Aquaglide Rebound Owner's Manual page 2

Assembly
1) Locate a flat, dry area with access to electrical outlet or extension cord.
2) Unroll and place the Slide on the ground next to the Rebound and
inflate to 0.08 psi. Inflation times can vary by inflator, but the slide
should be firm and tight when completely inflated. In hot weather, be
sure to leave room for air expansion, or let air out if it becomes too hot.
DO NOT OVER-FILL. After inflation, screw the valve cover on
tightly - be careful to align the threads of the cover to avoid stripping.
3) Attach the Slide to the Rebound using the 4 Interloc straps as shown in
the diagram below.
4) Do NOT drag the slide or any other Aquaglide product into the water.
Carefuly carry the products into the water to prevent punctures and
leaks.
Warning: Do not use an air compressor to inflate
tube. Air compressors are designed for high
pressure inflation and can cause the Slide to burst
if over-inflated, or cause damage to the strap
attachment.
Interloc Strap Assembly Instructions
1) Install the 4 Interloc straps to the Rebound to the 4 rings
on one side of the bouncer. Insert the velcro end of the
strap through the other end (looped end) and cinch in
place. Make sure that the white Interloc logos on the
velcro are facing up.
2) Thread the end of the interloc strap through the two
D-Rings on the Slide, then back through a single ring.
3) Pull all the webbing through the rings until the white arrow
of the interloc logo stops at the d ring below. Cinch until
it is tight.
4) Pass the end of the webbing back through the open area of
the D-Rings on top as shown.
5) Now bring the webbing through the opening in the single
D-Ring on the Slide as shown (A).
6) Fold the strap over onto the velcro (B), and Place the other
velcro tab in place to lock the strap (C)
Aquaglide Inc. #1 North Shore Dr, SE White Salmon, WA 98672 TEL: (509) 493-4938
C
B
A
for more information go to:
www.Aquaglide.net
FAX: (509) 493-4966
Rebound Slide Owners Manual
Aquaglide, Inc. #1 North Shore Dr, SE White Salmon, WA 98672 TEL: (509) 493-4938
Operation
1) Place the Slide in at least 8 ft. of water depth and in an area protected from
the wind and boat traffic. Review your lake rules and restrictions with
your local authorities. Make sure the Slide is securely attached to the
trampoline or bouncer. Always check the security of the straps periodically
during use
2) Carefully check area under the Slide for sharp or dangerous objects (i.e.
rocks or stumps).
3) Keep a safe distance from docks, boats, boat lifts, and any other structures.
DO NOT tie the Plunge to a dock! Do Not use the Slide except when
attached to an Aquaglide Rebound bouncer.
Care and Maintenance
1) While your product has been initially treated with UV protectant, long-term
exposure to sunlight will damage the product. Regularly apply a UV protec-
tant to the exposed surface of the tube to ensure the life of your product. We
reccomend using ONLY 303 UV Protectant intended for use on vinyl for this
purpose. Monthly application while the product is in use is required. NOT
DOING THIS WILL VOID THE WARRANTY. 303 UV Protectant is
available at most watersports dealers, or online at www.303-products.com.
2) WARNING: Certain products, especially petrolium-based solvents, clean-
ers and protectants such as ArmorAll can damage the product and use of
these products will void the warranty.
3) WARNING: Use of a high-pressure washer will damage the product and
void the warranty. To clean, use a soft bristle brush with mild soap and fresh
water. 303 UV Protectant contains a 'safe for vinyl' cleaner, and can be used
to clean and protect the product at the same time.
4) Check the inflation of your tube often. It may appear to have lost air early in
the morning, but will expand once the sun warms it. Maximum expansion
will occur in the heat of the day. Under-inflation can cause excessive rubbing
where the metal frame rests on the tube. Proper inflation is important as this
will discourage rodents from chewing and prevent damage from wear.
Storage
1) Before storing, place the Slide on a clean, level area. Clean with mild soap
and water and allow to dry completely. Apply 303 Protectant to the surface
of the tube and spring pad cover before deflating.
2) Remove ALL of the air from the tube using the deflation end of the high
output inflator/deflator. If some air is left in the tube, it may freeze causing
cracking.
3) Remove ALL of the air from the tube using the deflation end of the high
output inflator/deflator. If some air is left in the tube, it may freeze causing
cracking.
4) Store the Slide out of direct sunlight and protected from the environment in
a clean, dry location. It is best to store inside a container with moth balls to
prevent damage from rodents. NEVER store uncovered, in a damp location,
or on a concrete surface! NEVER store at temperatures below 40 degrees F.
