Models: LMFP- (48 / 60 / 72 / 84 / 96 / 108 / 120)
*Class A chimney can be used as an optional chimney system. Consult chimney system manufacturer's instructions.
WARNING:
If the information in these instructions is
not followed exactly, a fire or explosion
may result causing property damage,
personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier from
a neighbor's phone and follow the gas
supplier's instructions.
If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer, service
agency, or the gas supplier.
Do not store gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
REV 010721
Inc.
B-Vent* Gas Appliance with Masonry Firebox
IMPORTANT:
CAREFULLY BEFORE STARTING
INSTALLATION OF THIS APPLIANCE.
The logs and burner must be permanently installed and
are only for use in this appliance. This appliance must be
connected to a working flue meeting the requirements of
the ANSI Z21.50 standard.
Solid-fuels shall not be burned in this appliance.
This appliance must be vented vertically through the
roof. This appliance is not for installation in manufactured
or mobile homes. The installation, including provisions
for combustion, ventilation air, and required minimum
permanent vent opening, must conform with the National
Fuel Gas Code (ANSI Z223.1/NFPA 54) and applicable
local building codes. This gas appliance is designed to
burn with yellow flames; thus adequate ventilation is
absolutely necessary.
This gas appliance must not be connected to a chimney
fuel servicing a solid fuel burning appliance.
: Leave this manual with the appliance.
INSTALLER
CONSUMER:
This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases, unless a certified kit is used.
Instructions
Shown with optional Draft
Hood, Glass Doors, Burner
System and Firebrick
(ALL SOLD SEPARATELY)
READ THESE INSTRUCTIONS
WARNING:
Retain this manual for future reference.
PFS
C
®
US
