- Page 1 User Guide Of Digital Microscope AD208...
-
Page 2: Table Of Contents
Table of Contents Safety Instruction & Maintenance............... 错误！未定义书签。 Installation....................错误！未定义书签。 Button Description..................错误！未定义书签。 Quick start ........................错误！未定义书签。 Adjusting the Magnification and Focus ..................7 Using a Micro SD Card to Save Images/Videos ......... 错误！未定义书签。 Reviewing Images/Videos ................错误！未定义书签。 Settings ........................错误！未定义书签。... -
Page 3: Safety Instruction & Maintenance
Safety Instruction & Maintenance 1. Please read this manual before using the digital microscope to avoid permanent damage to the equipment caused by non-compliance with the manual. Keep the device in clean and dry environment and Keep it away from oil, water, gas and other materials that may cause corrosion. It is not recommended to use this product outdoors. -
Page 4: Installation
Installation （Pic.1 Installation1） （Pic.2 Installation2） （Correct direction） （Wrong direction） （Pic.3 Mounting metal clips） 1. Screw the optical bracket on the base (see the picture above, Pic.1 ) 2. Screw the microscope screw (see Pic.2) on the cross-beam ring outwards, leaving enough space for the microscope to fit in. - Page 5 to hold it in place. Do not jam the microscope in the position of focus cylinder during this process. If the installation is done correctly, the focus cylinder, microscope screen and the angle between the column and the base plate can be adjusted freely after installation. 5.
-
Page 6: Button Description
Button Description （Pic.4 buttons） ①Power on/off ②Mode/menu ③Up ④Down ⑤OK/Start recording video ⑥Take photos ⑦Light controller ⑧Focus controller ⑨Memory card slot ⑩USB port ⑪Reset hole... - Page 7 （Pic.5 Wiring Diagram）...
-
Page 8: Quick Start
Quick Start 1. connect the microscope mainframe with the power supply via the switch cable. (See Pic.5) 2. Press the power button (Pic.4/①) until the display lights up. (It is normal for the main unit to turn itself on when the power is applied.) *Troubleshooting If the screen appears to be stuck, reset the system using the "Reset hole"... - Page 9 The duration of the recorded video is displayed in red in the upper right corner of the screen. Press the "OK" button to start recording. stop recording, press the "OK" button briefly again. To capture pictures Method 1: Under the video mode ( ), press "OK"...
-
Page 10: Settings
Method 2 ： Press the "M" button to switch to the camera mode ( ), and then press "OK" to shoot. Note: Photos or videos cannot be taken under the playback mode. Reviewing pictures and videos To review images and videos on the display, use the “Mode”(M) button to enter review mode. - Page 11 （Pic.6 Video Menu） Then, press “Menu” button (or M on the monitor) again, you get into the Setting menu, like this: （Pic.7 Setting Menu）...
-
Page 12: Faq
Date/Time Press “OK” into Date/time setting. Use “Up” and “Down” to select the correct number for year/month/day. Once you finish setting a number, press “OK” on the monitor to the next number. Or, you can use “Left” and “Right” on the remote to get to the one that you want. Press “MENU”... -
Page 13: Warranty Card
microscope in order to save the settings. Through the switch cable to power off the main unit or directly cut the power, the settings will not be saved. 5. Why does the machine restart repeatedly? Please check the power adapter and use a high-quality 5V 2A power adapter. 6.Why does "memory card error"...
