SP Controls Mitsubishi XL5950U Application Note

I. Driver Features

1. Command Format

This device is controlled through RS-232.

2. RS-232 Commands

Power On Source: Video
Power Off Source: S-Video
Volume Up Source: Computer 1
Volume Down Source: Computer 2

3. Other Driver Features

Default Power Status Feedback:
Projector Restart Lockout Timer (Default):

II. RS-232 Control Wiring

Wire RS-232 control to a male DB9 as follows:
SP Controls
Device
Connect male DB9 to the intermediate Mitsubishi adapter cable (not included). Connect adapter cable to
projector port labeled RS-232C.
Serial Adapters (for NRC only): A and B
Alternate Wiring: If you do not have the Mitsubishi serial adapter cable, terminate the SP Controls control
cable directly on a male 8-pin mini-DIN as follows:
SP Controls
Device
Connect the male mini-DIN to the projector port labeled RS-232C.
© 2004-9 SP Controls Inc.
Menu
Adj Up
Adj Down
Adj Left
Adj Right
Enter
None
90 Seconds
GND to 5
TX to 3
RX to 2
GND to 4
RX to 7
TX to 1
SP Controls reserves the right to modify specifications without notice at any time.
SP Controls Application Note
Mitsubishi XL5950U
P in P
Expand
Mute
Auto Position
Still
Lens Shift
Control Cable
(shown from front)
Control Cable
(shown from front)
Revision C
1 2
3 4 5
6 7
8
