- Page 1 Changer CDC A01 Operating and Installation Instructions http://www.blaupunkt.com...
-
Page 2: Table Of Contents
(at a 45 Angle) ... 14 Installation Procedure (Suspended Installation) ... 15 GENERAL INFO Thank you for choosing this Blaupunkt product. We hope that you will enjoy it for a long time to come. Please read these Operating Instruc- tions before using the product for the first time. -
Page 3: Safety Instructions
If the information provided here is not suitable for your specific installation re- quirements, please contact your Blaupunkt dealer, your vehicle manu- facturer or our telephone hotline. SAFETY INSTRUCTIONS Tips for Safe Operation - This CD changer is designed only for... -
Page 4: Before Installing The Equipment
BEFORE INSTALLING THE EQUIPMENT Before Installing the Equipment Transport Locking Screws The mechanism in the CD changer is “locked” by the transport screws during shipping. Make certain to remove these screws before installing the changer. Note: After removing the transport locking screws, place the enclosed seals over the screw holes. -
Page 5: Position Of The Built-In
BEFORE INSTALLING THE EQUIPMENT Position of the Built-in Anti- Vibration Armature This device can be installed horizontally (suspended), vertically, or at a 45 ang- le. Once you have chosen an installation procedure, you have to set the position of the built-in anti-vibration armature accordingly. -
Page 6: Using The Changer
BEFORE INSTALLING THE EQUIPMENT For vertical installation: The built-in anti-vibration armature should be set to the “90” position. For installation at a 45 angle: The built-in anti-vibration armature should be set to the “45” position. USING THE CHANGER Using the Changer Loading a CD 1. -
Page 7: Installing The Magazine
You can load up to ten CDs. Installing the Magazine 1. Slide the cover to the right. 2. First make certain that the magazine is oriented so that the CD labels face up and so that the magazine faces in the proper direction for installation. Insert the magazine until it engages and thus is locked. -
Page 8: Handling Cds
HANDLING CDS Handling CDs New CDs The following symptoms often occur when using new CDs: - The CD does not play evenly after being inserted. - The changer changes to the next CD before it has finished playing the first - The changer plays the same CD over and over again. -
Page 9: Parts Used In Installation
HANDLING CDS 4. After use, return the CDs to their pro- tective cases to avoid major scratches that can lead to skipping on playback. 5. Never store CDs where they are ex- posed to direct sunlight, high humid- ity, or high temperatures over long periods. -
Page 10: Wiring
PARTS USED IN INSTALLATION 8-pin DIN cable Seals Double-sided adhesive tape Wiring Connect this cable to the main unit Reset Function Reset button You must use a ballpoint pen or a thin piece of metal to press the reset but- ton. -
Page 11: Installation
Installation Procedure for Installation on Carpet (Horizontal Position) - Make certain that the built-in anti-vi- bration armature has been set to the “0” position on both the right and left sides. - Using the hex bolts (M4 x 5), fasten the left and right brackets (A). -
Page 12: Installation Procedure For Installation On Carpet (Vertical Position)
INSTALLATION - Using a knife, cut through the carpet directly above the bolts of the mount- ing bracket (B). - Replace the carpet in its original po- sition, so that the bolts poke through the carpet. - Using the hex bolts again, refasten the changer on top of the carpet. - Page 13 - Lift up the carpet and decide where you want to mount the unit. - Fasten the double-stick tape sup- plied to the bottoms of the brackets (B) and remove the protective back- ing from the tape. - Fasten the unit to the floor by press- ing it down firmly.
-
Page 14: Installation Procedure For Installation On Carpet (At A 45 Angle)
INSTALLATION Installation Procedure for Installation on Carpet (at a 45 Angle) - Set the built-in anti-vibration arma- ture to the 45 position “45” on both the right and left sides. - Using the hex bolts (M4 x 5), fasten the left and right brackets (A). - Fasten the left and right brackets (A) to the corresponding brackets (B). -
Page 15: Installation Procedure (Suspended Installation)
- Using a knife, cut through the carpet directly above the screws of the mounting bracket (B). - Replace the carpet in its original po- sition, so that the screws poke through the carpet. - Using the hex bolts again, refasten the changer on top of the carpet. - Page 16 INSTALLATION Determine where you want to install the unit and drill four mounting holes. - Fasten the CD changer using the tap screws (M5 x 12). 3,6 ø...
- Page 17 09-435 99236 01-4010 7320 01-89583 8394 01-576 9473 01-4598830 02-369 6464 40 2085 023-565 6331 66-817 157 01-2185 11111 916-467952 08-7501810 01-8471650 02-6130 0514 01-324 8756 022-8771260 0212-3460040 708-6817188 +604-6413 640 Blaupunkt GmbH CM/PSS 8 622 403 245 WWW: http://www.blaupunkt.com...
