Introduction

About This Manual

General notes

Using this manual

Read Carefully

About trademarks

Warning

About pictures and images

Software Usage Contract

Chapter 1 Before Use

Chapter 2 Capture Environment

Chapter 3 Album Environment

Chapter 4 Movie Editing Environment

Chapter 5 Layout Environment

Chapter 6 Image Editor

Chapter 7 Video Disc Environment

Chapter 8 ImageMixer Easy Video

CD (Win)

Introduction

General notes

This manual is an HTML document which explains the functions of ImageMixer Ver.1.5 for

Sony

(henceforth, 'ImageMixer').

This manual does not explain the basics of Windows or Macintosh operating systems. Basic

operations, such as working with individual windows, are based on general usage of Windows

and Macintosh.

Screenshots may differ slightly depending on each company's bundling of this product.

Most screenshots currently used in this manual relate to the Windows version. The screenshots

for Windows and Macintosh differ slightly. Moreover, images may vary according to monitor

specifications.

Due to the fact that the most recent information related to this software has not been added to the

manual, please consult the Read Me file, included on the CD-ROM.

Using this manual

This manual explains all ImageMixer's many

(table of contents) displayed on left-hand side of the screen.

Blue text

indicates a link. Clicking it will display the relevant item.Once that item has been

displayed, the link will appear in

The end of the page can be referenced by clicking

The beginning of the page can be referenced by clicking

The preceding page (or preceding item) can be referenced by clicking

The following page (or following item) can be referenced by clicking

Issues of particular importance are indicated in

Homepage

The latest information on ImageMixer can be found on our home page:

http://www.ImageMixer.com/

About This Manual

functions.

purple

text.

red

Any item can be referenced by clicking the menu

text. Please read them carefully.
