Page 3: Introduction
Refer to the “Component Vocabulary” section of the Owner’s Manual to become acquainted with the names of parts. Note: Pictures in this publication may show the SWB-480 with optional accessories or brush kits. © TrynEx International 2013 (REV A) F51302C... -
Page 4: Safety
Owner’s Manual for maintenance checks and service Suitable and adequate mechanic’s equipment is required for performing maintenance and service proce- dures. The SWB-480 is powered by gasoline. Know the location of fire extinguishers and observe fire safety proce- dures. © TrynEx International 2013 (REV A) F51302C... -
Page 5: Assembly Instructions
Cut down at each corner of the box; fold the sides down. STEP 3 Rest the handlebar on the clamps. STEP 4 Mount Handlebar to the supports with the knob. STEP 5 Put the other half of the clamps onto the studs. © TrynEx International 2013 (REV A) F51302C... - Page 6 Put locknuts and washers on the studs. STEP 8 Tighten the nuts so the handlebars will still move, but not fall. STEP 9 Secure the handlebar supports to the handlebar with the knobs. © TrynEx International 2013 (REV A) F51302C...
- Page 7 Support the machine at the front with a wooden block. Secure the rear wheels with chocks. STEP 13 Attach Support Wheel. B. Push the sleeve A. Parts. through the wheel. Continued on next page... © TrynEx International 2013 (REV A) F51302C...
- Page 8 Remove the bolts on both sides that hold the Wheel Drive Housing to the Brush Drive Frame. Pull the Brush Drive Frame forward keeping the frame as level as possible and keeping the frame from scraping the cover. © TrynEx International 2013 (REV A) F51302C...
- Page 9 STEP 19 Fix the Cable to the Handle Bars with cable ties at the locations show. Trim the end off when finished all the cable ties. Continued on next page... © TrynEx International 2013 (REV A) F51302C...
- Page 10 STEP 21 Installing the Brushes. IMPORTANT The brushes must be assembled so the black A. Parts. row of bristles touches Washer the ground before the white row of bristles Brushes when the brush rotates. © TrynEx International 2013 (REV A) F51302C...
- Page 11 Cap-Gear. I. Tighten the locknut. H. Put the cap and washer on the end. You will need two 19 Thread on the Locknut. mm wrenches. © TrynEx International 2013 (REV A) F51302C...
- Page 12 Begin tightening. Do not force the knob to tighten. Refer to “Adjusting Brush Height” for instructions to adjust the brush height. FINISHED IMPORTANT Now that assembly is finished, fill the motor with oil and fuel tank with unleaded gasoline. See Maintenance Instruc- tions in Owner’s Manual for oil-filling instructions. © TrynEx International 2013 (REV A) F51302C...
-
