INTRODUCTION

The Little Giant liquid level control is designed to be used with
Little Giant Effluent and Sewage pumps or other pumps rated 13
Amps or less.
Little Giant products are carefully packaged, inspected and tested
to insure safe operations and delivery. When you receive your
switch, examine it carefully to determine that there are no parts
missing or which may have been damaged or broken during
shipment. If damage has occurred, make notation and notify
and/or return to the firm from which you purchased the switch and
they will assist you in replacement or repair.

SAFETY GUIDELINES

1. Read all instructions and safety guidelines thoroughly. Failure
to follow guidelines and instructions could result in serious
bodily injury and/or property damage.
2. During operation, the area around the pump and switch may
be covered with water. Take care when handling switch or
pump. Do not pull pump out of the water by the power cord.
3. Disconnect all electrical service to the pump and unplug the
pump and/or switch before working on the unit or handling the
unit.
4. Make sure all outlets used are grounded.
5. Do not stand in water while changing fuses, resetting circuit
breakers or repairing switch or pump.
Figure 1.
RFSN-6
RFSN-9
RFSN-10
Liquid Level Control
Non-Mercury/Float Type
Figure 2.
