DaVinci IQC Product Manual

Precision herbal inhaler
Hide thumbs

Advertisement

Quick Links

Download this manual
PRECISION HERBAL INHALER

Advertisement

loading
Need help?

Need help?

Do you have a question about the IQC and is the answer not in the manual?

Questions and answers

Summary of Contents for DaVinci IQC

  • Page 1 PRECISION HERBAL INHALER...
  • Page 2 Built Responsibly Since 2012...
  • Page 3 WELCOME TO THE DAVINCI FAMILY! CLEAN FIRST ™ TECHNOLOGY DaVinci promises to build with only the cleanest componentry. No metals or plastics are used in our sealed zirconia/glass airpath providing purity to the connoisseur.
  • Page 4 KNOW YOUR IQC Mouthpiece Zirconia “Flavor Chamber” Vapor Path 18650 Battery Onboard Pick Tool LED Display Control Button Up / Down Navigation Buttons “Pearl” Zirconia Adjustable Spacer Glass Lined Ceramic Oven Access...
  • Page 5 Included: 1x IQC device, 1x 18650 (in device), 1x Battery tab (in device), 2x stickers, 1x user's manual, 1x 10mm water adapter, 1x 10mm water adapter gasket, 1x extra pick tool, 3x alcohol wipes, 1x brush tool with plastic handle, 1x 3-ft braided nylon...
  • Page 6 GET TING STARTED Open the IQC’s bottom lid to reveal the glass lined ceramic oven. Pack herb tightly for maximum vapor. Close the bottom lid to allow the pearl to firmly pack the herb.
  • Page 7 Power IQC on/off by clicking the control button five times. Adjust the temperature up and down using the navigation buttons. Choose from the four preset ranges called Smart Paths™. IQC is programmed to start in Smart Path 3 (390-410°F). IQC will vibrate when target...
  • Page 8 SMART PATH™ MODE The Smart Paths™ are preset temperature experiences that will gradually increase the temperature over an 8 minute session. Switch between Smart Paths™ by pressing the up or down buttons while in Smart Path™ mode.
  • Page 9 BODY Start temp 390°F / 199°C End temp 410°F / 210°C MIND Start temp 370°F / 188°C End temp 390°F / 199°C FL AVOR Start temp 350°F / 176°C End temp 370°F / 188°C IQC shown in Smart Path 3...
  • Page 10 IQC shown in Precision Mode at 375°F...
  • Page 11 To enter precision mode, click the control button once display temperature, then quickly adjust up or down to select your preferred temperature. DaVinci heats to within one degree of accuracy so that the user may extract active compounds at their precise boiling point.
  • Page 12 IQC shown in Boost Mode...
  • Page 13 BOOST To boost your IQC quickly to 430°F (210°C), press and hold the control button. Continue to hold the control button to maintain maximum temperature. To exit boost and return to the previous temperature, press the up or down button anytime.
  • Page 14 IQC shown in Stealth Mode...

  • Page 15: Stealth Mode

    STEALTH MODE IQC comes in Stealth Mode. To adjust LED display to full brightness, click the control and up buttons together once. Dim the LED display by clicking the control and down buttons together once.
  • Page 16 IQC shown in Fahrenheit...
  • Page 17 °F |°C TOGGLE DISPL AY Toggle between Fahrenheit and Celsius by clicking all three buttons at once.
  • Page 18 IQC showing Temp Check...

  • Page 19: Temp Check

    TEMP CHECK In order to check your IQC temperature while in Smart Path mode, press the control button once. FACTORY RESET While the device is turned off, press all three buttons and hold for 10 seconds until device vibrates.
  • Page 20 IQC showing Bluetooth ON...

  • Page 21: Bluetooth Function

    BLUETOOTH FUNCTION To turn on or off the Bluetooth connectivity directly from the device, press the up and down navigation buttons together five times within a four second time frame. Disconnecting Bluetooth when not in use will save battery life. Bluetooth will automatically disconnect from device when less than 3% battery capacity remains.
  • Page 22 IQC shown fully charged...

