, 365, 180, 190, 565). It keeps the probe head ice free when having frost and thus enables failure-free measurements. The heating heats up to a maximum of 10°C.
  • Page 13 EDM 180 2.6 Test kit 186 The EDM Test kit model Nr. 186 is an accessory part for the Enviro product line of the company Grimm (165, 365, 180, 190, 565). It controls the correct installation and function of the systems.

  • Page 14: Sample Head

    Manual EDM 180 EDM 180 3.1 Introduction The measuring device for airborne dust of the series 180 is a stationary instrument which has been designed for the continuous measurement of airborne dust and its particle size distribution. The measured values will be output as mass concentration in the unit μg/m³ and distinguished according the fractions PM10, PM2.5, and PM1.
  • Page 15 Figure 2: Measuring principle All Grimm laser aerosol spectrometers and dust monitors use a laser diode as light source. The wavelength is for model 365 in visible range at 655 nm. The laser diode can be operated in a so- called Multiplex Mode, i.e.
  • Page 16 Manual EDM 180 The count rate results from the number of particles divided by volume flow rate. The particle size is proportional to the intensity of the detected scattering light signal whereas the scattering light intensity is also being influenced by the particles refractive index, particle shape, and orientation of the particle within the measuring volume.
  • Page 17 PSL samples and so validates the particle size measurement for this standard material. The first Grimm mother device, sort of “grandmother”, moreover was being compared to a reference device, viz. the laser aerosol spectrometer model LAS-X by PMS, Boulder, Colorado. By this procedure we ensure the correct particle size measurement in the specified channel, e.g.
  • Page 18 EDM 180 Grimm Calibration procedure The calibration between a candidate and the mother unit is done by use of a "Grimm Calibration Tower" that isfully computer-controlled and -automated and poly disperse dolomite dust as a standard aerosol. Why dolomite dust? Dolomite dust is cheap, anoxic, not hygroscopic, poly disperse and very stable during storage.
  • Page 19 After the tower calibration, a further comparison at indoor conditions is done. To illustrate the described procedure, the following two screenshots, so called "ramp" from the Grimm calibration software CalSoft, show two examples of a measured particle number concentration of a candidate compared to a reference unit before and after a calibration.
  • Page 20 Manual EDM 180 Figure 3: After calibration: Simultaneously measured particle number concentration for all 31 size channels of the candidate (red) and the mother unit (blue) vs. time At all enviro products (107, 180, 365) a continuous test of the complete system follows with an own sample probe and housing.
  • Page 21 Manual EDM 180 3.5 Gas flow concept Figure 3: Flow-Schema 3.6 Drying The air humidity and the ambient temperature are being measured by the sensor 1.153 FH. Is the relative air humidity above 55%, then the dryer circuit automatically switches on. The sample air flow passes after entering the sample head a nafion membrane.
  • Page 22 Testkit 1.142.M5 Data logger Source of supply Accessory, consumables and spare parts can be ordered at your local dealer or at GRIMM Aerosol Technik GmbH & Co. KG Dorfstrasse 9 83404 Ainring Tel.: +49 (0) 8654-578-0 Revision 1.0 29.03.2010 Page 22/61...
  • Page 23 Manual EDM 180 3.8 Specifications EDM 180 Measuring principle 90° scattering light measurement Light source Semi-conductive laser, wave length 660 nm Laser power Pmax 60 mW, normal 0.5/32mW (Multiplex) Opening angle 30 ° Sample volume flow 1.2 l/min ± 5 % constant through control Rinsing air flow 0.3 –...
  • Page 24 Manual EDM 180 Analog inputs: 3 inputs (0-10V), resolution 10 Bit (ca. 10 mV). Display with adjustable factors and offsets, selectable and editable texts Data storage card: 1MB - 4MB SRAM, battery buffered. Selectable interval 6 seconds to 60 minutes. Data: date, time measurement location number, error code, magnetic valve current, sensor data and analog voltages Power supply:...

  • Page 25: Calibration Label

    (CTS or DTS) by the terminal program. Figure 4: Pin alignment of the socket at the dust monitor „RS-232 to PC“ Only use the original GRIMM data cable due to the alarm output at the 9 pin RS-232 Subminiatur- socket! 3.10 Calibration label...

  • Page 26: Control Elements

    Manual EDM 180 Control elements Read this manual carefully BEFORE taking the device into operation! Please inspect every single part of the measurement unit after unpacking. If you expect that the device cannot be run safely anymore put it out of operation and ensure it cannot be run accidentally anymore. Expect a not safe operation, if •...

