Summary of Contents for ZoraBots Robin
- Page 1 User Manual docs.zorabots.be...
- Page 2 Power adapter x 1 (Design of adapter could diff er from EU/UK/US standard, picture may be diff erent from the real delivery) Robin x 1 Type-C cable x 1 User Manual docs.zorabots.be User Manual x 1 SIM card eject pin x 1...
- Page 3 Quick Guide User Manual Download and install the ZBOS Software of ZoraBots. Search for the ZBOS Control app in the App Store or Google Play or scan the QR code to download the app on your mobile device. Follow the instructions on the application on your mobile device.
- Page 4 • Open the ZBOS app. Select your Robot and log in with your account • Follow the instructions on the app to connect your Robin to the internet for the binding process. Turn your Robin off • Press and hold the power button for 3 seconds until your Robin is off;...
-
Page 5: Feature Introduction
• The Robot support one nano SIM card and 4G network. Install a SIM Card • Turn off your Robin and locate the SIM card slot under his left armpit. Push a SIM eject tool into the small hole next to the SIM slot with a little force to pull the SIM tray out. - Page 6 Do’s User Manual Grab your Robin properly: Use the handy grips of your Robin to pick him up. If your Robin is in sleep mode or turned off while charging, please place the Robin in the pose shown below.
- Page 7 Don’ts User Manual Do not touch your Robin when he is moving to Do not place your Robin at the edge of avoid hand injuries. a table. Do not twist or pull Robin’s head with Do not put your Robin on an inclined force.
- Page 8 Hardware User Manual Camera LCD eyes LED mouth Infrared sensor SIM slot Microphone Stereo speakers...
- Page 9 Hardware User Manual Sling hole Handy grip Volume button Power button Type-C interface...
- Page 10 Hardware User Manual Touch sensor Microphone Microphone array array...
-
Page 11: Buttons And Lights
User Manual Power button Press and hold Press and hold for 3 seconds to turn your Robin on or off. Press the power button to check the battery level after turning on Press your robot or during the charging process. -
Page 12: Product Specifications
Product Specifications User Manual Product name AlphaMini Robot Product model Alpha Mini Height 245mm, Width 149mm, Thickness 112mm (The actual Measurements size may vary slightly depending on the configuration, manufacturing process, and measurement method) Weight About 700g 14 joints in total Joints (3 head joints, 4 arm joints, 1 waist joint, 6 leg joints ) Network... - Page 13 Product Specifications User Manual Mode Frequency Max Emission Power (dBm) Bluetooth 2402MHz-2480MHz 9.532 2402MHz-2480MHz 1.146 Wlan 2,4G 2412MHz-2472MHz 16.8 Uplink:1922.4MHz-1977.6MHz LTE Band1 22.04 Downlink:2112.4MHz-2167.6MHz Uplink:1710MHz-1785MHz LTE Band3 21.89 Downlink:1805MHz-1880MHz Uplink:1922.4MHz-1977.6MHz WCDMA Band1 21.68 Downlink:2112.4MHz-2167.6MHz Uplink:882.4MHz-912.6MHz WCDMA Band8 22.16 Downlink:927.4MHz-957.6MHz...
- Page 14 • This product only supports official upgrades. Please do not upgrade the softwares/software systems in other ways to avoid damage or user information leakage. • In abnormal situations (such as start-up failure, shutdown failure, no response from the robot, or abnormal actions, etc.), please contact support.zorabots.be.
- Page 15 WARNING: 1 ) The packaging must be retained since it contains important information. 2) The battery charger used with the toy are to be regularly examined for damage to the cord, plug, enclosure and other parts, and in the event of such damage,they must not be used until the damage has been repaired.
- Page 16 CAUTION: Danger of explosion if battery is incorrectly replaced, Replace only with the same or equivalent type. means all the safety and operating instructions should be read before this product is operated.
-
Page 17: Eu Declaration Of Conformity
EU Declaration of Conformity We UBTECH ROBOTICS CORP LTD Address: 16th and 22nd Floor, Block C1, Nanshan I Park, No.1001 Xueyuan Road, Nanshan District, Shenzhen City, P.R. CHINA. declare under our sole responsibility that the product Product Name: AlphaMini Robot Model name: Alpha Mini Software:... - Page 18 ZoraBots Archimedesstraat 17, 8400 Oostende, Belgium www.zorabots.be...
