Precision Products SB4300RD Parts List And Instructions

MADE IN
USA
HOW TO ORDER
REPLACEMENT PARTS:
When ordering parts always
give model number, part
number and part description.
LIMITED WARRANTY
This unit is warranted against defects in materials and workmanship to the original
purchaser, under normal use and service, for a period of ninety (90) days from date
of sale. During the Warranty Period, we will repair or replace at our option free of
charge to the original purchaser, any part of the Unit that our examination shows to
be defective in workmanship or materials. This Warranty Does Not apply to
damage caused by misuse, abuse, neglect, accident, normal wear, or alterations by
unauthorized persons.
PRECISION PRODUCTS, INC.
06/05
S
B4300RD & SB4300RDGY BROADCAST SPREADERS
Parts List and Instructions
1
4
5
9
CUSTOMER SUPPORT
At Precision Products, Inc. delivering quality, value and outstanding service is our goal. However, sometimes parts do
become damaged or lost during transport from our facilities to the store. If you have any problems, please do not return
this merchandise to the store. Call us and we will take care of any problem you may have with this unit.
Phone (800) 225-5891 Ext. 204
Retain for future reference
Send To: Parts Division
Parts referenced with ** have two color options.
316 Limit Street
Lincoln, IL 62656
Phone (800) 225-5891
(217) 735-1590 Ext. 204
FAX (217) 735-2435
www.precisionprodinc.com
2
3
7
6
8
11
10
Ref Parts Description
No
No
1 2564B Axle - 1/2" x 17" (Black)
** 2564G Axle - 1/2" x 17" (Gray)
2 2886 Hopper
3 2887 Leg Stand (Black)
2887G Leg Stand (Gray)
**
4 2888B Handle (Black)
** 2888GY Handle (Gray)
5 2554 Handle Cover
6 2889G Gear Case
2890 Wheel
7
8 2546B Cross Brace (Black)
** 2546G Cross Brace (Gray)
9 2892B Hopper Support (Black)
** 2892G Hopper Support (Gray)
2441 Cable Control
10
11 2614 Spinner Disc
12
13
14
15
17
18 19 20
Qty Ref Parts Description
No
No
1 12 1868 1/4" x 2-1/4" Carriage Bolt
1660
13 1/4" x 1-1/4" Hex Head Bolt
1 14 1042 Hitch Pin Clip
1 15 1060 Split Spacer
1040R Hub Cap
16
1 17 1842 Split Bushing
1270
18 1/4" Hex Head Nut
1 19 2828 Wing Nut
1 20 1053 7/8" Tube Plug
2
1
TIP: Many of these hardware parts can
2
be purchased at your local hard
1
1
3845
16
Qty
7
2
1
2
2
2
6
3
2
