Summary of Contents for Lacanche LAE 413 FR
- Page 1 10-2016...
- Page 2 INSTALLING / POSITIONING on front, manual timer (0-15 mn). ELECTRICAL CIRCUIT DIAGRAM USER’S MANUAL CLEANING AND MAINTENANCE Part number LAE 413 FR 3.3 kW 230 V1N~ 50 Hz + T / E 14.3 Accessories: ► One large basket. ► One safety lid with trim cover.
- Page 3 Hob top option «LAE 413 FR» INSTALLER’S MANUAL Appliances must be installed in a workmanlike manner in accordance with the instructions in this manual and locally applicable regulations. This manual should be handed over to the user after installation. 10-2016...
- Page 4 INSTALLING/ POSITIONING ELECTRICAL CIRCUIT DIAGRAM See «Installing/ Positioning» in Cooker Installer’s manual. For references and descriptions of the various components refer to table 9 in appendix 0 All work on or repair of an appliance must be carried out by a qualified engineer. Limiting thermostat: In accordance with the construction regulations, the limiting thermostat is intended to protect the range from overheating.
- Page 5 Hob top option «LAE 413 FR» USER’S MANUAL IMPORTANT This appliance must be installed in accordance with all relevant standards and regulations in force in a room with adequate ventilation. Any change of voltage from that for which the appliance is set up must be carried out by a qualified installer.
- Page 6 Production capacity: Minimum level - Remove the basket. - Fill with good-quality frying oil up to a level between the two marks. LAE 413 FR FROZEN FRENCH FRIES* FRESH FRENCH FRIES* The oil level must be between the 2 marks.
- Page 7 CLEANING AND MAINTENANCE Before any cleaning work, isolate from the mains supply. Do not use a steam cleaner to clean the appliance. Wait until the fire tray has at least partially cooled. Draining: After any servicing it is advisable to drain only when it’s cold by slightly opening valve until oil starts to flow having previously carefully positioned a container underneath the valve.
