OPERATOR'S MANUAL
ANGLE POLISHER WITH
VARIABLE SPEED
Thank you for buying a WORKPRO product. Your angle polisher with variable speed has been engineered and
manufactured to WORKPRO's high standard for dependability, ease of operation, and operator safety. When
properly cared for, it will give you years of rugged, trouble-free performance.
WARNING: To reduce the risk of injury, the user must read and understand the operator's manual
before using this product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
W125020A
Advertisement
Table of Contents
Related Manuals for WorkPro W125020A
Summary of Contents for WorkPro W125020A
- Page 1 ANGLE POLISHER WITH VARIABLE SPEED Thank you for buying a WORKPRO product. Your angle polisher with variable speed has been engineered and manufactured to WORKPRO’s high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Introduction .......................... Important safety instructions .................... Safety warnings ......................... Safety warnings common for grinding, sanding, wire brushing, polishing, or abrasive cutting-off operations ........................ Additional specific safety instructions .................. Symbols ............................ Know your product ........................ -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS Avoid accidental starting. Be sure switch is WARNING! offbefore plugging in. Carrying tools with your finger onthe switch or plugging in tools that have the Read and understand all instructions. Failure to switch on invites accidents. follow all instructions listed below may result in ... -
Page 4: Safety Warnings
IMPORTANT SAFETY INSTRUCTIONS SERVICE When servicing a tool, use only identical replace- ment parts. Follow instructions in the Mainte- Tool service must be performed only by nance section of this manual. Use of unauthorized qualifiedrepair personnel. Service or maintenance parts or failure tofollow Maintenance Instructions performed by unqualified personnel may result in a may create a risk of shock or injury. -
Page 5: Cutting-Off Operations
SAFETY WARNINGS RESIDUAL RISKS Even if you are operating this product in accordance WARNING! with all the safety requirements, potential risks of injury and damage remain. The following dangers Some dust created by power sanding, sawing, can arise in connection with the structure and design grinding, drilling and other construction activities of this product: contains chemicals known to cause cancer, birth... - Page 6 SAFETY WARNINGS COMMON FOR GRINDING, SANDING, WIRE BRUSHING,POLISHING, OR ABRASIVE CUTTING-OFF OPERATIONS 7. Do not use a damaged accessory. Before each 14. Regularly clean the power tool’s air vents. The use inspect the accessory such as abrasive motor’s fan will draw the dust inside the housing and wheels for chips and cracks, backing pad for excessive accumulation of powdered metal may cause cracks, tear or excess wear, wire brush for...
-
Page 7: Additional Specific Safety Instructions
ADDITIONAL SPECIFIC SAFETY INSTRUCTIONS Do not use tool if ON/OFF Trigger does not turn it WARNING! ON or OFF. Any tool that cannot be controlled with the power switch is dangerous and must be RISK OF PERSONAL INJURY: repaired. ... -
Page 8: Symbols
SYMBOLS On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarize yourself with them to reduce hazards like personal injuries and damage to property. Volt, (alternating voltage) Millimetre Hertz Kilogram Watt dB(A) -
Page 9: Know Your Product
1. Auxiliary handle 5. Power cord 2. Spindle lock button 6. ON/ OFF Switch 3. Grinder spindle 7. Backing pad 4. Speed adjustment TECHNICAL SPECIFICATION Model #: W125020A Rated Voltage: 120V~60Hz Rated Power: No-load Speed: 1500-4000RPM Diameter: 7in (180mm) UNPACKING ... -
Page 10: Set Up Before Use
SET UP BEFORE USE INTENDED USE The machine is intended for polishing and sanding of Option 2: Using with a side handle (side handle painted or fiberglass surfaces. For reasons of not included). electrical safety the machine must not be damp or This tool can be used with many standard angle operated in a humid environment. -
Page 11: Operation Instructions
NOTICE: Only use the slower speeds for polishing. Otherwise, damage may occur to the paint being polished. WORKPRO Tools is not responsible for damage to the vehicle’s finish due to improper use of this polisher/sander. Plug the power cord into an electrical extension cord (not included). - Page 12 OPERATION INSTRUCTIONS Note: most common error when WARNING! waxing/polishing a vehicle is applying too much wax. If the Foam Pad becomes saturated with wax, To prevent electric shock, keep cord connection applying wax will be more difficult and will take off ground.
-
Page 13: Maintenance
OPERATION INSTRUCTIONS Wait until the polisher/sander has reached full speed, then gently contact the surface. Keep heavy pressure off of the polisher/sander when operating. Allow the sanding disk to do the work. Move the polisher/sander in a uniform pattern up and down or side to side as you sand to ensure SANDING even sanding. -
Page 14: Trouble Shooting
MAINTENANCE Use only a clean cloth and mild detergent to clean the g. Replace the Carbon Brush Covers. Do not over body of the polisher. Do not use solvents. Do not tighten. immerse any part of the tool in liquid. CARBON BRUSH MAINTENANCE. -
Page 15: Recycling And Disposal
TROUBLE SHOOTING Overheating. 1. Forcing tool to work too fast. 1. Allow tool to work at its own rate. 2. Blocked motor housing vents. 2. Wear ANSI-approved safety goggles and 3. Motor being strained by long or NIOSH-approved dust mask/respirator while small diameter extension cord.
