Blodgett 30036RSB Specifications

RSB Series - Freezer
Freezer Base with Remote Condenser
Model 30072RSB
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Electric condensate evaporator
Cool pan drop ins
Casters (in lieu of legs)
Open frame base with caster
Project
Item No.
Quantity
Model 30036RSB (36" wide with two 27" drawers)
Model 30048RSB (48" wide with two 31" drawers)
Model 30060RSB (60" wide with two 18" drawers and two 27" drawers)
Model 30072RSB (72" wide with two 27" drawers and two 31" drawers)
Model 30084RSB (84" wide with four 18" drawers and two 27" drawers)
Model 30096RSB (96" wide with six 27" drawers)
Model 30108RSB (108" wide with two 27" drawers and four 31" drawers)
The Blodgett freezer bases support modular sectional range tops. They
keep food refrigerated until the moment it is ready to be cooked. These
"remote condenser" models connect to a separate condenser unit (not
included). Battery-design assistance is available!
Blodgett can often accommodate special or custom requirements. Contact
your Blodgett representative.
CAPACITY
Unit capacity
Model 30036RSB
Model 30048RSB
Model 30060RSB
Model 30072RSB
Model 30084RSB
Model 30096RSB
Model 30108RSB
Drawer capacity
Each 18" drawer holds one pan front to back
Each 27" wide drawer holds two pans front to back
Each 31" wide drawer holds two pans side by side
STANDARD FEATURES
Self closing heavy duty drawers slide on stainless steel rollers
Drawers hold standard sized (12" x 20" x 4") pans - not included
CFC-free refrigeration system ahs an expansion valve for rapid temperature
recovery (the remote condenser unit is NOT included)
Foamed-in-place CFC-free polyurethane insulation provides highest insulation
factor available
Self-closing drawers have easy-to-grasp handles
Rubber magnetic door gaskets provide a positive seal and easy cleaning
Stainless steel top, front, sides, back, drawers and interior cavity
6" adjustable stainless steel legs
Interior corners are coved for easy cleaning
Condensate drain (1/2" I.D. tube) with optional electric condensate evaporator
Adjustable thermostat with external dial thermometer
Mullion coils are coated to resist corrosion and provide maximum air flow for
even cooling
Operates on 120 volt, single phase, 50/60 Hz AC power
Warranty: two year parts and labor from date of purchase
BLODGETT
www.blodgett.com
1100 Old Honeycutt Road Fuquay-Varina, NC 27526 USA
Phone: (877) 255-3976 • Fax: (866) 644-1354
4 pans
4 pans
6 pans
8 pans
8 pans
12 pans
12 pans
