Summary of Contents for Reach Bee3 Plus
- Page 1 Manual for Reach Bee3 Plus Recording Processor User Manual for the Bee3 Plus Recording Processor Document Ver. V1.0 Date of Issue 2019_07...
- Page 2 All rights reserved © SZ Reach Tech Co., Ltd. 2014, All parts of the manual, including text, picture, and graphic, are properties of SZ Reach Tech Co., Ltd. No individual or organization may copy any part of the manual in any way without the written permission of SZ Reach Tech Co., Ltd.
-
Page 3: Table Of Contents
Contents I. Overview ........................... 4 1.1 What is recording processor ................... 4 1.2 Interfaces ........................4 1.3 Main Interface ......................5 II. Connection ........................6 III. Quickstart ........................6 3.1 Recording ........................6 3.2 Layout Switching ...................... 7 3.3 Live ..........................7 3.4 File management and Replay ................ -
Page 4: Overview
I. Overview 1.1 What is the Reach Bee3 PLUS? The reach Bee3 PLUS recording processor is integrated with recording, live play and sharing, dual recording of two screens, automatic switching between pictures (single picture, picture-in-picture and picture-out-picture) and lectures, and the ability to upload recorded content to platforms such as Wowza, Youtube, Facebook, etc. -
Page 5: Main Interface
Manual for Reach Bee3 Plus Recording Processor HDMI IN 2 Video signal input 2 HDMI OUT HDMI Local output RJ45, Network connection USB 3.0 USB 3.0 Port LINE OUT Audio line out MIC IN MIC in LINE IN Audio line in... -
Page 6: Connection
Manual for Reach Bee3 Plus Recording Processor II. Connection Panel & it’s Ports III. Quickstart 3.1 Recording Start recording: Click the “Record” button on the main interface to start recording. Stop recording: Click the “Stop” button on the main interface to stop recording. -
Page 7: Layout Switching
Manual for Reach Bee3 Plus Recording Processor 3.2 Layout Switching Layout and channel switching: Click the preferred layout option on the main interface to switch the layout. Click to choose one video layout (single picture, only A or B channel), and Click to switch between screens A and B. - Page 8 Manual for Reach Bee3 Plus Recording Processor Click the forwards or backwards buttons, , in the bottom-right hand corner to choose the preferred file from the video list. Select a file from the list, , to choose the video file.
-
Page 9: Lock
Manual for Reach Bee3 Plus Recording Processor Controls for Video-playing mode are as follows: Click to switch videos during replay. Click to pause the video. Click to adjust the volume, currently just support 3.5mm audio output port for volume adjustment. -
Page 10: Setting Menu
Manual for Reach Bee3 Plus Recording Processor The lock password can be changed in the Settings Menu . 3.6 Setting Menu IV. Instructions (Setting Menu) Click the button on the main screen to go to the settings menu. -
Page 11: Input Setting
Manual for Reach Bee3 Plus Recording Processor 4.1 Input setting Click in the setting menu to enter the Audio and Video settings as shown above. 1) Audio Of the 3 choices, , click the corresponding button for the audio port being used to record and stream. -
Page 12: Output Setting
Manual for Reach Bee3 Plus Recording Processor 4.2 Output setting Click in the settings menu to find the Save, RTMP, RTSP and FTP features as shown above. 1) Save Click the save button to store recorded videos. - Page 13 Manual for Reach Bee3 Plus Recording Processor 2) RTMP With the standard RTMP protocol, it is sent to the stream media server that is installed with RTMP protocol (taking LAN as example) If a machine is installed with FlashMediaServer3.5 with an IP address of 192.168.1.195, the standard IP address under the main stream address or sub stream address could be set as rtmp://192.168.195/live/main or rtmp://192.168.195/live/sub .
- Page 14 Manual for Reach Bee3 Plus Recording Processor Choose the Type of unicast or multicast first, and then turn on the RTSP streaming by Please click OK button to save the setting at last. Watching Live: From the setting interface, you can get the RTSP link address, such as , input “rtsp://192.168.0.1:8557/main”...
-
Page 15: Encoding Setting
Manual for Reach Bee3 Plus Recording Processor Type in the FTP services information to enable the FTP upload function, and then click OK to save the setting. 4.3 Encoding Setting 1) Audio... - Page 16 Manual for Reach Bee3 Plus Recording Processor Set the Sample and Bitrate of audio, as seen in the figure and click the OK button to save the setting. 2) Video Click Main-stream or Sub-stream to choose a Streaming and Video Quality option for streaming and recording.
-
Page 17: Advanced
Manual for Reach Bee3 Plus Recording Processor Stream Type: CBR: Constant Bit Rate VBR: Variable Bit Rate CVBR: Constrained Variable Bit Rate Click OK button to save the setting. 4.4 Advanced 1) Layout Choose between the EqualRatio and Stretch options for the layout, and click OK to save the setting. - Page 18 Manual for Reach Bee3 Plus Recording Processor Here you can set the IP address, Gateway, DNS, etc. for the network settings. Reference the picture above for the following - . When is OFF: Click to input the IP address, Gateway and DNS manually and then click OK to save the setting.
- Page 19 Manual for Reach Bee3 Plus Recording Processor Click the "Up" and "Down" buttons to set the time or date and then click OK button to save the setting. 3) Screen Lock Type in the old and new passwords, and then click OK button to change the lock password.
- Page 20 Manual for Reach Bee3 Plus Recording Processor It is recommended to set them in default. 5) General System Upgrade Downloading updates by USB can be done here, but is currently unavailable. Instead, you can upgrade the newest version by Web. Type in the Web address to the Browser, and then choose the upgrading file to download it.
- Page 21 Manual for Reach Bee3 Plus Recording Processor Restore factory settings This function is currently unavailable Reboot To reboot the system, click the Reboot button once. 6) System Info You can find the system information in here, and is very important for any aftersale services.
