Crutchfield 000NAVIG Installation Manual

As with any car audio/video installation, your ﬁrst

step is to disconnect the negative terminal of your

car battery to prevent short circuits. Check your Crutchﬁeld

MasterSheet™ (available for most vehicles) or vehicle owner's

manual for speciﬁc directions. In some vehicles, disconnecting

the battery may require you to re-enter a security code or have

the dealer reset the internal computer.

Navigation Installation Guide

IMPORTANT

Before starting, compare items on your invoice with items received. Carefully check through packaging material.

If any item is missing, please call: Crutchfield Customer Service at 1-800-955-9091

Although reasonable attempts are made to verify the accuracy of the information

contained in this guide, it is presented without warranties or guarantees of any

type due to the constantly changing nature of this type of information and running

changes in vehicle production. Any person or entity using this information does so

at his or its own risk. If you find that our instructions do not apply to your vehicle,

or if you have questions, do not continue with your installation. Contact our

toll-free technical support for assistance (Tech support number is on your invoice).

Tools Needed:

(depending upon vehicle)

Flat Blade

Phillips

Screwdriver

Drill &

Pliers

Bit Set

Wire Stripper/

Crimp Tool

Wire taps

* 0 0 0 N A V I G *

Panel Tool

Utility Knife

Socket &

Male

Ratchet Set

and Female Disconnects

Torx Driver Set

000NAVIG

Revision 3/15/05

Table of Contents

Do you have a question about the 000NAVIG and is the answer not in the manual?

Page 1 IMPORTANT Before starting, compare items on your invoice with items received. Carefully check through packaging material. If any item is missing, please call: Crutchfield Customer Service at 1-800-955-9091 * 0 0 0 N A V I G * Although reasonable attempts are made to verify the accuracy of the information...
Page 2 ® Speed sensor wire location varies; it may be under the hood, as pictured above. Call the Tech Support phone number on your Crutchﬁeld invoice for assistance in locating the speed sensor in your speciﬁc vehicle. Copyright 2005 Crutchfield Corporation...
Page 3 000NAVIG Connecting to the Speed Sensor (cont.); Connecting to the Reverse Light Using a wire tap and male disconnect CAUTION: If the speed sensor wire is under the dash, you can run is the easiest way to make the wiring the lead to the DVD-ROM drive under the carpet on your connections you’ll need.
Page 4 Remove panels necessary to route and conceal wires. Test system before reinstalling panels. SAFETY CHECK Kick panel ✔ Make sure seats and seat belts are secured to manufacturers specifications. Upper Pillar Trimpanel ® Copyright 2005 Crutchfield Corporation...
Page 5 Though not difﬁcult, this should be done carefully. Once the cables are connected, and the box is mounted, you’re ready to navigate. All wires, including power, audio, and video, must be run from the ® navigation unit to the appropriate locations, usually under the vehicle’s carpet. Copyright 2005 Crutchfield Corporation...
