Dcbnet Conitel ASYNC Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Conitel ASYNC
Adapter

TABLE OF CONTENTS

SECTION 1 - DESCRIPTION .......................................................................... 2
SECTION 2 - SPECIFICATIONS .................................................................... 4
SECTION 3 - INSTALLATION ........................................................................ 6
SECTION 4 - CONTROLS AND INDICATORS ............................................ 9
SECTION 5 - NETWORK MANAGEMENT PORT .....................................11
SECTION 6 - INTERFACE SIGNALS AND CABLING.............................16
SECTION 7 - TROUBLESHOOTING ...........................................................21
SECTION 8 - WARRANTY..............................................................................22
Data Comm for Business, Inc.
PO Box 6329
Champaign, IL 61826-6329
July 16, 2013
(217) 897-6600
Firmware Version: 1.3
www.dcbnet.com
8500105

Advertisement

loading
Need help?

Need help?

Do you have a question about the Conitel ASYNC and is the answer not in the manual?

Questions and answers

Summary of Contents for Dcbnet Conitel ASYNC

  • Page 1: Table Of Contents

    Conitel ASYNC Adapter TABLE OF CONTENTS SECTION 1 - DESCRIPTION ................2 SECTION 2 - SPECIFICATIONS ..............4 SECTION 3 - INSTALLATION ................ 6 SECTION 4 - CONTROLS AND INDICATORS ..........9 SECTION 5 - NETWORK MANAGEMENT PORT ........11 SECTION 6 - INTERFACE SIGNALS AND CABLING......16 SECTION 7 - TROUBLESHOOTING ............21...

  • Page 2: Section 1 - Description

    DDS, radio links, or Ethernet/IP networks using the DCB EtherPath or EtherPoll. The Conitel Async Adapter can be used in conjunction with the DCB 202T modem for connection to RTU devices with built in modems. The transmit output of the 202T can be set to –16 dBm for connection to built in modems that are sensitive to high receive levels.
  • Page 3 TEST Conitel ASYNC Adapter LINE MODEM PORT 1 LOOPBACK SETUP RESET POWER ACTIVITY ERROR READY SETUP LOOPBACK Network Network Switches DSU Telco Power Management Port Composite CAA shown with optional built-in DSU/CSU...

  • Page 4: Section 2 - Specifications

    SPECIFICATIONS Data Port Port Speeds Asynchronous only 1200, 2400, 4800, 9600, 19,200, 38,400, or 57,600 bps Port Rate Selection Selected through network management port control with an asynchronous terminal. Data Format 32 bit Conitel 2020 Interface CCITT V.24, RS-232D, implemented in RJ-45, 8 position connectors.
  • Page 5 Environmental Operation: -40 to +70° C, 10 to 95% relative humidity Storage: -40 to +85° C, 10 to 95% relative humidity Network Management Port Commands Show Port Configuration Show Network Status Change Port Configuration Change Data Delay Configure Network Show / Change ID Set NMP Password Activity Counters Zero Activity Counters...

  • Page 6: Section 3 - Installation

    INSTALLATION Unpacking Remove the unit from the shipping container and examine it carefully for external damage. If shipping damage is apparent, notify the shipper immediately. The following accessories are included with the unit: external power supply • manual • warranty, maintenance contract and repair information •...
  • Page 7 Connect the unit to power. Power and Modem Ready indicators on the front panel of the CAA must be ON indicating the on-line condition. (See Section 4). Optional Built-In 56 or 64 Kbps DSU/CSU The optional DSU/CSU is configured using DIP switches accessable from the rear of the unit.
  • Page 8 Resetting Factory Defaults The factory default settings for the CAA are as follows: Data Port: Rate 1200 bps DCD to RxD delay DCD holdover 12ms Composite Port: Modem type ASYNC Rate 9600 bps To reset the unit to factory defauls use the !R command from the network management port or perform the following steps using the front panel switches: 1.

  • Page 9: Section 4 - Controls And Indicators

    CONTROLS AND INDICATORS Switches TEST LINE MODEM PORT 1 LOOPBACK SETUP RESET POWER ACTIVITY ERROR READY SETUP LOOPBACK 4.1.1 Front Panel Switches (shown with built-in DSU) Setup – Used in conjunction with Reset to recall factory default settings Loopback – Disabled. Reset –...
  • Page 10 For normal operation with a telephone company line, set the DSU for SLAVE clock timing (switch position 2 DOWN). For in-house line driver applications (56K only), set the host DSU for MASTER timing (switch position 2 UP). The remote unit should remain set for Slave clock.

