DOA-Nr.: EASA.21J.360
Subject:
Aircraft type affected:
Serial numbers affected:
Compliance:
Time of Compliance:
Purpose:
Background:
Manpower:
Materials:
Accomplishment instructions:
1. Disconnect the right hand (rh) and left hand (lh) aileron rod (XA42-2710-114) from aileron
bellcrank (XA42-2710-050) in the fuselage by removing the AN4-11 bolt connection.
2. Remove the rh/lh spade arms (XA42-5760-121).
3. Remove the sighting devices (XA42-5770-001).
Replaces Service Bulletin No. / Date:
Not applicable
XtremeAir GmbH, Harzstr.2, D-39444 Hecklingen
Tel: +49 39267 60999 0, Fax: +49 39267 60999 20
www.xtremeair.de info@xtremeair.de
Service Bulletin SB-2013-002
MANDATORY
Fuel Vent
XA41 and XA42
MSN 01 through 06, and 101 through 114
Mandatory
next 100 hours
To notify owners of above aircraft of a potential flight safety
condition.
The transparent fuel vent hoses installed in the aircraft listed
above have unsatisfactory ageing characteristics.
The present service bulletin provides instructions for the
installation of improved fuel vent hoses.
It is estimated approximately 25-30 man-hours will be required to
accomplish this bulletin.
The following material should be ordered through
spares@xtremeair.de:
10 m blue vent line
(1) ea. firewall assy. XA42-7130-180
(1) ea. thermal blanket XA42-7130-202
(1) ea. bulkhead fitting fuel XA42-2820-216
(2) ea. bulkhead fitting brake line XA42-3280-245
(1) ea. starter cable guide XA42-7100-206
in addition the following consumables are required:
•
RTV 106 sealant
•
Epple 33 adhesive
•
Locking wire MS20995C-32, 0,8mm
Document No.
SB-2013-002
A.01
Issue:
Date:
15.4.2013
Page 1 / 8
