Summary of Contents for sks CYCLONE
- Page 1 CYCLONE/CYCLONE PLUS MANUAL...
- Page 2 CONTENTS PARTS DIAGRAM MACHINE INSTALLATION & PREPARATION Checking For Damage Installation Environmental Conditions OPERATION & MAINTENANCE Cutting a Key - Cylinder Cutting a Key - Mortice Replacing The Cutters Machine Adjustment General Maintenance HEALTH & SAFETY...
- Page 3 PARTS DIAGRAM 1. Light bulb and cover 2. Voltmeter 3. Cutter guard 4. Cylinder follower 5. Cylinder cutter 6. Cylinder jaws/carriage 7. Swarf tray 8. Protective shield 9. Brush 10. Switch 11. Main switch 12. Mortice cutter 13. Mortice follower 14.
- Page 4 MACHINE INSTALLATION & PREPARATION The key cutting machine can be installed by the purchaser and does not require any special skills. However, some checks and preparation for use need to be carried out by the operator. CHECKING FOR DAMAGE The key cutting machine is solid and compact and will not normally damage if transport, unpacking and installation have all been carried out according to the instructions in this manual.
- Page 5 The Cyclone Plus has tilting mortice jaws to allow you to round the cuts. To use this feature you just need to remove the pin from the carriage. To lock the jaws back into the fixed horizontal position...
- Page 6 REPLACING THE CUTTERS WARNING! ENSURE MACHINE IS UNPLUGGED BEFORE UNDERTAKING ANY MAINTENANCE • Remove the three screws holding the case on the machine (one each side and one at back) then carefully lift the case off the machine • Locate the cut-out on the shaft that runs between the two cutters and insert a 4mm allen key (or similar) to lock the cutter shaft in position •...
- Page 7 If this is out of alignment: • Loosen the screw holding the tracer point • Turn the tracer adjustment ring (clockwise to extend tracer and anti-clockwise to retract it) until the cutter skims against the blank on the right whilst the key on the left is against the tracer •...
- Page 8 • Keep the machine clean of swarf, particularly the jaws and other moving parts using a dry brush NOTE – Do not use compressed air • Ensure the sliding shaft is kept lubricated • Check all screws and bolts for any slackness and tighten if necessary HEALTH &...