  • Page 11: Section 5 - Network Management Port

    NETWORK MANAGEMENT PORT Introduction The Network Management port (NMP) is used to configure the unit for proper operation. This connection must be used to configure the CAA composite and data ports. The NMP can also be used to configure remote CAA parameters after a link is established between the host and remote sites.
  • Page 12 Using the Network Management port To activate the NMP, press the ENTER key. When you see AT YOUR COMMAND >>, the NMP is active and ready for your commands. Type H <Enter> to display the command set. Commands 5.4.1 Help (H or ?) COMMAND LOCAL REMOTE PARAGRAPH Show: Config...
  • Page 13 NOTE Several commands allow port numbers or port number ranges to be included on the command line. When port numbers are included, the syntax is as follows: (Command)1 Port 1 (Command)1,2,4 Ports 1, 2 & 4 (Command)1 3 4 Ports 1, 3 & 4 (Command)2−4 Ports 2 thru 4 5.4.4...
  • Page 14 5.4.8 Set Password Use the Set Password (PW) command to set a password for access to the network management port. The password may be up to 15 characters long and is case sensitive. To clear the password, type DELETE at the PW prompt or reset the unit to defaults as described in paragraph 3.6.
  • Page 15 5.4.13 Test Tools The Test Tools (TT) menu summarizes the test and troubleshooting commands. These commands are listed separately to reduce the clutter in the main help list, but are always available from the command prompt. COMMAND LOCAL REMOTE PARAGRAPH Monitor Port Tx 5.4.14 Monitor Port Rx...

  • Page 16: Section 6 - Interface Signals And Cabling

    INTERFACE SIGNALS AND CABLING Connector Location and Pin Reference Network Network Switches DSU Telco Power Management Port Composite 1 2 3 4 5 6 7 8 CAA Rear Panel and RJ-45 Jacks RJ-45 Plug Positions...
  • Page 17 Port Interface 6.2.1 Composite Port (RJ-45) Signal In/Out Receive Clock Transmit Clock Data Carrier Detect Signal Ground Transmit Data Receive Data Request to Send Clear to Send 6.2.2 Data Port (Conitel In, RJ-45) Signal In/Out Data Set Ready Data Carrier Detect Busy Signal Ground Receive Data...
  • Page 18 Cables 6.3.1 Composite Port to Modem A two foot composite to modem cable is included with each unit. The configuration is as follows: Modem RJ-45 DB-25P 6.3.2 Data Port to Host Computer Configured as DTE Computer RJ-45 DB-25 (or other flow control output pin) (or other flow control input pin) (or 20 if 4 is flow control)
  • Page 19 6.3.2 Data Port to Host Computer, continued Configured as DCE Computer RJ-45 DB-25 (or 4 if 20 is flow control) (or other flow control output pin) (or other flow control input pin) To a PC Computer RJ-45 DB-25S DE-9S...
  • Page 20 6.3.3 Network Management Port To a TERMINAL Terminal RJ-45 DB-25P To a PC using terminal emulation Computer RJ-45 DE-9S DB-25S To a dial-up MODEM for remote access Modem RJ-45 DB-25P...

  • Page 21: Section 7 - Troubleshooting

    TROUBLESHOOTING General Approach When troubleshooting problems, a rational plan can save you many hours of frustration. The following is a brief outline of standard troubleshooting procedures. 1. Gather the facts to determine the exact nature of the problem. 2. Draw a picture of the system showing the equipment at both the host and remote ends and the phone lines or in-house wiring.

  • Page 22: Section 8 - Warranty

    Equipment must be shipped prepaid to DCB and will be returned at DCB's expense. Ship returned items to: Data Comm for Business 2949 County Road 1000E Dewey, IL 61840 ATTN: RMA# Data Comm for Business, Inc. PO Box 6329 Champaign, IL 61826-6329 (217) 897-6600 (217) 897-1331 Email support@dcbnet.com...
