Summary of Contents for Zero COMANDO 230V
- Page 1 ZCOM230 |CONTROL PANEL | COMANDO 230V HOME AUTOMATION COMANDO zero CONTROL UNIT SLIDING GATES HOME AUTOMATION 230V IT | EN | FR ZCOM230 VER1.0 01052018_REV1 USER MANUAL AND CONFIGURATION made in italy...
- Page 2 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION zero HOME AUTOMATION...
- Page 3 12 • Light bulb connection’s output or courtesy light • ZERO SRL is not responsible for the improper use of the pro- 13 • Motor’s output - Opening duct, or other use than that for which it was designed.
- Page 4 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION M2 Connector DIP 2 - ON Enables the SOFT STOP functions Limit-switches : 01 and 02 • Make sure that the limit switches connections are DIP 2 - OFF synchronized with the L1 and L2 LEDs (see explanation in page Disables the SOFT STOP functions 4A at point 3).
- Page 5 ZCOM230 |CONTROL PANEL | COMANDO 230V HOME AUTOMATION STEP 3 DIP 7 - OFF Connect the power to the control board check if the limit-swi- Enables the reading of the closing limit-switch. tches are activated correctly. When wiring the limit-switches at 01 and 02 terminals, the L1 and L2 LEDs will remain lit.
- Page 6 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION PROGRAMMING THE WORKING TIME AND ENGINE’S PAUSE STEP 1 With the gate closed, place the DIP 9 to “ON”, press transmit- ter (already programmed) / START and the gate will start to open.
- Page 7 ZCOM230 |CONTROL PANEL | COMANDO 230V HOME AUTOMATION CONNECTIONS LED DESCRIPTIONS COLOR FUNCTION DESCRIPTION Always on. Goes off when the CLOSING LIMIT SWITCH of motor is reached. Always on. Goes off when the OPENING LIMIT SWITCH of motor is reached Comes on when the START command is activated and goes off when released.
- Page 8 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION DIP SWITCH DEFAULT (FACTORY) SETTINGS The default settings are highlighted in the boxes with grey background. SOFT STOP AFTER LIMIT SWITCH SIGNAL DIP 1 SOFT STOP BEFORE LIMIT SWITCH SIGNAL SOFT STOP FUNCTION ENABLED...
- Page 9 ZCOM230 |CONTROL PANEL | COMANDO 230V HOME AUTOMATION FLASHING LIGHT & COURTESY LIGHT CONNECTIONS PHOTOCELLS CONNECTION...
- Page 10 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION LIMIT SWITCH (GATE OPEN/CLOSE POSITION) CONNECTION NOTE: ON-BOARD MAGNETIC LIMIT SWITCH FUNCTION the control unit is equipped with a CN2 connector to accommodate a magnetic limit switch module directly welded on control panel (on demand and just for Z01 model, will be also provided two magnetic stoppers for end limit switch positions).
- Page 11 ZCOM230 |CONTROL PANEL | COMANDO 230V HOME AUTOMATION zero HOME AUTOMATION PG11...
- Page 12 ZCOM230|CONTROL PANEL | COMANDO 230V ZCOMV24 |CONTROL PANEL | COMMANDO 24V HOME AUTOMATION TROUBLESHOOTING Problem Procedure Behavior Procedure II Make sure you have 230V Door doesn’t work power supply connected to Consult a qualified ZERO tech- Still not working.
- Page 13 All ZERO control boards have LEDs that easily allow to conclude which devices are with anomalies. All safety devices LEDs (DS) in normal situations remain On. All “START” circuits LEDs in normal situations remain Off.
- Page 14 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION EC DECLARATION OF COMFORMITY: The undersigned Mr. ANDREA MARAN , representing the following manufacturer, ZERO SRL Via Roma 25/A 36077 ALTAVILLA VICENTINA (ITALIA) Declares that the equipment described below: Description: Electronic control unit...
- Page 15 ZCOM230 |CONTROL PANEL | COMANDO 230V HOME AUTOMATION zero HOME AUTOMATION PG15...
- Page 16 ZCOM230|CONTROL PANEL | COMANDO 230V HOME AUTOMATION zero HOME AUTOMATION ZERO SRLS Via Olona 110, Gallarate (VA) ITALIA info@miozero.it - www.miozero.it PG16...
