NX Series Reader User Guide
NX-M00C
Master Box- No RM4 with connectors.
NX-M01C
Master Box- 1 X RM4 with connectors.
NX-M02C
Master Box- 2 X RM4 with connectors.
NX-M01CA
Master Box- 1 X RM4 with connectors with Antenna connectors
NX-M02CA
Master Box- 2 X RM4 with connectors with Antenna connectors
NX-R01
Reader Box- 1 X RM4 without connectors
NX-R02
Reader Box- 2 X RM4 without connectors
NX-R01C
Reader Box- 1 X RM4 with Power and R-Net connectors
NX-R02C
Reader Box- 2 X RM4 with Power and R-Net connectors
NX-R01CA
Reader Box- 1 X RM4 with Power, R-Net and Antenna connectors
NX-R02CA
Reader Box- 2 X RM4 with Power, R-Net and Antenna connectors
This User Guide must be read in conjunction with Reader, prior to use.
Version 1.00/Draft
02/12/2019
IMPORTANT!
Advertisement
Table of Contents
Summary of Contents for Allflex NX Series
- Page 1 NX Series Reader User Guide NX-M00C Master Box- No RM4 with connectors. NX-M01C Master Box- 1 X RM4 with connectors. NX-M02C Master Box- 2 X RM4 with connectors. NX-M01CA Master Box- 1 X RM4 with connectors with Antenna connectors NX-M02CA...
-
Page 2: Table Of Contents
7.5 Real time diagnostics ................................12 Tag Manager ................................... 13 Tag Read Actions ..................................13 10.0 Tag Filters ....................................13 11.0 Alerts ......................................13 12.0 Storing Tags ..................................... 13 13.0 Sending Tags .................................... 13 14.0 NX Series Reader Specifiactions ............................14 Page 2 of 14... -
Page 3: Regularity Notices And Conformity
Consult the dealer or an experienced radio/TV technician for help Modification warning (FCC Part 15.21) Warning: Any changes or modifications not expressively approved by Allflex could void the user's authority to operate this equipment. Canada This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). -
Page 4: Antenna Warning
Allflex NX Series Operational Manual ANTENNA WARNING This device has been designed to operate with the antennas listed below. The NX Series Readers are only approved with the detachable antennas below. In accordance with RSS-GEN Issue 2 June 2007 Section 7.1.4 and FCC Part 15.21, antennas not included in this list are strictly prohibited for use with this device. -
Page 5: The Nx Series
Allflex NX Series Operational Manual THE NX SERIES The NX Reader series is available in different configurations NX-R01 NX-R02 NX-M Model Description NX-R01 Reader Box – 1x RFM. No connectors. LED indicators for power, read, exciter and high noise. NX-R02 Reader Box –... - Page 6 Allflex NX Series Operational Manual The NX Antenna series is available in different configurations NX-AP12060 NX-AP9045 NX-AP6040 NX-AP4030 NX-AW50 Model Description NX-AW30 Antenna Wand 30cm NX-AW50 Antenna Wand 50cm NX-AW100 Antenna Wand 100cm NX-AW1500 Antenna Wand 150cm NX-AW2000 Antenna Wand 200cm...
-
Page 7: Preparation For Use
Protect computer and power leads from animals if the system is left in the yards. Treat the system with care; Allflex has built this system for the cattle yards, but it is an electronic unit and must be treated accordingly. -
Page 8: Connections
Allflex NX Series Operational Manual CONNECTIONS There are two type of reader connection configurations, NX-M and NX-R. 1. NX-M Master Reader shown below as a NX-M01CA 2. NX-R Slave Reader shown as a NX-R01CA Note: There are several variants of the NX-M and NX-R which have different connector... -
Page 9: Power
The power supply must be approved for use in your country and meet all your countries emission requirements Only use high quality regulated linear power supplies or solar panels. Please contact Allflex with any queries, you may have. Some switch mode power supplies are NOT suitable and must not be used. - Page 10 Allflex NX Series Operational Manual list all files download all files G 'file' download a file time Gets the systems current time time_set Set the systems current time using the following format:dd-MM-yyyy hh:mm:ss list all deleted files dfli Deleted files info list...
-
Page 11: Bluetooth
Allflex NX Series Operational Manual 6.1 Bluetooth If Bluetooth is enabled, you can access it's settings through the home screen by pressing the Bluetooth Icon on the right side of the screen. If disabled, you will need to access Bluetooth settings through the menu. -
Page 12: Rm4/Sync Module Diagnostics
Allflex NX Series Operational Manual RM4/SYNC MODULE DIAGNOSTICS Open RM4/Sync module diagnostics, image below, through Menu --> Tools --> Noise. 7.1 Locating RM4s By pressing the ID value for a RM4, you will send a find command to the associated device. This will cause a green LED to flash allowing you to see which devices are where in your system. -
Page 13: Tag Manager
Allflex NX Series Operational Manual TAG MANAGER Tag Manager is an all in one Tag Management program for Allflex Readers. The software supports tag session reading, writing and deleting. Some readers are also configurable through the software. To get Tag Manager vist http://www.aleis.com/aleis-software-user-guides/tag-manager. Once downloaded be sure to check for updates through Help, Check for updates. -
Page 14: Nx Series Reader Specifiactions
Allflex NX Series Operational Manual 14.0 NX SERIES READER SPECIFIACTIONS General Frequency: 134.2Khz, Bit 1 124.2Khz +/-2Khz, Bit 0 134.2Khz +/-1.5khz RFID Compatibility: ISO 11784 &11785 HDX and FDX-B User Interface: RS-232 Serial Port. Bluetooth and WiFi NX-M only. RS-232 Port: 9600bps, 8 Data Bits, No Parity, 1 Stop Bit.
