Edge Electrons EDGEIQ EE-202-0050 Installation, Commissioning And Operation Manual

Single phase series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALL THE
WORLD'S BEST
VOLTAGE
OPTIMISATION
TECHNOLOGY
1
2
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDGEIQ EE-202-0050 and is the answer not in the manual?

Questions and answers

Summary of Contents for Edge Electrons EDGEIQ EE-202-0050

  • Page 1 INSTALL THE WORLD’S BEST VOLTAGE OPTIMISATION TECHNOLOGY...
  • Page 3 EDGEIQ I N S T A L L A T I O N, C O M M I S S I O N I N G A N D O P E R A T I O N M A N U A L EE-202-0050 SINGLE PHASE SERIES...

  • Page 4: Table Of Contents

    Location ............................... 3 1.4. Wiring ..............................4 1.5. Edge Electrons ........................... 5 ‘M U S T G E T’ I N F O R M A T I O N ....................6 2.1. For the customer to register their unit ..................... 6 2.2.

  • Page 5: N S T R U C T I O N S A N D W A R N I N G S

    I N S T R U C T I O N S A N D W A R N I N G S BEFORE commencing installation or commissioning, please read completely through this manual and follow all warning statements. This manual contains important information. Failure to read and follow all instructions prior to performing the installation and operation will void the product warranty and could also cause serious personal injury, fire hazards and electric shock, which may lead to death.

  • Page 6: Wiring

    This manual provides specific wiring instructions for installations that have a single phase supply only. Note: If your installation has a two phase supply, three phase supply or battery inverter, we recommend you contact your Edge Electrons representative to discuss alternatives. 1.4.2. Termination to the unit internal breaker rating 1.4.3.

  • Page 7: Edge Electrons

    Any warning provided by Edge Electrons must be passed through to the end user. Edge Electrons offers a warranty only as to the quality of its product to conform to the catalogue specifications. No other warranty is offered.

  • Page 8: M U S T G E T' I N F O R M A T I O N

    ‘M U S T G E T’ I N F O R M A T I O N Electrical contractor must complete the below information and return this page to Edge Electrons at customersupport@edgeelectrons.com as soon as possible after commissioning the unit. Receipt by Edge is required to validate the Edge Electrons product warranty.

  • Page 9: I N S T A L L A T I O N ' M U S T D O ' S

    Installation is re-energised  Perform handover to customer – including supply of Certificate of Electrical Safety  Complete ‘Must get’ information (See page 6) and email to Edge Electrons  (customersupport@edgelectrons.com). Non-receipt of this information can impact the product warranty Site monitoring ...

  • Page 10: E Q U I P M E N T A N D P A C K A G I N G

    E Q U I P M E N T A N D P A C K A G I N G 4.1. Front case labelling Mounting slot Vents LED indicator Antenna Terminal box and cover 4.2. Dimensions E D G E I Q H A N D B O O K...

  • Page 11: Packing List

    4.3. Packing list Do not commence installation of the EdgeIQ if there is any visible breakage, loose connections and/or missing parts. Any missing or broken components from the below list must be notified to Edge Electrons immediately after unpacking the unit.

  • Page 12: I N S T A L L I N G T H E E D G E I Q

    I N S T A L L I N G T H E E D G E I Q 5.1. Mounting: Indoor/outdoor use, IP54 enclosure Prior to mounting the EdgeIQ onto a wall, select which side of the circular knockout to remove from your chosen cable entry for the unit.
  • Page 13 Note: The EdgeIQ must have MINIMUM CLEARANCE around the unit (to ensure efficient performance) as shown in Diagram 2: Minimum clearance location for EdgeIQ on page 12. Fan outlets and side exhaust vents on the EdgeIQ unit must ALWAYS remain clear and free of obstruction Diagram 1: Installing mounting screws 1.Drill an 8mm hole on the wall, 35mm depth...

  • Page 14: Wiring The Edgeiq

    Diagram 2: Minimum clearance location for EdgeIQ 5.2. Wiring the EdgeIQ A. Remove the 8 screws - 6 at the front and 2 underneath the terminal box - to disassemble the front cover. A diagrammatical explanation of steps B to E below is shown in Diagram 3: Wiring. B.

  • Page 15: Conduit Fitting

    the CT clamp around the AC wire that supplies the solar inverter on the installation. This is to monitor the output of the solar inverter. E. Install the modem into the USB socket. (Refer to Section 6. Communication Kit Installation for instructions).

