AEG LAVAMAT 84950 Instruction Booklet

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LAVAMAT 84950
Instruction booklet
Washing machine

Advertisement

Table of Contents
loading

Related Manuals for AEG LAVAMAT 84950

Summary of Contents for AEG LAVAMAT 84950

  • Page 1 LAVAMAT 84950 Instruction booklet Washing machine...
  • Page 2 Dear Customer Thank you for choosing one of our high-quality products. With this appliance you will experience the perfect combination of functional design and cutting edge technology. Convince yourself that our appliances are engineered to deliver the best performance and control - indeed we are setting the highest standards of excellence.

  • Page 3: Table Of Contents

    Contents Contents Instruction booklet Safety information Product Description Detergent dispenser drawer Control panel Display 12-13 First use Setting the language Setting the time Personalization Setting the brightness Setting the contrast Setting the acoustic signal Return to main menu Daily use Load the laundry Measure out the detergent and the fabric softener Select the required programme...
  • Page 4 Indice Select the CHILD LOCK option Select the TIME SAVING option Select the START/PAUSE Select the DELAY START Altering an option or a running programme Interrupting a programme Cancelling a programme Opening the door after the programme has started At the end of the programme Washing programmes 24-27 Programme information...
  • Page 5 Indice Emergency emptying out Something not working 39-43 Technical Data Consumption value Installation 46-50 Unpacking Positioning and levelling Water inlet Water-stop device Water drainage Electrical connection Enviroment concerns Packaging materials Old machine Ecological hints Guarantee Customer service centres...

  • Page 6: Safety Information

    Instruction booklet Safety information Prior to using for the first time The safety of AEG/ELECTROLUX appliances complies with the industry ● standards and with legal requirements on the safety of appliances. However, as manufacturers, we feel it is our duty to provide the following safety notes.
  • Page 7 Safety information Wash small items such as socks, laces, washable belts etc in a washing bag or ● pillow case as it is possible for such items to slip down between the tub and the inner drum. Do not use your washing machine to wash articles with whalebones, material ●...
  • Page 8 Safety information This appliance is designed for domestic use. It must not be used for purposes ● other than those for which it was designed. Only wash fabrics which are designed to be machine washed. Follow the ● instructions on each garment label. Do not overload the appliance.
  • Page 9 Safety information Make sure that children or pets do not ● climb into the drum. To avoid this the machine incorporates special feature. To activate this device, rotate the button (without pressing it) inside the door clockwise until the groove is horizontal. If necessary use a coin.

  • Page 10: Product Description

    Product description Product description Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Rating plate Detergent dispenser drawer Drain pump Control panel Three adjustable feet; The rear Drum light foot on the left-hand side is Door opening handle automatic Detergent dispenser drawer...

  • Page 11: Control Panel

    Control panel Control panel Henceforth the programme selector dial, the buttons and the display will be indicated with the numbers given in this table. ALGODÓN MEMORIA 1 MEMORIA 2 ANTIBACTERIAS ALGODÓN ECO 40-60 MIX TEJIDOS EXPRESS INT. GRUESOS 20 MIN - 3KG SINTÉTICOS PLANCHA OUTDOOR...

  • Page 12: Display

    Chapter Repetition Display (7) COTTONS/LINEN 01:40 Press START to run 13:05 program Temperature - symbol Spin Speed, Rinse Hold , Night Cycle - symbols CHILD SAFETY LOCK - symbol TIME SAVING (Daily) (Super Quick) - option symbols DELAY START - symbol Option symbols: PREWASH , STAIN , SENSITIVE...
  • Page 13 Chapter Repetition Programme progress display After having pressed the button 8, the display shows the running phase of the washing program . On the display you can see also the description of the selected type of fabric, an animated bar, that indicates the carried out cycle and the remaining one, the duration of the washing program and the end of cycle.

  • Page 14: First Use

    First Use Ensure that the electrical and water connections comply with the installation instructions. Remove the polystyrene block and any material from the drum. Run a cotton cycle at 95°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine.

  • Page 15: Setting The Brightness

    S S E E T T T T I I N N G G S S menu. Press the button 5 to access in the menu. Use the button 4 again to scroll all the settings and press button 5 to confirm your choice. Setting the brightness The B B R R I I G G H H T T N N E E S S S S setting allows you to modify the backlight intensity of the display.

  • Page 16: Daily Use

    Daily Use Load the laundry 1. Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. 2. Close firmly the door. You must hear a click during closing.

  • Page 17: Select The Required Programme

    Select the required programme (1) You can choose the right programme for any type of laundry following the descriptions on the washing programme tables (see Washing Programmes). Turn the programme selector dial to the required programme. The programme selector determines the type of washing cycle (e.g. water level, drum movement, number of rinses) and the washing temperature according to the type of laundry.

  • Page 18: Programme Options

    «Night cycle» : by selecting this option, the machine will not drain the water of the last rinse, so as not to wrinkle the laundry. As all spinning phases are suppressed, this washing cycle is very noiseless and it can be selected at night or in times with a more economical power rate On some programmes the rinses will be...

