southpaw enterprises 2255 Instruction Sheet

southpaw enterprises, inc.
Instruction Sheet
Floor Mirror 2255
Take time to familiarize yourself with the use and maintenance of this equipment before using. Please file
this Instruction Sheet in an accessible location: the Instruction Sheet must be read and familiar to anyone
who is using Southpaw Enterprises Equipment.
IMPORTANT: Please check equipment immediately for any damage that may have resulted during shipping.
If any damage has occurred, please contact Southpaw Enterprises, Inc. immediately.

MATERIALS LIST

1 - Folding Side Support
1 - Mirror / Blackboard with fixed side bolts
2 - Black Plastic Knobs
4 - Large Washers
1 - Instruction Sheet
1 - Maintenance Checklist
IMPORTANT: Keep all parts together.

ASSEMBLY PROCEDURES

1. Remove the knobs and one washer from each side of the
mirror.
2. Unfold the frame (Fig. 1) and gently spread the tops of each
side support until you can place the mirror between them.
(Fig. 2).
3. Put one of the bolts into the hole on the top of one side
support, then put the bolt on the opposite side into the hole
on the other side support. Put one washer and a knob on
each bolt.
4. Tighten knobs firmly. DO NOT OVER TIGHTEN!
5. To remove the protective covering from the mirror, lift at
edges. If there is any difficulty removing the sheeting, use
aliphatic naphtha, kerosene, or distilled alcohol to moisten the
adhesive. Do not use other chemicals or sharp objects to
remove the sheeting.

TO ADJUST THE ANGLE OF THE MIRROR

1. Loosen knobs (Fig. 3).
2. Move mirror to desired angle.
3. Tighten knobs firmly.

SPECIAL NOTES

•
The floor mirror is not designed to be used parallel to the
floor in a table-like manner.
•
Do not use tape on mirror surface.
Store these instructions in a safe place or
with the enclosed maintenance checklist
Mirror/Blackboard
Washers
Black
Knob
Bolt
Side Support
Mirror/Blackboard
®
Side Support
Fig. 1
Fig. 2
Fig. 3
Black
Knob
