American Changer Corp.
th
1400 NW 65
Place
Ft. Lauderdale, FL 33309
Service Questions?: E-mail:
Table of Contents
SECTION A: SET-UP & INSTALLATION
Uncrating & Setup
SECTION C: TROUBLESHOOTING
INFORMATION
SECTION E: PARTS LISTS
Parts Compact Hopper
CoinCo branches and Service centers
are on the back cover of this manual.
Rev. MIDI C-40 Jan"04
www.americanchanger.com
Internet Address:
3
3-4
4
4
4
5-6
6
6
6-13
6
6
7
9
10-11
12
14-16
14
15-16
17
20-23
VALICHANGER
OPERATIONS MANUAL
SERIES AC400/500
Parts & Service:(888)741-9840
service@americanchanger.com
Operating voltage
Power consumpt.(controller only, add hopper and validator)10
Operating temperature
Interface to Hoppers
Interface to Validators
AC 500 CoinCo BA30BAB Validator
The CoinCo Dollar Bill Validator is warranted for two years
from date of purchase.
AC400 JCM DBV-10 Bill Validator is warranted for 1 year.
COVERED
¥ Defect in workmanship or material.
NOT COVERED
¥ Damage caused by physical abuse.
¥ Misapplication.
¥ Vandalism.
¥ End users attempt, on his own to repair item.
¥ Cleaning maintenance.
It is the End User's responsibility to follow cleaning
maintenance procedure outline on page 12. Any unit coming
in for repair requiring only a cleaning will be charged a flat
rate of $65.00 plus shipping and handling
Dispensing System and Logic Board
The dispenser and logic board is warranted
for one year from date of purchase.
COVERED
¥ Defects caused by material or workmanship.
NOT COVERED
¥ Damage caused by physical abuse.
¥ Misapplication.
¥ Vandalism.
¥ End Users attempt, on his own to repair.
A Return material authorization number (RMA#) must be
obtained before returning a unit for repair . A copy of
invoices must accompany any and all warrantee work.
1
Sales:(800)741-9840
Fax:(954)917-5204
Specifications
120 VAC +10/-15 %
32 - 130 degrees Fahrenheit
24vdc & 12vdc 1.5 amps max.
120vac .5 amps max.
Warranty
w
Advertisement
Table of Contents
Related Manuals for American Changer VALICHANGER AC400 Series
Summary of Contents for American Changer VALICHANGER AC400 Series
-
Page 1: Table Of Contents
VALICHANGER OPERATIONS MANUAL SERIES AC400/500 American Changer Corp. Parts & Service:(888)741-9840 1400 NW 65 Place Sales:(800)741-9840 Ft. Lauderdale, FL 33309 Fax:(954)917-5204 www.americanchanger.com Internet Address: service@americanchanger.com Service Questions?: E-mail: Specifications Table of Contents Operating voltage 120 VAC +10/-15 % Power consumpt.(controller only, add hopper and validator)10 SECTION A: SET-UP &... - Page 2 If this is a concern for your area of business, we recommend purchasing a surge protector locally NOTE: A POWER STRIP IS NOT A SURGE PROTECTOR. AC __________ S/N# _________________________ Tested By ___________________________ Date __________________ Thank You, American Changer Corp.
-
Page 3: Mounting Instructions
UNCRATING AND SET-UP Let the electrician run the conduit, install the new breaker, wire and help decide how the wiring will enter Remove your Series AC400/500 changer from the shipping the changer (from the back or the bottom). This will box. -
Page 4: Filling The Hopper
mark next to it. Whenever the “Empty” LED is “ON” the Plug the male end into the AC wall outlet. Do not validator is disabled and it will no longer accept bills. use an extension cord unless allowed by the building electrical code. -
Page 5: Functional Descriptions
LED on the main logic board comes on steady, and the American Changer. red LED on the main logic board will light then go off Indications for a blocked coin optic or bad hopper then flicker on once per second in the standby mode. -
Page 6: Indicator Lights
Indicator Lights AC500 ONLY! Main Logic Board: Green LED on: AC power applied to the logic board. All fuses are good. CoinCo MAGPRO Series Flash Codes Flash codes 1-18 may appear during normal servicing of the Red LED BA30. If more than one error or condition exists, the lower Heartbeat - 5 and 12vdc present. -
Page 7: Ac400 Removing A Bill Jam
AC400 BILL VALIDATOR CLEANING AND UN-JAMMING... - Page 8 COINCO MAG50B VALIDATOR SECTION PAGE Removing the Bill Box Clearing a bill jam Setting the bill types accepted Cleaning the sensors Cleaning a salted unit Replacing the belts...
-
Page 9: Ac500 Clearing A Bill Jam
Removing the bill box. To remove the 1000 bill stacker from the CoinCo validator follow the picture below. REMOVING A BILL JAM From time to time a foreign object or ripped bill will become caught in the validator. Follow the picture below to remove the item. -
Page 10: Setting The Coinco Dip Switches
SETTING THE BILL ACCEPT DIP SWITCHES... - Page 11 CLEANING THE BILL VALIDATOR Refer to the pictures and the procedure on the next page to clean the bill validator every 4-6 months.
