- Page 1 EYEON PRODUCT MANUAL Model:EyeOn-14WE...
-
Page 2: Table Of Contents
Table of Contents Introduction……………………………………………………………………………………………………………………………..Page 4 Symbol Definitions……………………………………………………………………………………………………………….Page 4 EyeOn……………………………………………………………………………………………………………………………………….Page 4 Product Overview…………………………………………………………………………………………………………Page 4 Features……………………………………………………………………………………………………………………….Page 5 Technical Specifications………………………………………………………………………………………………..Page 6 Feature Details……………………………………………………………………………………………….………….Page 7-8 Accessory Overview……………………………………………………………………………………………………………….….Page 9 BumpGuard…………………………………………………………………………………………………………………..Page 9 Overview…………………………………………………………………………………………………………..Page 9 Technical Specifications…………………………………………………………………………………….Page 9 Installation………………………………………………………………………………………………………..Page 9 PowerGrip……………………………………………………………………………………………………………………..Page 9 Overview………………………………………………………………………………………………………...Page 10 Charging…………………………………………………………………………………………………..…..…Page 10 Technical Specifications……………………………………………………………………………….….Page 10 Installation…………………………………………………………………………………………………..….Page 10 Getting Started……………………………………………………………………………………………………………………..…..Page 11 Device Setup…………………………………………………………………………………………………………..…….Page 11... - Page 3 User Setup………………………………………………………………………………………………………Page 14 Number of Calibration Points………………………………………………………………………….Page 15 Calibration Target……………………………………………………………………………………………Page 15 Positioning………………………………………………………………………………………………………Page 16 Calibration………………………………………………………………………………………………………Page 17 Calibration Results………………………………………………………………………………………….Page 17 QuickACCESS Software-Toolbar…………………………………………………….……………………….Page 18-19 QuickACCESS Software-Settings……………………………………………………..…………………….……..Page 20 Calibration Menu…………………………………………………………………………………………….Page 20 Click Menu…………………………………………………………………………….………………………..Page 21 Toolbar Menu…………………………………………………………………………..…………..…………Page 22 Profile Menu………………………………………………………………………….………………………...Page 23 Support Menu……………………………………………………………………….……………..………….Page 24 Done Menu………………………………………………………………………………………………………Page 24 Additional Software Information……………………………………………………………………………………………….Page 25 Additional Windows Features &...
- Page 4 Operating Environment……………………………………………………………………………………………….Page 30 Storage Environment…………………………………………………………………………………………………..Page 30 Warranty & Repair……………………………………………………………………………………………………………………Page 31 Manufacturer’s Limited Warranty………………………………………………………….………………..Page 31-32 Premium Warranty…………………………………………………………………………………………..………….Page 33 Premium+ Warranty…………………………………………………………………………..………………………..Page 33 Compliance………………………………………………………………………………………………………………..……………..Page 34 Statement of Compliance………………………………………………………………………………..……………Page 34 Applicable Directives……………………………………………………………………………………..……………..Page 34 Directives and Standards………………………………………………………………………………..…………….Page 34...
-
Page 5: Introduction
PRODUCT MANUAL INTRODUCTION Symbol Definitions: Symbol Definition The WARNING symbol calls attention to a procedure, practice, or the like, which, if not correctly performed or adhered to, could result in personal injury. Do not WARNING! proceed beyond a WARNING symbol until the conditions identified are fully understood. -
Page 6: Features
EyeOn – Features Front Camera Power Status Charge Status Charging Port USB Port Eye Gaze Reset Button Touchscreen Speakers Volume Power Eye Gaze Camera Up & Down Rear Camera Headphone Port USB Port HDMI Port Speakers Kickstand... -
Page 7: Technical Specifications
EyeOn – Technical Specifications Size/Type: 14” IPS LCD Display Resolution: 1080p (1920x1080) Aspect Ratio: 16:9 Display Viewing Angle: 85° Vertical and Horizontal Refresh Rate: 59 Hz Protection: Gorilla® Glass Screen Protection Front Camera Resolution: 2MP Web Cameras Rear Camera Resolution: AEYE 2.0 Eye Tracker Camera with 2nd Technology: Generation Eye-Tracking-On-A-Chip Technology... -
Page 8: Feature Details
EyeOn – Feature Details Power Status The power indicator light will display green when the EyeOn is on, in sleep mode, or charging. The power indicator light will be off when the EyeOn is shut down. Charge Status The charge status light provides an indication of the battery charge level. Charge Status Light Color Battery Level Green... - Page 9 HDMI Port The EyeOn includes an HDMI output port for connection to other displays. Eye Gaze Reset Button The EyeOn includes an eye gaze reset button allowing the eye gaze camera to be reset within seconds. Speakers The EyeOn includes four speakers integrated inside of the housing to maximize the volume level for speech output.