  • Page 19: Select The Stain Option

    Select the Stain option Select this option to treat heavily soiled or stained laundry with stain remover (extended main wash with time optimised stain action phase). This option is not available with a temperature lower than 40°C. For the compatibility between this option and all washing programmes consult the chapter «Washing programmes».

  • Page 20: Select The Child Lock Option

    by pressing the button 4 select the number of the MEMORY (1-2) in which ● you wish memorize your customized programme. press the button 5 to save the selected programme. On the display appears the ● message «Saved» in highlighted mode. To change the memorized programme setting repeat the procedure from the beginning.

  • Page 21: Select The Time Saving Option

    Select the Time Saving option (button 6) The washing machine proposes by default the washing cycle for «Normally soiled laundry». The washing cycle can be shorted by means of this button. This option can be selected with the washing programmes for COTTONS, SYNTHETICS and DELICATES.

  • Page 22: Altering An Option Or A Running Programme

    Selecting the delayed start: Select the programme and the required options; ● Select the delay start by pressing the button 9; ● Depress the button 8: the machine starts its hourly countdown. The ● programme will start after the selected delay has expired. You can cancel the delay time at any moment, before you press the button 8.

  • Page 23: Opening The Door After The Programme Has Started

    Opening the door after the programme has started First set the machine to pause by pressing the button 8. If the messages «Pause» and «Door unlocked» appear alternately on the ● display, the door can be opened. the messages «Pause» and «Door unlocked» don’t appear on the display, ●...

  • Page 24: Washing Programmes

    Washing programmes Washing programmes Programme/ Description of the T T y y p p e e o o f f l l a a u u n n d d r r y y Options Temperature programme Spin reduction/Rinse hold/Night cycle Main wash White cotton: e.g.
  • Page 25 Washing programmes Washing programmes Programme/ Description of the T T y y p p e e o o f f l l a a u u n n d d r r y y Options Temperature programme Spin reduction/Rinse Main wash DELICATES hold/Night cycle - Delicate fabrics: for...
  • Page 26 Washing programmes Washing programmes Programme/ D D e e s s c c r r i i p p t t i i o o n n o o f f t t h h e e T T y y p p e e o o f f l l a a u u n n d d r r y y Options p p r r o o g g r r a a m m m m e e Temperature...
  • Page 27 Washing programmes Washing programmes Type of fabric Max. Load 8 kg COTTONS 4 kg SYNTHETICS DELICATES 4 kg JEANS 2 kg EASY IRON 3 kg BLANKET 2 kg WOOL ANDWASH 1 kg LINGERIE SILK 3 kg OUTDOOR SPORTS . - 3 3 kg 5 kg QUICK INTENSIVE...

  • Page 28: Programme Information

    Programme informations Programme informations The washing program for white cottons. This program eliminates the micro-organisms thanks to the washing by 60°C HYGIENE and an additional rinse. So that this action is more effective, place into the compartment "Stains" a special additive "Hygiene"...
  • Page 29 Programme informations Programme informations Delicate washing programme suitable for silk and mixed Silk synthetic items. Washing temperature is 30°C. Special program for sport clothes washing. The maximum Outdoor sports temperature is 40°C. By selecting this program, do not add any additives. Special program at 30°C, duration - approx.

  • Page 30: Washing Hints

    Preparing the wash cycle Preparing the wash cycle Sorting out the laundry Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. Temperatures for normally soiled white cottons and linen (e.g. tea cloths, 95°...

  • Page 31: Maximum Loads

    Preparing the wash cycle Maximum loads Recommended loads are indicated in the washing programme charts. General rules: Cotton, linen: drum full but not too tightly packed; Synthetics: drum no more than half full Delicate fabrics and woollens: drum no more than one third full. Washing a maximum load makes the most efficient use of water and energy.

  • Page 32: Detergents And Additives

    Preparing the wash cycle Rust: oxalic acid dissolved in hot water or a rust removing product used cold. Be careful with rust stains which are not recent since the cellulose structure will already have been damaged and the fabric tends to hole. Mould stains: treat with bleach, rinse well (whites and fast coloureds only).

  • Page 33: Quantity Of Detergent To Be Used

    Preparing the wash cycle The washing machine incorporates a recirculation system which allows an optimal use of the concentrated detergent. Pour liquid detergent into the dispenser drawer compartment marked just before starting the programme. Any fabric softener or starching additives must be poured into the compartment marked before starting the wash programme.

  • Page 34: International Wash Code Symbols

    International wash code symbols International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C...

  • Page 35: Care And Cleaning

    Care and cleaning Care and cleaning You must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine.

  • Page 36: Drain Pump

    Care and cleaning 2. Remove the conditioner insert from the middle compartment. 3. Clean all parts with water. 4. Put the conditioner insert in as far as it will go, so that it is firmly in place. 5. Clean all parts of the washing ma- chine, especially the nozzles in the top of the washing-in chamber, with a brush.

