- Page 1 BIG SHOTS® WIRELESS TRANSMITTER AND RECEIVER OPERATION AND MAINTENANCE GUIDE Artistry In Motion, Inc. 19411 Londelius Street, Northridge, CA 91324 Tel: 818.994.7388 Fax: 818.994.7688 Website:www.artistryinmotion.com Ver 08/20...
- Page 2 User acknowledges that Artistry In Motion, Inc. has not and will not conduct any investigation into the skill, expertise, training and licensing, as may be applicable or necessary by custom, usage, trade or law, of the user or of user’s agents, employees and assigns, to...
- Page 3 RECEIVER HARDWARE DESCRIPTION. The Big Shots® Wireless Receiver compact single-shot sequential UHF receiver is a highly sensitive narrow band (superhetrodyne) radio receiver designed to be used for remote control applications where high reliability is critical. When used with the Big Shots®...
- Page 4 (The Big Shots® frame has been designed so as to not interfere with the wireless signal.) If the firing position of the Big Shots® cannons Artistry In Motion, Inc.
-
Page 5: The "Battery" Indicator
The “ARM” switch has “Safe” and “Armed” positions. In the “Safe” position, the Big Shots ® Cannon cannot be fired. The “CHANNEL” switch allows the user to select either “CH A” or “CH B” as the operating channel for the receiver. This allows for two queues in the standard system. - Page 6 8 hours to fully recharge. When using the Big Shots Wireless Battery Charger it is impossible to over charge the battery. The charger has a built in circuit to detect when the battery is fully charged.
- Page 7 TRANSMITTER HARDWARE DESCRIPTION The Big Shots® Wireless Transmitter is a low power two channel, guarded toggle switch, hand-held remote control transmitter with a range of 600 feet (line of sight operation) when used with the Big Shots® Wireless Receivers. All inscriptions on the transmitter panel are luminescent to facilitate use of the transmitter in a dark environment.
- Page 8 “Safe” position while the transmitter is not being used. The key may only be removed from the switch in “Safe” position. Keys are interchangeable, as all Big Shots® Wireless Transmitters are keyed the same. THE “ARMED” INDICATOR This green lamp, located at the “Armed”...
-
Page 9: Operation And Maintenance
Be sure that the receiver is in the “Safe” mode, and select Channel A on the channel select switch. Turn the key on the Wireless Big Shots® Transmitter to “Armed” and press the “Fire CH A” button. The receiver battery light will illuminate a solid green when the transmit button is depressed. - Page 10 “BATTERY” lights on the receiver should both light up red. You should hear the solenoid valve in the Big Shots® Cannon click as it opens and closes. If the “Fire” and “Battery” lights flash red, but you do...
-
Page 11: Maintenance
418 MHZ. Because this system operates in the UHF region, interference from lamp dimmers, electrical discharges, and other natural sources is also minimal. Artistry In Motion, Inc. 19411 Londelius Street, Northridge, CA 91324 Tel: 818.994.7388 Fax: 818.994.7688 Website:www.artistryinmotion.com... -
Page 12: Specifications
Length of box 6.00 in Weight of receiver + bracket 1 lb. 14.4 oz. If further information or service is required, contact: Artistry In Motion, Inc. 19411 Londelius Street Northridge, CA 91324 818.994.7388 Artistry In Motion, Inc. 19411 Londelius Street, Northridge, CA 91324 Tel: 818.994.7388...