  • Page 27: On/Off Switch

    Manual EDM 180 4.3 On / Off switch With the main switch (Power – lower left side of the front panel) the device is being switched on or off. Do not switch off the unit out during operation- (measurement-) mode but first enter stand-by-mode (press key Stand-by).
  • Page 28 Manual EDM 180 4.5 Key pad Between operation- and stand-by-mode a partly different reaction of the device due to the handling of the keys might occur. Your entry will be confirmed by a short signal tone. Figure 5: Key pad spectrometer 4.6 Key functions –...
  • Page 29 Manual EDM 180 Keys functions within operation mode Displays the averages of the dust concentration of all valued measurements (PM10, PM2.5, PM1) after switching on the device or deleting the averages with the related sample volume. The averages related sample volume appears after approximately 5 Mean/Weight seconds and remains displayed as long as the key is being pressed.
  • Page 30 Manual EDM 180 4.8 Key functions within the stand-by mode Like within the measuring mode – with additional resetting of the averages and the average measurement volume by pressing the keys [Mean/Weight] and [-] at the Mean/Weight same time. Press this key to leave the stand-by mode and to begin a new measurement row. Stand-by Additional pressing of the key [+] or [-] enables to choose 2 favored PM-values out of PM Mode...
  • Page 31 Manual EDM 180 Data storage (internal / external) Storage capacity Depending on the device´s setting – means the set interval and the storage card capacity - different storage times will be reached. Only PCMCIA SRAM data storage cards can be used. Data will be stored using the First in First out (circular buffer) method.
  • Page 32 When not using for a longer period of time the battery should be taken out of the device.  The storage card can only be read out either directly on the GRIMM aerosol spectrometer or via an external card reader. Not possible via PC with PCSI card reader.

  • Page 33: Installation

    Manual EDM 180 Measurement Installation The measuring system ENVIRONcheck 180/181 has to be installed in the 19“ rack as the topmost unit. The space needed is 6 HU ( 180: 4HU, 181: 2HU). Erecting the 19” rack please mind, that the sample pipe 182 is to be inserted directly through the ceiling / roof construction into the sample pipe holder 181.
  • Page 34 Manual EDM 180 Installation sample pipe 182 and sample pipe 181 Install the sample pipe holder at the topmost position of the 19” rack. Screws and further mounting parts are not included in the scope of delivery) The temperature/ humidity sensor with carrier (separate delivery) has to be built onto the sample pipe and thread the connection cable through the sample pipe.
  • Page 35 Manual EDM 180 Within the final position the screw must not be visible anymore, but the red dot. Now tighten the safety screw. Revision 1.0 29.03.2010 Page 35/61...
  • Page 36 Manual EDM 180 Installation 180 The slide bars provided by the customer for the 19“ drawer have to be mounted. Subsequently mount the EDM180 and connect it to the power cable. The power cable has to be provided by the customer When tightening the 180 and the sample pipe holder 181 please mind, that the connections of 180 and 181 with the lift have to be...
  • Page 37 Manual EDM 180 Taking the EDM 180 into operation Please choose previous to the measurement how the data shall be gathered and processed (Online data collection via network and storage onto the PCMCIA data storage card / only storage of the data onto the PCMCIA data storage card without online data collection).
  • Page 38 Manual EDM 180 An faultless device shows the message: SelfTest OK, otherwise: New SelfTest. Should this error message appear more than once a device error is present which has to be remedied. The instrument tries five times to execute the self-test successfully, then the message „Fatal Error Please Check!“...

  • Page 39: Hyper Terminal

    HyperTerminal via RS-232 interface 6.1 Hyper Terminal Every GRIMM spectrometer can be operated online via HyperTerminal with the according control commands. HyperTerminal is a text based communication program which is part of Windows (version 2.0 and higher). Windows Vista does not contain HyperTerminal anymore, but can be downloaded from the website of Hilgraeve with costs.
  • Page 40 Manual EDM 180 Press OK Now you have to change the properties of the connection Press OK. Revision 1.0 29.03.2010 Page 40/61...
  • Page 41 Manual EDM 180 Further are following adjustments important: These are properties / adjustments of the connection Revision 1.0 29.03.2010 Page 41/61...
  • Page 42 Manual EDM 180 Work with Hyper Terminal Check the connection with the order “v”. You should see the version of the unit. The sign “?” will show you a help window. Revision 1.0 29.03.2010 Page 42/61...
  • Page 43 Manual EDM 180 With the sign ”|” and then the tabulator key you switch the unit in the service mode. Now you can see a helpful text, like the version date and explanation for the P-LINE after start measurement. Pressing ’r’ will set it running, after a few minutes the screen will look like this The picture shows the data from an environmental DUSTMONITOR 107.

