Summary of Contents for Tellur TLL331281
- Page 1 Wi-Fi Smoke Sensor User Manual TLL331281 For other languages, please visit smart.tellur.com...
- Page 2 Thank you for choosing Tellur! To ensure an optimum performance and safety, please read this user manual carefully before using the product. Keep this user manual safe for future references. WHAT’S IN THE BOX Please consult this checklist for all parts.
-
Page 3: Product Overview
1.PRODUCT OVERVIEW Increase your sense of security with Tellur's WiFi Smart Smoke Sensor. Having an intelligent double-checking algorithm, the device senses smoke and temperature changes and triggers the alarm. When it detects smoke, the sensor alerts you through an acoustic alarm, a light indicator and a push notification is sent to your smartphone. -
Page 4: Product Diagram
Quick guide: • Make sure the WiFi network is a 802.11 b/g/n 2.4GHz band and internet is available. • Download the app from Apple store or Google Play; • Register an account in the app and login with your email address; •... -
Page 5: Product Specifications
4.PRODUCT SPECIFICATIONS Power supply: 1 x CR123A DC 3V (included) Battery life: Up to 3 years Detection range: Up to 50 m2 Alarm level: 85dB @ 3 meters Push notifications: Yes Tamper notifications: Yes Low battery notifications: Yes History record: Yes Self test: Yes WiFi standard: IEEE 802.11b/g/n Supported WiFi network: 2.4GHz... - Page 6 5. INSTALL APP AND REGISTER AN ACCOUNT Download the Tellur Smart App for both iOS and Android OS. Scan the QR code to download Tellur Smart App Android Download App(IOS&android) Set up router This device only supports 2.4GHz frequency band router, does not support 5GHz frequency band router, please set the relevant parameters of the router before WiFi configuration, WiFi passwords do not include special...
- Page 7 6. ADD AND REMOVE DEVICE IN YOUR APP ACCOUNT 6.1 Open the app and login, Click Add Devices > Security and Sensor > Smoke Detector (Wi-Fi) to start the device adding. 6.2 Press the device button for 5 seconds to enter the Wi-Fi configuration state (fast blinking in EZ mode or slow blinking in AP mode).
- Page 8 Note: *Make sure the device and APP work in same Wi-Fi configuration mode, both in EZ mode or in AP mode. *In some case that the EZ mode is not working Wi-Fi network, AP mode is the only option. • EZ mode: make sure your APP is internet available and device and APP both work in EZ mode.
- Page 9 Click AP Mode, make sure your APP is internet available and device and APP both work in AP mode. Confirm to input the SSID and Password of Wi-Fi network, then select the Device AP name with Tellur Smart App in Wi-Fi list then back to App to finish the device adding.
- Page 10 6.6 Remove device 1) Click “Remove Device” to remove this device from your account; click “Restore manufacturer Defaults” to remove the device from your account and clear the history record in cloud. 2) After remove device or Restore manufacturer defaults from the APP, repeating the Device add steps to your account;...
-
Page 11: Product Installation
7.PRODUCT INSTALLATION •The product is only for indoor ceiling installation; •It is recommended to install this product in each corridor outside the room. If more rooms face different corridors, it is suggested to install the product in each corridor; •For the room or corridor that is longer than 12m, it is recommended to install a product at each end;... - Page 12 If the ceiling is inclined, as the top is a "dead air" area, install the device on the top of the horizontal 90cm, as shown in figure 2 90cm Figure 2 •Do not install in the bathroom, or in places accessible to water or water droplets.
- Page 13 7.1Installation Method I (Screw installation) •Mark the center point of the two holes in the bracket at the selected installation place on the ceiling or wall, drill two holes in the mark with the drill bit and insert the tapping screw to make it flush with the ceiling or wall. (Note: keep the sensor away from dust when drilling) •Use the two screws in the accessories kit to install the bracket in position.
- Page 14 Product installation Product installation alignment icon side view alignment icon front view 7.2Installation Method II (3M tape installation) •As shown in the figure below, align the product body with the bracket at an angle by referring to the "Product installation alignment icon " on the bracket.
- Page 15 Product installation Product installation alignment icon side view alignment icon back view •Use the 3M tape from the accessories kit, stick it on the back of the bracket and place the product in the desired position.
- Page 16 LED will flash RED, GREEN and YELLOW, meaning the device is working properly. During self-test the sensor will also send a notification to the Tellur Smart app. ! Important notes -The sensor will self-check for online status every 10 hours.
-
Page 17: Troubleshooting
Fault mode In case of fault alarm (such as low battery, dismantling, sensor failure), press the Test/Mute button for 3 seconds then release. The sensor will be muted for 12 hours, during which you can replace the battery, re-mount the device, self-test the sensor. - Page 18 -Re-position the sensor if there are many false alarms (non-fire alarms) -Try to clean the sensor if there are many false alarms. 9.WARNING -Always use indicated battery type, do not replace it with other battery. -Proper dispose of the battery, do not incinerate, burn, dismantle the battery.
- Page 19 Disposal and recycling information The crossed-out wheeled-bin symbol on your product, battery, literature or packaging reminds you that all electronic products and batteries must be taken to separate waste collection points at the end of their working lives; they must not be disposed of in the normal waste stream with household garbage.
- Page 20 Pentru manuale in alte limbi vă rugăm să scana i codul QR Para otros idiomas, escanee el código QR Pour les autres langages, veuillez scanner le code QR Für andere Sprachen scannen Sie bitte den QR-Code Per altre lingue, eseguire la scansione del codice QR www.tellur.com/manual-tll331281...