-
Page 12: Coinco Validator Cleaning
MAGPRO CLEANING: IF ANY OF THESE PROCEDURES ARE PERFORMED TO YOUR VALIDATOR AFTER IT IS RETURNED UNDER A WARRANTY REPLACEMENT, YOU WILL BE SUBJECTED TO A $65.00 LABOR FEE. CLEANING AND MAINTENANCE: Note: Petroleum-based cleaners and freon-based propellants can damage plastic and some electronic components. Scouring pads and stiff brushes may harm the protective conformal coating on the circuit boards and can mar the plastic. - Page 13 REPLACING THE BELTS Every 2-3 years the belts on the CoinCo will wear out. To replace them, remove the validator components down to the picture show. Refer to the parts diagram at the end of the manual for help getting to this point.
- Page 14 TECHNICAL FLOW DIAGRAM FOR THE AC400/500 NOTE: Before starting this procedure ensure the changer is plugged in, the ON/OFF switch is on, the hopper is full of coins, and all wire harnesses are connected securely and correctly. The wires exiting the red connectors should point away from the board! Start Here! Is the “Empty”...
-
Page 15: Troubleshooting Guide
TROUBLESHOOTING GUIDE TO USE THE TROUBLESHOOTING GUIDE, MATCH UP THE PROBLEM, THEN FOLLOW THE SOLUTION SUGGESTIONS. After every step re-try operating the changer to see if the problem has been solved. Problem: Solution: Ensure the changer is plugged in. Ensure the on/off switch is rocked to the (1) position (down). Unplug the female end of the line cord from the main logic board AC A. - Page 16 TROUBLESHOOTING GUIDE TO USE THE TROUBLESHOOTING GUIDE, MATCH UP THE PROBLEM, THEN FOLLOW THE SOLUTION SUGGESTIONS. After every step re-try operating the changer to see if the problem has been solved. PROBLEM: SOLUTION: Clean the validator optic LED’s. (See pg. 12) I.
- Page 17 COIN CONTROLS COMPACT HOPPER PARTS LIST...
-
Page 18: Ac500 Cabinet Parts Breakdown
AC500 CABINET PARTS BREAKDOWN AC500 CABINET PARTS SHOWN #1 - AC5010 -CABINET W/DOOR AND LOCK NUT ASSY #2 - AC5060 -AC500 MAIN LOGIC BOARD #3 - AC5040.1 -COIN CONTROLS COMPACT HOPPER #4 - AC5081 -$1 & $5 FULL FRONT STICKER #5 - AC5080 -SCREW –IN T-HANDLE #6 -... -
Page 19: Ac400 Cabinet Parts Breakdown
AC400 CABINET PARTS BREAKDOWN AC400 CABINET PARTS SHOWN #1 - AC5010 -CABINET W/ LOCK NUT ASSY #2 - AC4060 -AC400 MAIN LOGIC BOARD #3 - AC5040.1 -COIN CONTROLS COMPACT HOPPER #4 - AC5081 -$1.00 FULL FRONT STICKER #5 - AC5080 -SCREW –IN T-HANDLE #6 - AC1093 -LOCK AND 2 KEYS #7 -... - Page 20 COINCO PARTS LIST MOUNTING ASSEMBLY PARTS BREAKDOWN PART # DESCRIPTION PICTURE # MP90-1-1 Machine Screw MP90-1-2 “Snack Mask” Black Plastic MP90-1-3 Machine Screw MP90-1-4 Main Frame, Plastic MP91-1-5 Mask Gold Mounting Bracket MP90-1-6 Bill grounding spring MP91-1-7 Machine Nut...
-
Page 21: Coinco Parts Breakdown
COINCO PARTS BREAKDOWN BELTS ONLY! MP91-2-10 PART # DESCRIPTION PICTURE # MP90-2-1 Bottom Lower Housing Cover MP90-2-2 Transformer holding hose MP90-2-3 120VAC Transformer MP90-2-4 Lower Spring, Anti-Cheat Lever MP91-2-5 Lower Mounting, Anti-Cheat Lever MP90-2-6 Lower Anti-Cheat Lever MP90-2-7 Lower Housing Assembly, Complete MP90-2-8 Belt, Center MP90-2-9... - Page 22 COINCO PARTS BREAKDOWN DESCRIPTION PART # PICTURE # Dust Cover MP90-3-1 Upper Transport & Hub Assembly, Complete MP90-3-2 Motor, Transport & Gear Assembly Complete MP91-3-3 Wheel, Encoder MP90-3-4 Stacker, Push-Plate Assembly MP90-3-5 Spring, Belt Tension MP90-3-8 Motor, Stacker Assembly Complete MP90-3-9 Pulley, Idler MP90-3-10...
- Page 23 COINCO PARTS BREAKDOWN MP90-4-IF PICTURE # PART # DESCRIPTION MP90-4-1 Lid, Logic board Box MP91-4-2 Body, Logic board Box MP90-4-3 Main Logic Board MP90-4-4 Sticker, Serial Number / Warranty MP90-4-IF Intermediate Frame with Bearings...
- Page 24 Phone: 813-249-7338 Phone: 504-734-0280 Dallas, TX 75247 Bob Wilcox Frank Case Phone: 214-638-3970 Ft. Lauderdale Maryland Houston American Changer 6655 Amberton Drive 2500 Central Parkway 1400 NW 65 Place Bay “L” Suite “K” Ft. Lauderdale, FL 33309 Baltimore, MD 21227...
