By connecting the fully flexible display (FFD) and the development
motherboard to build a basic development kit, users can use the basic
development kit to carry out creative development such as building
applications or flexible interactions, with sensors included in the system for
developers to use.
1.1.1 Connection method
Royole RoKit User Manual
Advertisement
Table of Contents
Related Manuals for ROYOLE RoKit
Summary of Contents for ROYOLE RoKit
- Page 1 Royole RoKit User Manual 1. User Guidance Development model 1.1.1 Connection method 1.1.2 Connection method of expansion accessories 1.2 Flexible display mode 2. Precautions 3. Technical Support 1. User Guidance Development model By connecting the fully flexible display (FFD) and the development...
- Page 2 • Connect the components as shown. • Press and hold for 3 seconds [Power on/off button] to enter boot. • Type-C connected to the computer for development and debugging • Please use a matching adapter for power supply (not included), or through the power bank (5V2.0A).
- Page 3 FFS expansion board Microphone expansion board Optical distance sensing expansion board...
- Page 4 Power conversion board Wi-Fi antenna 1.2 Flexible display mode Assemble the flexible display by connecting the FFD and HDMI adapter board, the signal is then provided through the HDMI connection. • Connect the components as shown. • The output resolution of the host must be set as 1440*1920.
- Page 5 2. Precautions Structural FFD Lamination Structural FFS Lamination The thickness of the complete flexible display is only about 0.01 mm (10 micrometers). In order to adapt to the daily use scenarios of developers, the thickening protection treatment is carried out. Please abide by the following guidance for daily operation of the FF and FFS: 1.
- Page 6 • FFD outer/inner bending minimum bending radius The thickness of the Royole flexible display is only about 0.01 mm, and the bending radius can reach 1 mm. Taking into account the actual use of the development and application, the corresponding cover and laminate have been added to the original flexible display.
- Page 7 • FFD bending ways and area...
- Page 8 For more development guides and technical support, please visit our official website address: https://global.royole.com/us/developer-rokit Thank you for your support! Wishing your flexible ideas can become reality in your hands! Legal Disclaimer ©2021 Royole Corporation. The Royole logo, and Royole are registered trademarks of Royole Corporation. All rights reserved.