-
Page 10: Accessory Overview
Accessory Overview: BumpGuard™ - Protective Case Overview The BumpGuard protective case provides additional durability to prevent damage in the event that the EyeOn is dropped. The case surrounds all four sides of the EyeOn device, as shown in blue below. Front View Back View Side View... -
Page 11: Overview
Front View Side View Charging The PowerGrip, when installed on your EyeOn, will automatically charge as long as it is connected to the provided power adapter. The PowerGrip will only charge after your EyeOn is fully charged. Approximate 4 hours to fully charge. When the PowerGrip is not connected to power adapter, it will discharge before drawing power from your EyeOn. -
Page 12: Getting Started
GETTING STARTED: Device Setup: Powering On: To power on your EyeOn press the power button on the top of your device once (see pg. 5 for power button locations and functions). Once powered on your device will launch into the Windows Desktop. Windows Desktop Overview: Once the EyeOn is set up, you will be presented with the Windows desktop, which will be used to launch applications and adjust device settings like brightness, volume, and connecting external devices. -
Page 13: Adjusting The Volume
Adjusting the Volume The volume of the EyeOn can be adjusted by using either the volume buttons on the top of the device or through Windows settings. To adjust the volume through Windows: 1. Select the “Sound” icon on the bottom-right corner of the taskbar (see Windows Desktop Overview on pg. -
Page 14: Connecting To A Wireless Network
Connecting to a Wireless Network (Wi-Fi): Your EyeOn should be connected to the internet to access any online features. To connect to a Wi-Fi network: 1. Select the “Network” button in the bottom-right corner of the taskbar (see Windows Desktop Overview on pg. -
Page 15: Eyegaze With Quickaccess
EyeGaze with QuickACCESS™: To enable the EyeGaze control function of your EyeOn, you should launch the “QuickACCESS” application (see “Windows Desktop Overview” on pg. 11 to locate the QuickACCESS application). QuickACCESS Software: Setup When launching the QuickACCESS software for the first time, the program will take you through a setup tutorial. -
Page 16: Number Of Calibration Points
Step 3: Number of Calibration Points Select the number of calibration points. Tip: For the first calibration, we recommend a 9-point calibration. Step 4: Calibration Target Select the preferred calibration target image. Tip: We recommend using the balloon or penguin calibration targets with children or individuals with low-cognitive function in order to focus their attention during the calibration process. -
Page 17: Positioning
Step 5: Positioning You will need to be within an appropriate distance from the eye gaze camera before starting the calibration process. ➢ If the circle is red, the Seemore character will prompt you to move closer or further away from the EyeOn. -
Page 18: Calibration
Step 6: Calibration Follow the targets that appear on the screen with only your eyes. Avoid moving your head while following the targets. Step 7: Calibration Results If the calibration is successfully completed, the QuickACCESS toolbar can be launched by clicking the next arrow that appears on the screen with either the touchscreen input or eye gaze input. -
Page 19: Quickaccess Software-Toolbar
QuickACCESS Software: Toolbar Position Indicator Pause Eye Gaze Toolbar Up/Down Toolbar Left/Right Page Down Page Up Right Click Left Click Double Click Drag & Drop Zoom Window Snap Keyboard Settings Position Indicator Indicates whether you are at the proper distance from the eye gaze camera. ➢... - Page 20 Keyboard Launch an on-screen QWERTY keyboard. Pause Eye Gaze Pause the eye gaze functionality to use alternative device input methods, such as the touchscreen. Toolbar Up/Down Adjusts the position of the QuickACCESS toolbar between the top and bottom of the screen. Page Down Scroll to move the page down when using applications such as webpages.
