Table of contents Camera Specifications ..........7 Introduction ..................8 Camera types ..................8 1.1.1 Connecting Cameras to the Imagechecker ........... 11 1.1.2 2-Mega-Pixel Digital Camera ANPVC 1210 / 2260 ......... 12 Time Diagram for Image Grabbing ............12 1.2.1 Dimensions ..................14 1.2.2 Specifications .................. -
Page 7: Camera Specifications
Chapter 1 Camera Specifications... -
Page 8: Introduction
1.1.1 Camera types The camera types listed below are available as standard types. Select the type most suitable for your application. 2-Mega-pixel Gray digital 2-Mega-pixel Gray digital camera (ANPVC 1210D) camera (ANPVC 1211D) For details specification contact the technical sup- port. - Page 9 Table of contents Quad-speed Color digital 2-Mega-Pixel Color digital camera (ANPVC 2040) Camera (ANPVC 2260) Pixel size 7.4 x 7.4m 4.4 x 4.4m...
- Page 10 Table of contents Triple-speed Gray digital camera (ANPVC 5030) For details specification contact the technical support. No. of pixels 300,000 pixels Image transfer time Ca. 11ms Dimensions (width x 29 x 29 x 58mm height x depth) CCD size 1/3 inch Pixel size 6.0 x 6.0m...
-
Page 11: Connecting Cameras To The Imagechecker
To hook up a camera, connect it to the frame grabber camera connector via the camera cable (PoCL). Please read the notes below prior to operating any of the cameras. Only use the cameras and camera cables recommended by Q.VITEC. Please refer to our homepage for a lens selection table: http://www.qvitec.de... -
Page 12: 2-Mega-Pixel Digital Camera Anpvc 1210 / 2260
Lens Use the proper lens for each camera. Make sure to use only lenses with a resolution suitable for the camera. For more information please contact Q.VITEC. The following lenses are available: ANPVL162, lens f=16 for 2-mega-pixel digital camera ... - Page 13 Table of contents rate considerably. As the transfer time is not reduced proportionally to the number of image lines used, you need to determine the transfer time case by case. Time diagram for image grabbing Important: The duration of the image grabbing depends to a large degree on the image transfer time and the shutter speed: image grabbing = shutter speed + image transfer time All camera settings like shutter speed, offset, gain, gamma, flash signal output etc.
-
Page 14: Dimensions
Table of contents 1.2.2 Dimensions 1.2.3 Specifications Feature Specification Image sensor Interline transfer method. 1/1.8" CCD, pixel size: 4.4m x 4.4m (tetragonal pixel) No. of effective pixels 1628 x 1236 pixels (horizontal x vertical) Grabbing mode Progressive scan, full image mode/partial scan mode Shutter speed 1/15 - 1/12500s Synchronous method... -
Page 15: Spectral Response
Table of contents 1.2.4 Spectral Response... -
Page 16: Quad-Speed Digital Camera Anpvc 1040
Table of contents 1.3 Quad-Speed Digital Camera ANPVC 1040 Description Additional information Lens Use the proper lens for each camera. Lens fixture C-Mount lens Mounting plate Insulation type plate. The plate can be attached to four sides of the camera. Cable connector Connects the camera cable Mini CL SDR (PoCL). - Page 17 Table of contents Time diagram for image grabbing Important: The duration of the image grabbing depends to a large degree on the image transfer time and the shutter speed: image grabbing = shutter speed + image transfer time All camera settings like shutter speed, offset, gain, gamma, flash signal output etc. are made on the property page "Camera Settings"...
-
Page 18: Dimensions
Table of contents 1.3.2 Dimensions 1.3.3 Specifications Feature Specification Image sensor Interline transfer method. 1/3" CCD, pixel size: 7.4m x 7.4m (tetragonal pixel) No. of effective pixels 659 x 494 pixels (horizontal x vertical) Grabbing mode Progressive scan, full image mode/partial scan mode Shutter speed 1/10s - 1/12500s Lens fixture... -
Page 19: Spectral Response
Table of contents 1.3.4 Spectral Response... -
Page 20: 5-Mega-Pixel Digital Camera Anpvc 1510
Table of contents 1.4 5-Mega-Pixel Digital Camera ANPVC 1510 Description Additional information DC IN connector For connecting the camera cable that also supplies power to the cam- Digital interface connector For connecting the Camera Link cable Camera cable Mini CL-SDR (PoCL) Camera Link cable Fastening screws ... - Page 21 Table of contents If you would like to use the partial scan mode, the camera needs to be programmed via the serial interface. Please contact the technical support. Time diagram for image grabbing Important: The duration of the image grabbing depends to a large degree on the image transfer time and the shutter speed: image grabbing = shutter speed + image transfer time All camera settings like shutter speed, offset, gain, gamma, flash signal output etc.
-
Page 22: Dimensions
Table of contents 1.4.2 Dimensions Unit: mm (inch) -
Page 23: Specifications
Table of contents 1.4.3 Specifications Feature Specification Image sensor Interline transfer method. 2/3" CCD, pixel size: 3,45m x 3.45m (tetragonal pixel) No. of effective pixels 2456 x 2058 pixels (horizontal x vertical) Grabbing mode Progressive scan, full image mode/partial scan mode Shutter speed 1/10s –... -
Page 24: Partial Scan Mode
Table of contents 1.5 Partial Scan Mode Here you can specify which part of the image sensor should be used for image grabbing. If you reduce the sensor area used, the image grabbing time will be shorter. The image size for a full image is 640 x 480 pixels for the quad-speed and the ultra-compact camera, and 1600 x 1200 pixels for the 2-mega camera. -
Page 27: Index
Index Index Time response ......12, 16, 20 5-mega-pixel camera ANPVC 1510 ..20 ANPC 1510 .......... 20 Dimensions ........22 Specifications ........23 Spectral response ......23 Time response ........ 20 ANPVC 1040 ........16 Dimensions ........14 Specifications ........18 Spectral response ...... -
Page 28: Record Of Changes
