- Page 1 INSTALLATION AND OPERATION MANUAL Quick install instructions on back cover Please leave this manual with the unit at all times Important warranty information enclosed Sonorous Model 1 4/8/2004...
- Page 2 This page intentionally left blank. Sonorous Model 1 4/8/2004...
-
Page 3: Table Of Contents
TABLE OF CONTENTS What is the Sonorous model 1? Sonorous and Messaging Provider Contact Information System Overview Front Panel Figure 1 - Front Panel Diagram Connections Panel Figure 2 - Side Panel Diagram CD Preparation Instructions Message Length Tables Installation Step 1 –... -
Page 4: What Is The Sonorous Model 1
CD to make it work. These key files are only supplied to dealers using this feature. The Sonorous Model 1 is the most versatile digital player of its kind with a list of features that includes: CD-ROM Loadable –... -
Page 5: Sonorous And Messaging Provider Contact Information
You must have this information should you require assistance installing or configuring the unit, and when you need new voice messages or background music. Sonorous and Messaging Provider Contact Information Dealer name: Contact person: Phone: Address: Serial number: (11 digits) Sonorous Model 1 4/8/2004... -
Page 6: System Overview
Open/Close Button – Opens and closes the motorized CD drawer for CD loading and removal. Status LED – Lights to indicate the current operation status of the unit. Symbols Key - Indicates the Sonorous is equipped with Sonocrypt. - Indicates the Sonorous is equipped with Sonocrypt Sonorous Model 1 4/8/2004... -
Page 7: Connections Panel
1KΩ Audio Output – Used to connect to an external audio system such as a KSU/PBX Phone System or an amplifier. Power Switch – Used to turn the unit Off/On. Power Supply – Used to supply power to the unit. Sonorous Model 1 4/8/2004... -
Page 8: Cd Preparation Instructions
™, you must burn the key file along with your .mp3 production(s). NOTE: Some audio editors embed album art or cover art into the .mp3 files. Some of these files may not be compatible with the Sonorous. Sonorous Model 1 4/8/2004... -
Page 9: Message Length Tables
In the example above, the size of the file is 3,842,048 bytes. If you divide that by 1,048,576, the result, 3.66MB, will be the size of the file in MB. On a base 16MB Sonorous, you still have 12.34MB of available memory. Sonorous Model 1 4/8/2004... -
Page 10: Installation
(which is different from a standard multi-outlet power strip) is strongly recommended. Damage caused by power surges, lightning, or other electrical problems are not covered under warranty. Figure 3 - Installation Diagram Sonorous Model 1 4/8/2004... -
Page 11: Connection Instructions
2. Connect either the 8Ω or 1KΩ audio output jack to the PA sound system input using a mono RCA-to-RCA cable (included). If the sound system does not have an RCA-style input, use the included RCA to 1/8 inch adapter. Sonorous Model 1 4/8/2004... -
Page 12: Step 2 - Load Messages
If you do decide to remove the CD, LEAVE IT OUT. Every time you insert a CD with the power switch on, all messages are erased and the CD load process begins. Sonorous Model 1 4/8/2004... -
Page 13: Message Review
This is useful for listening to the messages privately before they play over the sound system. Messages only play after they are loaded into the Flash memory. Step 3 – Adjust Volume The Volume Knob is used to adjust the volume to a comfortable level. Sonorous Model 1 4/8/2004... -
Page 14: Playback Operation
If you experience a POST failure, try turning the unit off, unplugging it and letting it sit for a few minutes. Then, plug it back in and turn it on to see if the failure occurs again. If it does, you should return the unit for service. Sonorous Model 1 4/8/2004... -
Page 15: Wall Mounting Instructions
Place the unit on a sturdy table, away from any obstructions that may disrupt its mounting. The unit may be installed in any direction; however, be sure that the area in front of the CD-ROM drawer is clear, allowing it to open completely. Sonorous Model 1 4/8/2004... -
Page 16: Technical Specifications
Power supply .......110VAC 60Hz to 15VDC 1.6A, center pin positive Audio output ........Mono RCA jack Adjustable volume control Audio output impedance....8Ω or 1KΩ Size..........3.25" x 9.50" x 9.10" (H x W x D) Color ..........Black Weight .........5 pounds (excluding power supply) Sonorous Model 1 4/8/2004... -
Page 17: Troubleshooting
Check the power switch (should be on) Check power pack for correct DC output voltage & No power-main current. power light is off Check AC source to make sure it is not controlled by a switch. Table 2 – Troubleshooting Sonorous Model 1 4/8/2004... -
Page 18: Fcc Notice
Sonorous users are fully responsible for any music, mechanical, and recording rights. This manual is copyright ©2003-2004 Nel-Tech Labs, Inc. All rights reserved. No part of it may be copied, photocopied, reproduced, translated, or reduced to any electronic medium or machine-readable form without Nel-Tech's prior written consent. -
Page 19: Limited Warranty
Please indicate the Product's serial number in all correspondence. an authorization number is not issued in the absence of a serial number. Nel- Tech Labs, Inc., 101 Zachary Rd., Manchester, NH 03109-5609, Phone: (603) 641-8844. Sonorous Model 1 4/8/2004... -
Page 20: Quick Install Instructions
2. Connect either the 8Ω or 1KΩ audio output jack to the PA sound system input using a mono RCA-to-RCA cable (included). If the sound system does not have an RCA-style input, use the included RCA to 1/8 inch adapter. For more detailed instructions, read the inside of the manual. Sonorous Model 1 4/8/2004...
