TechBrands LA9014 User Manual

Obdii gsm/gps tracker
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
1.
Insert a SIM card (not included) into the SIM card slot located beside the case (Press yellow button to release).
Note: 4G SIM cards are acceptable to use with this device however the unit only operates on a 2G band.
This unit requires data to be activated on your pre-paid or contract SIM card.
(Recommend order 20-30M/Month data package)
2.
Insert the tracker into the OBDII socket (mostly located under the car panel,12V or 24V vehicle compatible ), the
tracker will power on automatically.
3.
Contact your mobile service provider to obtain the APN "name" in order to view the location on the tracking website.
APN's vary depending on your SIM card's plan (i.e. pre-paid or contract)
4.
Enter the following command via SMS on your the tracker to set the APN "name":
Send SMS "APN*123456*apnname" (123456 refers to the default password)
For example:
Plan: Vodafone Pre Paid
APN "Name": live.vodafone.com
Send SMS: APN*123456*live.vodafone.com
If the APN "Name" has been entered correctly, you will receive a SMS stating "APN:live.vodafone.com"(example)
Note: The APN "name" needs to be entered correctly otherwise the location may show up in China, Africa, etc.
5.
Login to the tracking website (www.responsegps.com) using the last 7 digits of the serial number for the username
and password which is located in the battery compartment of the tracker.
For example:
Serial number: CC2014012345678
Username: 2345678
Password: 2345678
6.
Free "Response GPS" app is available on iTunes® and
current tracking location on your iOS® or Android smart phone or tablet.
App name: ResponseGPS
LA9014 OBDII GSM/GPS Tracker
User Manual
Quick Guide
www.responsegps.com
tracking platform to easily view the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LA9014 and is the answer not in the manual?

Questions and answers

Summary of Contents for TechBrands LA9014

  • Page 1 LA9014 OBDII GSM/GPS Tracker User Manual Quick Guide Insert a SIM card (not included) into the SIM card slot located beside the case (Press yellow button to release). Note: 4G SIM cards are acceptable to use with this device however the unit only operates on a 2G band.

  • Page 2: Basic Functions

    Basic Functions: GPS Tracker Power Indicator Light OBD Interface SIM Card Slot Specification OBD interface, no installation charge  Diagnostic Car Status (reply by SMS)  Auto download & configuration setting for APN & GPRS   SMS balance checking for Tracker SIM card ...
  • Page 3 out of power and the tracker will switch off automatically. 2. Install SIM card Press the push button beside the SIM car slot, the SIM card holder will pop out as shown in the image. Place the SIM card in the holder by leaving the metal pin side face up and then push the holder back into the tracker.

  • Page 4: Installation

    & password again by SMS. Installation 1. Obtain a 2G GSM phone SIM card that needs SMS service, incoming caller ID display, and GPRS function. Please disable the PIN code of the SIM card, this SIM card phone number is the tracker number and all other operations (calling and sending SMS) for the tracker.

