- Page 1 Getting Started Guide Version 1.0 CC3000-Pmod ™ Compatible Wi-Fi Adapter ®...
- Page 2 REVISION HISTORY DATE VERSION REVISION 08/21/2012 Initial Release 2 Getting Started with the CC3000-Pmod Compatible Wi-Fi Adapter Version 1.0 ™ ®...
- Page 3 Upon completion, be sure to retain your login and password information for future visits to Avnet’s DRC. Logging in once gives you unlimited access to all technical support files and downloads. You will also have the chance to request email notifications whenever there are updates to your design kit.
- Page 4 Marks other than its own. Avnet and AV design logos are registered trademarks and service marks of Avnet, Inc. Avnet’s Marks may be used only with the prior written permission of Avnet, Inc. 10. General. The terms and conditions set forth in the License Agreement or at www.em.avnet.com...
-
Page 5: Table Of Contents
Lab Tools Software Installation ..........16 Version 1.0 Getting Started with the CC3000-Pmod Compatible Wi-Fi Adapter 5 ™... -
Page 6: About This Guide
ABOUT THIS GUIDE Additional Documentation Available from Avnet: Documents specifically regarding the Avnet designed Xilinx Spartan-6 FPGA LX9 MicroBoard (PN: AES-S6MB-LX9-G) are available for download at: http://www.em.avnet.com/s6microboard • Xilinx Spartan-6 FPGA LX9 MicroBoard User Guide This specification provides a detailed description of the S6LX9 MicroBoard circuitry. -
Page 7: Additional Support Resources
PCB interface level. Additional Support Resources Please post questions to the specific kit thread on the Avnet Development Kit Community Forum at http://community.em.avnet.com/t5/Avnet-Development-Boards/ct-p/Avtbds To search the database of silicon and software questions and answers or to create a technical support case in http://www.xilinx.com/support... -
Page 8: Introduction
CC3000. Conforming to the Digilent Pmod Interface ™ Specification and 2 x 6 pinout, it is designed to attach to Avnet FPGA development boards that comply with the Pmod Interface Specification. The built-in IP networking stack provides ubiquitous Wi-Fi and Internet access without needing a complex CPU and OS. -
Page 9: Getting Started
Wi-Fi Webserver Reference Design Demo Requirements • Computer running Windows XP or later, with an Internet browser installed. • Wi-Fi Access Point/Router whose SSID,etc can be configured by the user. • Avnet Spartan-6 FPGA LX9 MicroBoard • CC3000-PMOD Wi-Fi module • S6LX9_CC3000_PMOD_WiFi_Demo_mcs_13_4_1.zip file • Type A male to Type A female USB extension cable and/or a +5V power supply with Type A female USB... - Page 10 The IP parameters shown in the DOS window above have been hard-coded in the project’s demo_config.h and cc3000.c files. Thus the Wireless Access Point/Router configuration must be edited accordingly on your WAP: Access Point/Router SSID = xfest2012-s6lx9 AP LAN subnet IP address = 192.168.1.1 10 Getting Started with the CC3000-Pmod Compatible Wi-Fi Adapter Version 1.0 ™...
-
Page 11: Wi-Fi ® Webserver Demo Setup Instructions
PMOD Connector. Ensure that on the WiFi PMOD, J4 is installed and J3 is set with a jumper between pins 2-3 “Normal Mode”, as shown below. Figure 5 Version 1.0 Getting Started with the CC3000-Pmod Compatible Wi-Fi Adapter 11 ™... - Page 12 0, exhibiting the same flashing Red LEDS (D2, D3, D9, D10). The following two figures show two points in time of the terminal output: Figure 7 12 Getting Started with the CC3000-Pmod Compatible Wi-Fi Adapter Version 1.0 ™...
- Page 13 Alternately clicking the web page buttons will toggle the LEDs in the pairs listed. This takes us to the end of the WiFi Webserver demonstration. For any issues with this demonstration please Centralized-Support@avnet.com contact Avnet Centralized Technical Support at or via the web at http://www.em.avnet.com/techsupport Version 1.0...
-
Page 14: Next Steps
Now that you have run through the embedded demo, you should have at least the Xilinx 13.4 development tools ISE WebPACK and EDK in order to proceed. The source project can be downloaded from http://www.em.avnet.com/pmodwifi, after selecting the “support & downloads” button. -
Page 15: Getting Help And Support
As discussed earlier, below is a diagram of the existing demonstration which is the “Spartan-6 LX9 Internet Appliance Demo” shown at 2012 X-fests. “Plan B” is only needed if hardwired ethernet is desired. A full description, including the hardware requirements of this full application will be place on the Avnet DRC at http://www.em.avnet.com/pmodwifi... -
Page 16: Installation And Licensing Of Lab Tools
