u s e r ' s m a n u a l
B Z E - 5 P
H a l f - D I N 5 B a n d R o t a r y C o n t r o l
P r e – A m p P a r a m e t r i c E q u a l i z e r
w i t h L e v e l C o n t r o l

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BZE5P and is the answer not in the manual?

Questions and answers

Related Manuals for Blitz BZE5P

Summary of Contents for Blitz BZE5P

  • Page 1 u s e r ’ s m a n u a l B Z E - 5 P H a l f - D I N 5 B a n d R o t a r y C o n t r o l P r e –...
  • Page 2 I N T R O D U C T I O N . . . Thank you for purchasing the Blitz Graphic Equalizer. Rest assured you have purchased a quality product designed and engineered to give YOU many years un-compromised musical service. The Blitz Graphic Equalizer has been designed using the latest in electronic technology available today.

  • Page 3: Table Of Contents

    t a b l e o f c o n t e n t s general features precautions features and specifications mounting and installation system wiring troubleshooting...

  • Page 4: General Features

    · Half-DIN Size · Output Volume Control · Input Gain Adjustments · Sub Output Frequency and Gain Control · 5 Band Graphic Equalizer · 5 Band Parametric Control · 20 Total Frequency Band Selector · Defeat Switch · Remote Power On/Off g e n e r a l f e a t u r e s ·...

  • Page 5: Precautions

    Keep all electronics away from moisture, dust, extreme heat or extreme vibrations. Blitz Audio products are capable of sound pressure levels in excess of 150dB. Continuous exposure to sound pressure levels over 100 dB may cause permanent loss of hearing.

  • Page 6: Features And Specifications

    f e a t u r e s a n d s p e c i f i c a t i o n s Front panel Line & Aux Inputs Rear panel Power Connections (+12V, Remote, Ground) Front & Rear Channel Outputs Sub Channel Outputs Aux Input Switch Parametric...
  • Page 7 1. EQ Frequency Controls These switches determine the frequencies the gain knobs on the front panel will affect. Setting a switch on one of the 5 bands on top of the equalizer permits the corresponding control on the front panel to raise or lower the gain at that frequency. 2.

  • Page 8: Mounting And Installation

    Please take the time to install your new Blitz Signal Processor securely, according to this diagram, using the hardware provided. This Half-DIN size unit can also be installed in the dash adjacent to the head unit, provided that there is a slot available.

  • Page 9: System Wiring

    Connect 12V DC from a constant battery source to a +12V slip-on spade terminal and install a one (1) amp fuse in line. Connect the signal processor’s GROUND to a good chassis ground, near where the unit is mounted, or to the case of the head unit. Connect the signal processor’s REMOTE TURN-ON lead to the remote turn-on lead out of the head unit, and install a 1/2 amp fuse in line.

  • Page 10: Troubleshooting

    T r o u b l e s h o o t i n g PROBLEM Signal processor does not turn on. Level of sound is low. Background noise is too high. POSSIBLE CAUSE • Remote turn-on wire has 12V. •...
  • Page 12 Should the product fail due to factory defects in material or workmanship, your unit will be repaired or replaced at the sole discretion of Blitz. To obtain warranty service you must first call our Consumer Return Hotline number at (718) 236-6948 to obtain a Return Authorization number.
