JBL OnBeat
Quick Setup Guide
WeLCOme
Thank you for purchasing the JBL OnBeat
aWake iPad dock. This quick setup guide will
show you how to connect and set up your
dock. To download the free JBL AmpUp App
please go to the Apple App Store.
NOTE: Alarm functions described below are
only available through the JBL AmpUp app.
COnneCtIOnS
1. Plug the JBL OnBeat aWake's power supply into the DC-In connector on the unit and
into a working AC power outlet. The JBL OnBeat aWake will automatically turn on. The
clock display screen will read "On" for 3 seconds and will then show "--:--". When you
dock your device the OnBeat aWake's clock display will synchronize with the device's
clock and will display the current time.
2. If you are going to use your JBL OnBeat aWake with another audio source, plug one
end of a 3.5mm (1/8") stereo cable (not supplied) into the JBL OnBeat aWake's Audio-In
connector, and plug the other end into the audio source's audio out or headphone out
connector.
aWake
™
™
DC-In
Audio-In
DC In
Aux In