  • Page 5: Setting Instruction

    username & password by sending SMS. You can check the APN & GPRS username password by sending SMS “CHECK*123456” to tracker, Send SMS “APN*123456*apnname” to the tracker can set the APN, and send SMS “USERNAME*123456*username*password” to the tracker can set the GPRS username &...
  • Page 6 Send SMS “IP*123456*58.64.155.133,8011” to the tracker, in which, “IP” is the fixed command, “123456” is the password and “58.64.155.133,8011” is the IP address of the server computer of our website. Once it is successfully done, there will be a SMS “IP: 58.64.155.133, 8011”. However, the IP address may be changed with the upgrade of our server, please see the notices on our website.
  • Page 7 means sending SMS. Having successfully done, there will be a SMS “Balance Mode: SMS”. Send SMS “BALANCEMODE*123456*CALL” to the tracker, it means calling USSD command number to check balance, in which, “BALANCEMODE” is the fixed command, “123456” is the password and “CALL” means calling USSD number. One it is successfully done, there will be an SMS “Balance Mode: CALL”.
  • Page 8 can not send to user by SMS (alarm information, battery low, SOS, etc). 5.1. Add authorized phone number by SMS Send SMS“ADDPHONE*123456*A*number”(Not including the quotation marks “ ”, number means the telephone number you want authorized, the following is same) to tracker is OK, “ADDPHONE” is a command;...
  • Page 9 7. Set Alarm by Calling: ON/OFF Send SMS “CALLON*123456” (Call to authorized number) or “CALLOFF*123456” (No calling) to the tracker, “CALLON” or “CALLOFF” is a command, “123456” is the tracker password, if the operation is success, the tracker will send back the information “Alarm by calling: ON” or “Alarm by calling: OFF”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”.
  • Page 10 tracker stop moving, the tracker will stop upload the tracking and turn off GPS & GPRS to go to sleep mode, a few minutes later the tracker status on the platform also will change to offline. If the tracker is always online, the tracker will send tracker status to platform all the time, but this will exhaust more data charge and car battery power, and if the car will park long time or the car battery is old, this maybe cause the car battery power low and cannot start car engine, we do not recommend this working mode.
  • Page 11 send back OBD & car status information”, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. OBD information example: Number of DTCs: 1, P0340, Car voltage: 13V, GPS battery 66%. The detail information of the DTC please see the car owner book, the different model car has different DTC, the 4S or fixing factory can diagnostic your car by mobile phone.
  • Page 12 Send SMS “RESET*123456” to tracker can make the tracker power off and power on again, “RESET” is the fixed command, “123456” is password. The tracker will send back information “Cancel all alarm setting and re-power on”, then the tracker will power off and power on automatically, if the password is not right, the operation is fault, and the tracker will send back information “Wrong Password”.
  • Page 13 phone calling can trigger the tracker to locate immediately, if the tracker has authorized number, then only authorized phone calling can trigger the tracker to locate immediately. The SMS information sample is as follow: Send SMS “LOCATE*123456” to the tracker, “LOCATE” is a command, “123456” is password. If the operation is success, the tracker will send back the information as above.
  • Page 14 Google® map will display like above, the SMS example is as follow: No GPS signal, Just Cell ID Location: http://maps.google.com/maps?q=N22.6775,E114.1518 Note: this location is locate by GSM base station ID, the precision is not very high, in the city maybe 30-50 metres, in the country may be over 1 km, so the location is only used for reference. If the cell ID cannot get the location either, the tracker will reply “Cannot get location, please try again later”.
  • Page 15 If the authorized number has been set, use the authorized phone number to send SMS “DISARM#” to the tracker also can trigger the tracker to enter arm state. 6. Set Move Alarm by Sending SMS Send SMS “MOVEALARMON*123456” (Enable move alarm) or “MOVEALARMOFF*123456” (Disable move alarm) to the tracker, “MOVEALARMON”...
  • Page 16 number. If the tracker is triggered continually, every authorized phone will receive max 3 alarm SMS per hour. The geo-fence alarm SMS is as follow: Geo-fence Alarm https://maps.google.com/maps?q=22.67680N,114.15188E Battery: 88% After disable the move alarm, the system will not check distance again. Also send SMS “CANCELALARM*123456”...

  • Page 17: Platform Operation

    cancel all the alarm setting include Shock Alarm / Move Alarm / Geo-fence Alarm / Over Speed Alarm, if the password is not right, the operation is fault, the tracker will send back information “Wrong Password”. 11. Monitor Sound in Car Send SMS “MONITOR*123456*13987654321”...

  • Page 18: Troubleshooting

    card support 2G GSM network or not. 2. Please confirm that the SIM card PIN code has been disabled, otherwise the tracker cannot find GSM network, and the Green LED will keep ON. 3. Also please confirm the SIM card has enable GPRS service(Some SIM card need send SMS to enable the GPRS data service), the tracker will cost 20-30M GPRS data every month, order a GPRS data package can save money.

  • Page 19: Specifications

    C to +55 Absolute Temperature C to +70 Storage Temperature C to +80 Distributed by: TechBrands Electus Distribution Pty. Ltd. 320 Victoria Rd, Rydalmere NSW 2116 Australia Ph: 1300 738 555 Int’l: +61 2 8832 3200 Fax: 1300 738 500...