  • Page 44: Data Transfer

    Manual EDM 180 DATA TRANSFER: To download the Data Card and Capture the file you have to be in STANDBY then go to the TRANSFER Menu at the top of the HYPERTERMINAL screen, clicking on it will bring up a SUB Menu, click on CAPTURE TEXT.
  • Page 45 Manual EDM 180 Press START Now type in the command ’d’, than you have to see: Memo card : 8.60 from: 8F050061 Location : 1 : -After enter will read only data of the adjusted location 1 If you want to read out all locations (1-99) you have to press 0 before Enter. - put in another number will read only the data from this number Press Enter and the transfer will start.
  • Page 46 Manual EDM 180 Switching possibilities of the GRIMM 190 With a terminal program Previous to switching the device it has to be within service mode 0. Therefore a terminal program is necessary. Following versions are possible: Version 7.80 PM10, PM 2.5, PM1 in storage, LCD and via the RS.232 interface.
  • Page 47 Manual EDM 180 With GRIMM software 1177 version 3.30 For use both version with GRIMM software it is necessary to load both drivers and activate one of them. With OPTION SYSTEM open follow window with EXTRAS SWITCH VERSION it is possible to switch between both versions...

  • Page 48: Transmission Protocol

    Above the socket is an LED which shines green at an established connection. Red signalizes the data transfer. Only use the GRIMM data cable RS-232 with the catalogue number 1.143E. The service socket is treated prior-ranking when the terminal program sets the handshake lines (CTS or DSR) to high.

  • Page 49: Check Filter

    Manual EDM 180 Output of the current alarm value. Changeable within stand-by mode. Output of the battery capacity (always 130%) ASCII-data transmission from the storage card (only within stand-by mode) Location „0“ for all locations Output error code (ERROR). See chart next page. Error- Meaning Solution...
  • Page 50 Manual EDM 180 Switch on fast mode. Measured data will be output every 6 seconds Output gravimetric factor. Within stand-by mode changeable. At the model 365 the gravimetric factor can be changed between 0.5 and 2.5 in steps of 0.01. Output operation hours Interval for the normal output and storage.
  • Page 51 Manual EDM 180 Output filter weight and its according sample volume Output and subsequent resetting of the averages and volume Output model and version number of the device Model 365 Version 7.80 E Output serial number Ser.No. 87F03017 Output calibration factors for the analog input voltages Set baud rate for data transmission: 0 = 9,600 Baud 1 = 19,200 Baud...
  • Page 52 Manual EDM 180 Underline Output of the user texts and analog input factors (only within stand-by mode). Example: The first line shows the three user texts, the second line the three multiplication factors for the analog voltages, and then the offset values. Selection or change of the user texts as well as the factors for analog voltage outputs on the LCD display (only within stand-by mode).
  • Page 53 Manual EDM 180 8.4 RS-232 transmission of measured values The firmware 7.xx outputs the mass concentration values because of its resolution of 0.1 μg/m with the multiplication factor of 10! At each intervals´ end happens the output of the measured values with their according measurement pre-information.
  • Page 54 Manual EDM 180 Within Fast Mode the measured values are being sent every 6 seconds 8.5 Additional information within service mode: CRC sum In order to retrieve additional information the device can be switched into the simple service mode. Therefore send via the terminal program Alt 124 and Alt 09 (TAB) to the dust monitor. Sending the character „!“...

  • Page 55: Service Mode Settings

    Manual EDM 180 8.7 Service mode settings With service mode 0 Outputting the data via the RS-232 interface also additional data and explaining texts will be output. Several control commands are available, e.g. the request for the last service by "~" last Service, or the request for the volume flow by "^F"...
  • Page 56 Manual EDM 180 Special data protocol “GESYTEC“ 9.1 Change of mode from Standard to Gesytec The change from the STANDARD to the Gesytec-mode (which is similar to the German Bayern-Hessen protocol) is only possible via the key pad of the dust monitor. Turn the 365 dust monitor off by pushing the main power switch.
  • Page 57 Manual EDM 180 Setting within normal operation The only extension to this manual affects the additional RS-232 command „:“ which lets you execute the GESYTEC pre-settings. Sending within stand-by mode the character „:“ (ASCII-Code 58) will call up following sub-menu: -- Settings Gesytec -- Kennung Geraet: 250 Serialnumber :...
  • Page 58 Manual EDM 180 GESYTEC Structure RS-232 data transmission within Gesytec mode For 3 parameters ( PM10, PM2.5, PM1 Byte-Nr. Data format Field description <STX> start of text telegram code number of measuring parameters 7-10 nnn# instrument identification 11-19 ±nnnn±ee# value of PM10 in ng/m3 20-22 operational status 23-25...