-
Page 21: Quickaccess Software-Settings
QuickACCESS Software: Settings Calibrate Menu The calibrate menu allows you to re-calibrate at any time via a 1-point, 5-point, 9-point, 16-point, or user driven calibration. 1-Point Calibration: To be used as a quick, calibration update to improve your eye gaze accuracy. 5-Point Calibration: Requires you to follow 5 targets on the screen in a fixed pattern. -
Page 22: Click Menu
Click Menu The click menu allows you to adjust the type of click functionality for your preferences. Click Type: ➢ Dwell Click: Allows you to click by dwelling your gaze for a specified period of time. ➢ Blink Click: Allows you to click by blinking for a specified period of time. Enable Click Sounds: Allows you to turn the click sounds on or off. -
Page 23: Toolbar Menu
Toolbar Menu The toolbar menu allows you to adjust the settings for the QuickACCESS toolbar. Toolbar Layout: Allows you to select the type of QuickACCESS toolbar: Simple, Advanced, or Pro. These versions offer different levels of available buttons in the toolbar. The Windows 10 toolbar is also compatible for use with your EyeOn device and is integrated with each Windows 10 license. -
Page 24: Profile Menu
Profile Menu If multiple people will be using your EyeOn device, you can create user profiles to save individual calibration settings. New User: To create a new user profile, type the person’s name into the “New User” field. Click “Create” to launch the calibration process for the new user. User List: ➢... -
Page 25: Support Menu
Support Menu The support menu allows you to submit a support ticket for any technical issues related to the QuickACCESS software. Submit Support Ticket: Click the “Submit Support Ticket” button to open the form which will allow you to request technical support in the event of a technical issue. Done Button When you are ready to close out of the QuickACCESS settings menu, click the “Done”... -
Page 26: Additional Software Information
ADDITIONAL SOFTWARE INFORMATION Additional Windows Features & System Settings: Browsing your Files Any files that are saved to your device (documents, pictures, downloads, etc.) can be found in the Windows “File Explorer”. To navigate the File Explorer: 1. Select the File Explorer button on the bottom of the Windows task bar to open the file menu. Once the file menu is open, select the appropriate folder that you would like to navigate to, from the menu on the left side (see Windows Desktop Overview on pg. -
Page 27: Adjusting Power Options
3. Select the “+ Add Bluetooth or other device” button at the top of the Bluetooth menu. The Bluetooth connection menu will open. 4. Select “Bluetooth” from the menu that opens and the EyeOn will search for nearby Bluetooth devices to connect to. 5. -
Page 28: External Display Settings
External Display Settings The EyeOn supports connecting an external display via the HDMI port on the side of the device (see “EyeOn Features” on pg. 5 for reference). To adjust settings for an external display: 1. Select the “Start” button in the bottom-right corner of the task bar (see Windows Desktop Overview on pg. -
Page 29: Application Options
Application Options: Application Overview The EyeOn device supports several applications for various functions including speech generation and eye gaze. Speech Generation Applications The EyeOn can be pre-loaded with various speech generation applications. The application configuration is selected when the EyeOn device is ordered. Common speech generation applications include: Application Description Augmentative and alternative communication (AAC) software... -
Page 30: Support
Success Coach program. EyeTech™ has designed this program to support your unique goals, so you can utilize EyeOn as a seamless extension of yourself. Our Success Coaches are equipped to help you do just that! Our Success Coach team consists of: •... -
Page 31: Maintenance
Proper disposal of your device and the device’s battery is important for safety as well as beneficial to the environment. EyeTech cares for the environment and encourages its customers to properly dispose of devices and accessories in accordance with local regulations. In some areas, disposal of these items in household or business trash may be prohibited. -
Page 32: Warranty & Repair
If you discover a defect, EyeTech will, at its option, repair or replace your device with a new or refurbished unit of the same or similar model. - Page 33 What do I do if I need support? EyeTech can be reached via email or by phone at any time.. Please ensure you have your device serial number ready in order to receive prompt support.
-
Page 34: Premium Warranty
What options do I have if my issue is not covered under warranty? EyeTech provides quality hardware repairs for devices that are less than 5 years old and that are no longer covered by a limited hardware warranty. This includes repairs to common accidental issues like broken/cracked displays, I/O Ports (USB, Audio Jack, HDMI, etc.), damaged power/volume buttons, etc. -
Page 35: Compliance
COMPLIANCE Statement of Compliance: EyeTech Digital Systems, Inc. declares that this equipment is in compliance with and is built to the standards called out in EU directive 2002/95/EC. Applicable Directives EyeTech Digital Systems, Inc. declares that this equipment is in conformity with the provisions of Council EMC Directive, 2004/108/EEC. - Page 36 FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference.. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
- Page 37 Operations in the 5.15-5.25GHz band are restricted to indoor use only. RF Exposure Information and Statement The SAR limit of FCC/IC is 1.6 W/kg averaged over one gram of tissue. Device types: EyeOn-14WE (FCC ID: 2AVV8-EYEON, IC: 25941-EYEON)) has also been tested against this SAR limit. The highest SAR value reported under this standard during product certification for use at the body is1.491W/kg.