  • Page 16: Power Connection To Main Switchboard

    5.4. Power connection to main switchboard A. Ensure the main isolator is OFF to completely isolate the EdgeIQ Unit. Important: Each incoming power supply, along with any additional grid tie/solar power/battery and any other embedded generator source on the electrical installation MUST each be safely isolated before commencing the electrical wiring work B.
  • Page 17 5.4.1. Diagram 4: Wiring for SINGLE phase standard installation without a Solar Inverter E D G E I Q H A N D B O O K...
  • Page 18 5.4.2. Diagram 5: Wiring for SINGLE phase standard installation with a Solar Inverter E D G E I Q H A N D B O O K...

  • Page 19: Solar Inverter Current Transformer (Ct) Connection (Where Applicable)

    5.5. Solar inverter current transformer (CT) connection (where applicable) • Install the split core current transformer onto the AC live wire output of the solar inverter incoming to the switchboard. • The arrow mark on each CT must be in the direction of current (pointing towards breaker box). •...
  • Page 20 C. Install the communication antenna onto the threaded SMA connector D. Comms indicator lights-up with power. See Table 2: Modem status LED colours to determine connection is made. Table 2: Modem status LED colours Green, blinking twice every 3s The USB stick is powered on. Green, blinking once every 3s The USB Stick is registering with a 2G network Blue, blinking once every 3s...

  • Page 21: A T T A C H S A F E T Y L A B E L S

    A T T A C H S A F E T Y L A B E L S The following safety labels must be attached for all installations with solar, prior to commissioning the unit, to inform other electricians who attend the site after the installation of the EdgeIQ. 6.1.

  • Page 22: Appendix A : P R O D U C T I N F O R M A T I O N

    A P P E N D I X A : P R O D U C T I N F O R M A T I O N Product Name EdgeIQ Product model number EE-202-0050 Series Configuration 5KVA, Single Phase, 240 VAC Serial number EE-202-0050-005-0000001 to EE-202-0050-005-999999 Input Voltage...

  • Page 23: Appendix B : C O M M I S S I O N I N G C H E C K L I S T

    Note: Both the input and output of the EdgeIQ must have an earth connected (at the same potential) The screw holding the cable of line and neutral has been correctly torque. (torque setting: 20.4Kgf.cm minimum) M2M modem should be connected to the correct port as shown on sticker in unit Please tick when this step is completed: Note: Port for the M2M modem (dongle) is the back...
  • Page 24 Note: Both the input and output of the EdgeIQ must have an earth connected (at the same potential) The screw holding the cable of line and neutral has been correctly torque. (torque setting: 20.4Kgf.cm minimum) Please tick when this step is completed: M2M modem should be connected to the correct port as shown on sticker in unit Note: Port for the M2M modem (dongle) is the back...
  • Page 25 Perform continuity test and confirm that polarity Please tick when this step is completed: is correct for all cables Line Note: Do not close cover of the EdgeIQ unit yet as Neutral further test required Earth Perform visual inspection: Please tick when this step is completed: Check that all cables are secure and undamaged, cable support systems and cable protection are also secure and undamaged.
  • Page 26 With installation isolated at main switch, perform an external earth fault loop impedance test Result :___________________ Ohms Ze between incoming active supply (line side terminal (External impedance) of main switch) to the main earthing conductor: Result :______________________ Amps 1. Disconnect main earthing conductor from the earth bar in the main switchboard.
  • Page 27 If status LED does not turn green within 5 minutes, turn-off the main isolation switch supplying the EdgeIQ and return to items A1 to A5 Please confirm active to neutral voltage on the With the status LED green: Measure the voltage between active and neutral on the input EdgeIQ input terminals are between 216v and terminals, check the input voltage is reading...
  • Page 28 If solid blue signal cannot be obtained, re-check the signal strength of the VODAFONE to the installed site. If signal is still low on Vodafone signal coverage map, consult Edge Electrons for possible solution. Please tick when this step is completed: Turn-on all circuit breakers at the main.
  • Page 29 Please confirm Active to Earth voltage on the With the status LED green, measure the voltage Edge IQ output terminals is 230v: between Active and earth on the Edge IQ output, confirm that the output voltage is reading 230V With the status LED green, measure the voltage Please confirm that input voltage between neutral between neutral and earth on the input terminals and earth is approximately zero volts:...

  • Page 30: Appendix C : E D G E I Q L E D S T A T U S I N D I C A T O R S

    A P P E N D I X C : E D G E I Q L E D S T A T U S I N D I C A T O R S LED Status Indicators LED Response EdgeIQ Status Steady Green EdgeIQ is online and is in regulation mode...
  • Page 32 CO N TA C T For more information about EdgeIQ, or to get a free quote, please call 1300 334 329 or email customersupport@edgeelectrons.com...
