140274 CHS-Newport Alum Top Sq Dining table - Champagne Silver
Parts
A
B
C
ATTENTION:
1. Please read this instruction carefully before assembly.
2. Aluminum is soft metal, over tightening may strip threads or break the part.
3. Do not use power tools.
Assembly steps
1. Fix leg A onto the table frame B with S.S plate C .screw D and Hex key E.
Assembly Instructions
Description
Table leg
Frame
S.S Plate
B
E
D
C
A
QTY
Parts
2X
D
1X
E
8X
E
D
C
Description
Screw
M6*35mm
Hex key M4
QTY
16X
1X