  • Page 37: Water Inlet Filter

    Care and cleaningChapter 6. When no more water comes out, unscrew the pump and remove it. Always keep a rag nearby to dry up spillage of water when removing the pump. 7. Remove any objects from the pump impeller by rotating it. 8.

  • Page 38: Frost Precautions

    Care and cleaning Frost precautions If the machine is installed in a place where the temperature could drop below 0°C, proceed as follows: 1. Close the water tap and unscrew the water inlet hose from the tap. 2. Place the end of the emergency emptying hose and that of the inlet hose in a bowl placed on the floor and let water drain out.

  • Page 39: Something Not Working

    Something not working Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. During machine operation it is possible that the yellow pilot light ot the button 8 flashes, one of the following alarm codes appears on the display and at the same some acoustic signals sound every 20 seconds to indicate that the machine is not...
  • Page 40 Something not working Problem Possible cause/Solution The water tap is closed. « « C C a a n n n n o o t t f f i i l l l l w w a a t t e e r r . . P P l l e e a a s s e e c c h h e e c c k k t t h h a a t t t t h h e e t t a a p p i i s s o o p p e e n n a a n n d d t t h h e e n n p p r r e e s s s s S S T T A A R R T T / / P P A A U U S S A A »...
  • Page 41 Something not working Problem Possible cause/Solution Too much detergent or unsuitable detergent (creates too much foam) has been used. ● Reduce the detergent quantity or use another one Check whether there are any leaks from one of the inlet hose fittings. It is not always easy to see this as the water runs down the hose;...
  • Page 42 Something not working Problem Possible cause/Solution The transit bolts and packing have not been removed. ● Check the correct installation of the appliance. The support feet have not been adjusted ● Check the correct levelling of the appliance. The machine vibrates or is noisy: The laundry is not evenly distributed in the drum.
  • Page 43 Something not working Problem Possible cause/Solution The display shows the alarm code: Anti-flooding system has activated. « « A A n n t t i i - - f f l l o o o o d d i i n n g g s s y y s s t t e e m m h h a a s s b b e e e e n n Disconnect the appliance and contact the Service ●...

  • Page 44: Technical Data

    Technical data Technical Data Width 60 cm Height 85 cm Dimensions Depth 63 cm (door included) Power supply voltage/frequency 230 V/50 Hz Electrical connection Voltage - Total power absorbed 2200 W Overall power - Fuse Minimum fuse protection 10 A Minimum 0,05 MPa Water supply pressure...

  • Page 45: Consumption Value

    Consumption value Consumption value Water consumption Energy consumption Programme duration Programme (in litres) (in kWh) (in minutes) Cottons 95° 2,55 Hygiene 60° 40-60 MIX 40° Jeans 60° Synthetics 40° 1,15 Easy iron 40° 0,55 Delicates 40° Blanket 40° Delicate Rinses Drain Spin Wool 40°...

  • Page 46: Installation

    Installation Installation Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. 1. After removing all the packaging, carefully lay machine on it’s back to remove the polystyrene base from the bottom.
  • Page 47 Installation 4. Unscrew and remove the two large rear bolts B and the six smaller bolts C. HEC0003 5. Remove the bracket D and tighten up the six smaller bolts C. Slide out the relevant plastic spacer E. HEC0023 6. Open the porthole, take out the inlet hose from the drum and remove the polystyrene block fitted on the door seal.

  • Page 48: Positioning And Levelling

    Installation Positioning and levelling Install the machine on a flat hard floor. Make sure that air circulation around the machine is not impeded by carpets, rugs etc. Before placing it on small tiles, apply a rubber coating. Never try to correct any unevenness in the floor by HEC007S putting pieces of wood, cardboard or similar materials under the machine.

  • Page 49: Water-Stop Device

    Installation Do not place the inlet hose downwards. Angle the hose to the left or right depending on the position of your water tap. 3. Set the hose correctly by loosening the ring nut. After positioning the inlet hose, be sure to tighten the ring nut again to prevent leaks. 4.

  • Page 50: Electrical Connection

    Installation P1118 Important! The drain hose may be extended to a maximum of 4 metres. An additional drain hose and joining piece is available from your local Service Centre. Electrical connection Information on the electrical connection is given on the rating plate on the inner edge of the appliance door and in the chapter «Technical Data».

  • Page 51: Enviroment Concerns

    Environment concerns Enviroment concerns Packaging materials The materials marked with the symbol are recyclable. >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Old machine Use authorised disposal sites for your old appliance. Help to keep your country tidy! The symbol on the product or on its packaging indicates that this product may not be treated as household waste.

  • Page 52: Guarantee

    European guarantee European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee orotherwise by law. If you move from one of these countries to another of the countries listed, the appliance guarantee will move with you subject to the following qualifications: The appliance guarantee starts from the date you first purchased the appliance...

  • Page 53: Customer Service Centres
