QZ -CB20 User Manual

User Guide
QZ USB 3.1 Type-C to HDMI Cable
QZ-CB20

Introduction

The QZ USB 3.1 Type-C to HDMI Cable allows you to transmit video signals from a DP Alt mode enabled
Type-C or Thunderbolt 3 source to a high definition HDMI display (TV sets, projectors, etc). There is no
need for you to connect the source display to the sink display with an HDMI cable as it is already
equipped with 6ft HDMI cable. It works on Macbook or Google new Chromebook Pixel and other DP Alt
mode enabled Type-C or Thunderbolt 3 devices. You can watch videos or slideshows together on the big
screen

Package Content

QZ USB 3.1 Type-C to HDMI Cable, 6ft
Welcome Guide

Specifications

Product Name
Product Model
Material
Output Interface
Input Interface/Power Source
Alt Mode over USB Type C
HDMI Support
Cable Length
Weight
Color
QZ USB 3.1 Type-C to HDMI Cable
QZ-CB20
PVC
HDMI Male
USB-C 3.1 Male/Bus Power
DP 1.2 Alt Mode
4Kx2K@60Hz
4:4:4, 8bit with 18Gbps Bandwidth
6/8/10/12 bit color depth output
Output pixel format RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2
HDCP 2.2 & HDCP 1.4
HDR
6 ft
68 g
Black