  • Page 59: Error Status

    Manual EDM 180 86-89 nnn# serial number 90-96 hhhhhh# valve voltage in % 97-100 nnn# instrument identification + 3 101-109 ±nnnn±ee# value of count in particles/litre 110-112 operational status 113-115 error status 116-119 nnn# serial number 120-126 hhhhhh# internal temperature in 1/4°C <ETX>...
  • Page 60 Manual EDM 180 The "ST"-Telegram (ASCII-format): Byte-Nr. Data format Field description <STX> start of text telegram code instrument identification empty space key, ( mostly a letter ) <ETX> end of text <BCC1> block symbol upper nibble <BCC2> block symbol lower nibble The following "ST"-telegrams has been incorporated: "R"...
  • Page 61 Manual EDM 180 10 Sensors 10.1 Analog input The dust monitor has 3 analog inputs at the 6 pin socket. This is located on the inner side of the connection module in the sample holder 181. It can be connected to any suitable analog sensor with an output voltage between 0 and 10 Volts.
  • Page 62 Manual EDM 180 10.4 Weather station Via the optional „one-wire“ connection it is possible to connect additional climatic sensors such as 1. Wind direction 2. Wind speed 3. rain fall. These sensors need additional space on the storgae card and thus decrease the storage times. In order to connect the climatic sensors switch off the device and then simply connect the sensors.

  • Page 63: System Messages

    Manual EDM 180 11 System messages The operation safety of the system is permanently being controlled. If errors occur, the undermentioned status messages can be activated. When exceeding the set alarm treshold of having a device failure such as a defect of the volume flow control, the LCD will show a warning message and a warning signal resounds.
  • Page 64 Manual EDM 180 PLEASE Write protection activated CHECK MEMORAYCARD Memory card contains data from a different device. WRONG SERIAL NO. Ser.No.xxxxxxxx Read out data and then format the card WRONG VERSION! Memory card contains data from a different device. CLEAR MEMORYCARD Read out data and then format the card FATAL ERROR! Self test faulty several times.

  • Page 65: Maintenance And Cleaning

    Manual EDM 180 12 Maintenance and cleaning It is recommended to annually execute following points! 12.1 Sample air duct inside the optical chamber of the spectrometer 187 Switch off the device. Demount sample pipe as well as the glass bottle and then blow the sample air duct with oil-free and clean compressed air with an maximum pressure of 3Bars upwards down.
  • Page 66 Manual EDM 180 13 Accessory 13.1 Sensor for temperature and humidity (model 1.153FH180) This sensor is necessary for the standard cubic meter correction. Size: Diameter 15mm, length 130mm, cable ca. 2m Plug: 6 pin Power supply: 10V +-5% < 5mA Temperature range: -20°...

  • Page 67: Warranty

    GRIMM Aerosol Technik will fix the device at the factory exempt from charges; only the transport fees just as the accordant additional charges are for the customers account. On-site repair will only be done for refunding the travel and service costs.
  • Page 68 Manual EDM 180 g) The buyer just as the seller both agree that this WARRANTY RESTRICTION, which form the claims, and restrictions shall not being questioned. Both parties are registered traders under German Commercial Code. h) In case of a legal action the place of jurisdiction is Traunstein, Germany. Revision 1.0 29.03.2010 Page 68/61...
  • Page 69 15.2 Repair Having knowledge that defect or inactive devices cause disprofit, it is Grimm's politics to care as fast as possible about those customer issues. If an idleness/ breakdown is ascertained, we kindly ask you to immediately contact the next GRIMM selling agency or you local dealer.
  • Page 70 Manual EDM 180 15.3 Dimensions Revision 1.0 29.03.2010 Page 70/61...
  • Page 71 Manual EDM 180 Revision 1.0 29.03.2010 Page 71/61...
  • Page 72 Manual EDM 180 Revision 1.0 29.03.2010 Page 72/61...
  • Page 73 Manual EDM 180 16 Index Analog adapter ..........63 Maintenance and cleaning ......62 Analog input ............ 58 Mass concentration range ....... 23 Analog inputs ............ 24 Measuring chamber ......... 38 Analog voltages ..........49 Measuring principle ........14, 15 Barometer ............
