Steiner 75-70709 Parts Manual

Cab for 220 tractor cb220

Hide thumbs

Table Of Contents

Quick Links

MODEL:

75-70709

CAB FOR 220 TRACTOR CB220

Table of Contents

Need help?

Do you have a question about the 75-70709 and is the answer not in the manual?

Questions and answers

Summary of Contents for Steiner 75-70709

Page 1 MODEL: 75-70709 CAB FOR 220 TRACTOR CB220...
Page 2 CALIFORNIA WARNING Proposition 65 Warning The engine exhaust from this product Diesel engine exhaust and some of contains chemicals known to the State its constituents are known to the State of California to cause cancer, birth of California to cause cancer, birth defects or other reproductive harm.
Page 3: Table Of Contents
TURF UNIT IMPORTANT MESSAGE Thank you for purchasing this CGC, Inc. product. You have purchased a world class product, one of the best designed and built anywhere. This product comes with an Owner/Operator's Manual. The useful life and good service you receive from this product depends to a large extent on how well you read and understand this manual.
Page 4: Description / Specifications
DESCRIPTION / SPECIFICATIONS TURF UNIT DESCRIPTION The sturdy CB220 cab is carefully designed to fit the Model 220 2 X 4 TURF UNIT equipped with a ROPS roll bar. It is extremely useful in cold weather when operating a snowblower or a power angle blade. Exceptional features include ease of entry from either side, full glass windshield, back window and lightweight removable doors.
Page 5: Safety
SAFETY TURF UNIT This symbol means: NOTICE !!! ATTENTION! Unauthorized modifications may present extreme BECOME ALERT! safety hazards to operators and bystanders and could also result in product damage. Your safety and the safety of others is involved. Commercial Grounds Care, Inc. strongly warns Signal word definitions against, rejects and disclaims any modifications, The signal words below are used to identify levels of...
Page 6 SAFETY TURF UNIT GENERAL SAFETY 1. Read and understand the Owner’s Manual before attempting to operate this machine. 2. Operate all controls from the operator’s seat. NO RIDERS. 3. Keep all shields in place and safety switches adjusted properly. 4. Do not leave equipment unattended. STOP the engine and remove the key. 5.
Page 7: Installation / Removal
INSTALLATION / REMOVAL TURF UNIT INSTRUCTIONS FOR MOUNTING ASSEMBLED CAB ON 220 TURF UNIT NOTE: Detailed Cab Assembly Instructions are found in the assembly instructions found on Pages 7-16. 1. Turf Unit must be equipped with a roll bar. 2. Remove 3 roll bar mounting bolts on each side where the cab mounts. 3.
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS TURF UNIT 1. Have a ROPS approved roll bar and seat belt mounted to your tractor, using the roll bar instructions. NOTE: Cab mounting uses 3 roll bar mounting bolts A on each side as shown. 2. Disconnect battery. 3.
Page 9 ASSEMBLY INSTRUCTIONS TURF UNIT 7. Install the rear side panels D aligning the 3 bottom holes with the bottom holes of the roll bar. Fasten using the (6) bolts remaining from the roll bar installation. 8. Position the roll bar supports C with the slots at the top of the side panels D and fasten with a 3/8 X 3/4 flange bolt and flange nut.
Page 10 ASSEMBLY INSTRUCTIONS TURF UNIT Line up the post I with the edge of the fender J. Making sure the post is square with the fender, mark and drill (2) 13/32" holes for the 3/8 bolts. 11. Reinstall the front lower panel using the 3/8 flange bolts in the top hole and 5/16 X 1/2 flange bolts in the lower hole.
Page 11 ASSEMBLY INSTRUCTIONS TURF UNIT 12. Cut and place self-adhesive foam strips K on the bottom of the rear window panel as shown. 13. Fasten the rear window panel L to the side panels M using 5/16 X 1/2 flange bolts and nuts N.
Page 12 ASSEMBLY INSTRUCTIONS TURF UNIT 14. Remove top bolts on hood. 15. Mount front window panel to lower front panels using 5/16 X 1/2 flange bolts and nuts. 16. Install trim on filler plate close to front of cab and tractor using trim with bulb on top as shown. Use hood bolts to install plate to hood, to close the space between the cab and the tractor as shown.
Page 13 ASSEMBLY INSTRUCTIONS TURF UNIT 17. Place the roof section down over rear side, rear window panels and front window panel as shown. Fasten with 5/16 X 1/2 flange bolts and nuts. Do not tighten at this time. 18. Mark and drill a 13/32" hole at location P through the remaining hole in the lower front panel and fasten to the fender with a 5/16 X 1/2 bolt.
Page 14 ASSEMBLY INSTRUCTIONS TURF UNIT 21. Now look at the alignment of the assembled cab. With all the bolts still loose you can move the panels to obtain a good fit around the door opening. Adjust door hinges and/or cab. 22. Tighten all bolts at this time. 23.
Page 15 ASSEMBLY INSTRUCTIONS TURF UNIT 24. Mount striker plate R as shown. Adjust striker plate and latch so door will open and close freely. 25. With the door mounted and latched, draw the outline of the door in pencil. This will aid you in installing the weatherstrip along (3) sides of the opening as shown in Photo.
Page 16 ASSEMBLY INSTRUCTIONS TURF UNIT 26. Mount the wiper above the windshield according to the wiper instructions. Check the wiper blade path so that it does not contact the rubber molding. Wiper position should be set at 85 degrees. Refer to the wiper instructions for position adjustment.
Page 17: Parts Section
PARTS SECTION TURF UNIT PARTS SECTION...
Page 18 CAB PARTS (1) TURF UNIT FIGURE 1...
Page 19: Cab Parts (1)
CAB PARTS (1) TURF UNIT FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 62-666 ROOF PANEL 44-113 HEADLINER 4137033 DOOR-RIGHT 4137032 DOOR-LEFT 56-052-102 FOAM WEATHERSTRIP 102" 4 (USE 2 PER DOOR) 64163-55 WASHER .328X.75X14 64141-6 NUT, 5/16-18 64139-08 BOLT-5/16-18X3/4 64-580 DOOR HINGE...
Page 20 CAB PARTS (2) TURF UNIT FIGURE 2...
Page 21: Cab Parts (2)
CAB PARTS (2) TURF UNIT FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 64139-13 BLT-WLF 5/16-18X1/2 64141-6 NUT, 5/16-18 35-054 WINDSHLD WIPER ARM 35-055 WINDSHLD WIPER BLADE 35-053 MOTOR-WINDSHLD WIPER 1 57-009-123 WINDSHLD MOLDING-123" 06-035 FRONT WINDSHLD GLASS 60-667 PANEL-FRONT 60-668...
Page 22 COMMERCIAL GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.cgcequip.com BOB-CAT BUNTON RYAN STEINER...
