Summary of Contents for SASFORKS QUICK COUPLER
- Page 1 Made in USA QUICK COUPLER ======================================= OPERATOR MANUAL ======== MANUAL v3 =====...
-
Page 2: Table Of Contents
The SAS QUICK COUPLER is not intended to lift any people and is not intended to be used with any device or object for that purpose. The SAS QUICK COUPLER is not intended to lift any object overhead of any people. -
Page 3: Introduction Letter
S.A.S. of Luxemburg, LLC, 133 Center Drive Hwy 54, PO Box 260, Luxemburg, WI 54217 USA Phone: 920-845-2198 • 1-877-SAS-FORK • Fax: 920-845-2309 • Web: www.sasforks.com © 2021 S.A.S. of Luxemburg, LLC PAGE 3 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 4: General Safety Guidelines
S.A.S. of Luxemburg, LLC, 133 Center Drive Hwy 54, PO Box 260, Luxemburg, WI 54217 USA Phone: 920-845-2198 • 1-877-SAS-FORK • Fax: 920-845-2309 • Web: www.sasforks.com © 2021 S.A.S. of Luxemburg, LLC PAGE 4 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 5: Ce Specific Notices & Emergency Stop Function
S.A.S. of Luxemburg, LLC, 133 Center Drive Hwy 54, PO Box 260, Luxemburg, WI 54217 USA Phone: 920-845-2198 • 1-877-SAS-FORK • Fax: 920-845-2309 • Web: www.sasforks.com © 2021 S.A.S. of Luxemburg, LLC PAGE 5 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 6: Serial Number Location
S.A.S. of Luxemburg, LLC, 133 Center Drive Hwy 54, PO Box 260, Luxemburg, WI 54217 USA Phone: 920-845-2198 • 1-877-SAS-FORK • Fax: 920-845-2309 • Web: www.sasforks.com © 2021 S.A.S. of Luxemburg, LLC PAGE 6 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 7: Installation
Set parking brake and turn engine off. • Follow wheel loader manufacturer’s instructions to depressurize hydraulic system. • Do not work under a lifted object, loader arms or Quick Coupler. Avoid pinch & crush hazards. • Remove existing pinned on attachment. •... -
Page 8: Optional Electric Pump Kit Wiring
S.A.S. of Luxemburg, LLC, 133 Center Drive Hwy 54, PO Box 260, Luxemburg, WI 54217 USA Phone: 920-845-2198 • 1-877-SAS-FORK • Fax: 920-845-2309 • Web: www.sasforks.com © 2021 S.A.S. of Luxemburg, LLC PAGE 8 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 9: Pre-Operation Inspection (& Maintenance)
Daily pre-operation inspection is recommended for safe use of SAS™ Quick Coupler. List below is a summary related to the Quick Coupler. This is not an exhaustive list of items to inspect. Refer to machine manufacturer’s operator manual for additional items that need to be inspected prior to machine operation. - Page 10 DAILY PRE-OPERATION INSPECTION (PAGE 10) (SUGGESTED MINIMUM INSPECTION GUIDELINES) © 2021 S.A.S. of Luxemburg, LLC PAGE 10 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021...
-
Page 11: Connecting / Disconnecting
B. Actuate hydraulic control in cab to retract Locking Pins, fully disengage from forks/bucket/tool. C. Slowly tip quick coupler forward about 20 degrees, this should be smooth with no resistance. If there is resistance, immediately stop, remove tension by small roll back, retract Locking Pins a second time to be sure they are free. -
Page 12: Repair Flow Chart
Malfunctions of equipment can result in un-expected movements from stored energy. Failure to follow safe practices can result in property damage, injury or death. SAS Quick Coupler does not work properly or work at all? Connect 3rd spool hoses 1. Are the two hydraulic hoses properly connected? Fix all leaks &... -
Page 13: Weld Notice
SAS™ QUICK COUPLER DO NOT MAKE UNAUTHORIZED WELDS TO SAS™ QUICK COUPLERS To prolong the life of the SAS QUICK COUPLER assembly, as part of the daily pre- operation inspection, be sure to closely inspect the structural framework and welds. -
Page 14: Limited Warranty
· Misuse or Improper operation – See SAS FORKS™ Operator Manual. · Exceeding the weight and/or lift limitation, lower or either any Identification Plate attached SAS Quick Coupler or wheel loader OEM capacity ratings. · Negligence or Failure to perform routine inspection and/or maintenance as outlined in the SAS FORKS™ Operator Manual. -
Page 15: Standard Sas-Euro-Iso Interface Quick Coupler F5551 & Up
PIN RETENTION SPACER SAS EURO SPACER-0625-0000 PIN RETENTION BOLTS SAS EURO WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER SAS EURO WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 15 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... - Page 16 STANDARD SAS EURO ISO VOLVO INTERFACE For Parts Contact: SAS FORKS Phone: 920-845-2307 Ext. 101 Email: parts@sasforks.com N~FLAT WASHER F5474 LOCKING PIN © 2021 S.A.S. of Luxemburg, LLC PAGE 16 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021...
-
Page 17: Custom Jrb416 Interface Quick Coupler
F5482, F5539, F6046 SPACER-0625-0000 PIN RETENTION BOLTS F5482, F5539, F6046 WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER F5482, F5539, F6046 WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 17 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 18: Custom Jrb418 Interface Quick Coupler
PIN RETENTION SPACER F5576: BOM#35 SPACER-0625-0000 PIN RETENTION BOLTS F5576: BOM#28 WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER F5576:BOM#32 WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 18 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 19: Custom Jrb420 Interface Quick Coupler
HYDRAULIC HOSE JRB420 PIN RETENTION SPACER F6040 SPACER-0625-0000 PIN RETENTION BOLTS F6040 WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER F6040 WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 19 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 20: Custom It28 Interface Quick Coupler
WASHER-F 0.375-GR8 PIN RETENTION SPACER F6074 SPACER-0625-0000 PIN RETENTION BOLTS F6074 WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER F6074 WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 20 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 21: Custom It38 Interface Quick Coupler
WASHER-F 0.375-GR8 PIN RETENTION SPACER F5469 SPACER-0625-0000 PIN RETENTION BOLTS F5469 WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER F5469 WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 21 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021... -
Page 22: Custom F6094 Interface Quick Coupler
WBOLT 0.3125X1.50 GR8 HYDRAULIC HOSE PIN RETENTION SPACER SPACER-0625-0000 PIN RETENTION BOLTS WBOLT 0.625X1.50 GR8 PIN RETENTION WASHER WASHER-F 0.625 GR8 © 2021 S.A.S. of Luxemburg, LLC PAGE 22 SAS/op/proc/forks/operator man/Quick Coupler /SAS Quick Coupler Manual v3.pub 9:52 AM 3/30/2021...
