- Page 1 T h e E m o t i o n o f M o t i o n Installation Guide Power enhancement Iveco Eurostar 470 EDC 13.6 Euro 2 345 kW...
- Page 2 Our aim is to supply you with results, not only products. Thank you for choosing to buy from STEINBAUER. T h e E m o t i o n o f M o t i o n .
- Page 3 To be able to take the benefits of all technical advantages of your newly purchased STEINBAUER Additional electronic, please consider the following advices. Do not use the STEINBAUER Additional electronic before you have read and understood Please read all instructions carefully before installation.
-
Page 4: Installation
“Important information”. See “Important information”. How it works The STEINBAUER Fuel saver modifi es the injection system by fi ne tuning the duration of the injectors. The fuel injection and engine speed are recorded and recalculated to optimize performance. Installation Connect the wiring loom of the ECU´s connector to... - Page 5 Start ignition and measure voltage to find the correct wire. (see measurement) Reference signal wire STEINBAUER Power enhancement Air pressure sensor Connection via “Electronic pedal sensor”, alternative method Solder the reference signal wire on the wire of the electronic pedal sensor.
- Page 6 “bucking”, stop or emergency mode of engine (severe less power) or fl ashing of defect control lights. You can remedy these problems by fi ne adjustment of the STEINBAUER Additional electronic with the Potentiometer. The adjustment of the Potentiometer does not adversely eff ect the power enhancement.
-
Page 7: Remote Control
Negative (-) terminal. Part no. 200089. Remote Control Connect the grey wire of the remote control to the Battery Switch wire (grey wire of the STEINBAUER Additonal Wires for electronic). power supply Switch wire... -
Page 8: Terms And Conditions
The dispatch is always at the expense and risk of the customer. The risk with delivery ex works or from storage pass vides the evidence that failures have been caused by Steinbauer Tuning Technologies Austria GmbH or have been to the customer, even if the supplier has taken over the extradition. If shipment is delayed through the fault of the caused at least wantonly negligent. - Page 9 . s t e i n b a u e r . c c HEAD QUARTER: STEINBAUER Tuning Technologies Austria GmbH Neu Gablonz 5 4470 Enns T: +43 / (0)7223 / 811 75-0 F: +43 / (0)7223 / 811 75-40 E: info.at@steinbauer.cc...