  • Page 23: Battery Life

    BAT TERY LIFE Press the up and down button together to check the battery level. Your IQC will vibrate when 10% remains.
  • Page 24 IQC showing USB-C Port...
  • Page 25 CHARGING THE 18650 BAT TERY Your IQC comes with a rechargeable and replaceable flat-top 18650 battery. To charge the battery while it is still in your IQC, insert the provided USB-C cable into the USB-C port on the back of the IQC...
  • Page 26 • Do not disassembled or short circuit. • Do not store your IQC or battery near heat sources. • Do not use your IQC if it is unusually hot to the touch. • Only use the DaVinci flat top 18650 battery.
  • Page 27 ONBOARD PICK TOOL Located under the upper lid and along the inner wall, the pick tool is used to: • Remove the flavor chamber • Stir and pack herbs • Remove dosage pod • Remove clogged particulates.
  • Page 28 “PEARL” ZIRCONIA ADJUSTABLE SPACER Turn the pearl to increase or decrease the oven chamber volume by up to 50%. To increase vapor density, adjust the pearl to ensure a tightly packed oven.
  • Page 29 ZIRCONIA VAPOR PATH AND “FL AVOR CHAMBER” Your IQC zirconia ceramic vapor path assists in cooling your vapor and doubles as a container for herbs. Use the pick tool to remove the flavor chamber for cleaning, filling or replacement.
  • Page 30 10 MM ADAPTER Your IQC comes fitted with a flat mouthpiece for discreet, hygienic use. For use with water filtration systems, remove the flat mouthpiece and replace with the 10mm adapter.
  • Page 31 CLEANING To keep your IQC working optimally, we recommend that all parts that come in contact with vapor are cleaned regularly. Soak the mouth piece and flavor chamber in isopropyl alcohol as needed and finish with a rinse of water.
  • Page 32 WARNINGS 1. Do not use IQC if it appears to be damaged, broken or is operating in an unusual manner. 2. This unit contains hot componentry. Use extreme caution to avoid burns. 3. Keep your IQC out of reach of children and pets.
  • Page 33 CERTIFICATIONS CE - Certificate of Conformity - EU RoHS -Product level compliance based on the European Union’s Directive 2002/95/EC, the Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment FCC - Equipment authorization issued by an FCC - recognized Telecommunication Certification Body WEEE - The European Community Directive 2012/19/EU on waste electrical and...
  • Page 34 We are not responsible for any damage and/or injury caused by the use, misuse or mishandling of the product or rechargeable batteries. IQC is not a medical device and is not regulated by the FDA. All medical diagnoses should be treated as instructed by a medical physician.
  • Page 35 If a physical defect arises and a claim is received within the warranty period, at its option and to the extent permitted by law, DaVinci Tech will either (1) Repair the product defect, or (2) Exchange the product with a product that is new or is a functionally equivalent product.
  • Page 36 Manual de Producto en Español davincitech.com/iqc-es...
  • Page 37 Manuel de Produit en Français davincitech.com/iqc-fr...
  • Page 38 Deutsches Produkthandbuch davincitech.com/iqc-de...
  • Page 39 davincitech.com/iqc-he...
  • Page 40 Nederlandse Producthandleiding davincitech.com/iqc-nl...
  • Page 41 THANK YOU for being part of the DaVinci Family. To learn about and claim your 5 year warranty, register your device at davincitech.com/register.
  • Page 42 CONNECT. SHARE. LEARN. #davincivaporizer #knowyourdose @davincivape @davincivaporizer youtube.com/davincivaporizer...

  • Page 43: Customer Support

    CUSTOMER SUPPORT 1-800-336-7224 davincitech.com/contact-us support@davincitech.com...
  • Page 44 davincitech.com...
